1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $89.23

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $93.28
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,673.17
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $61.66
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $8,315.78
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $733.84

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $306.83

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $40.26

Gaskets

PN	Item
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,898.69
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $3,212.52
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $365.29
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $266.12
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $330.08

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,507.76
001609592	URRACO DISTRIBUTOR CAP URRACO DISTRIBUTOR CAP	Avail to order Our Price: $352.11
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,673.17
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,653.00
001609591	URRACO ROTOR ARM URRACO ROTOR ARM MAGNETTI MARELLI	Avail to order Our Price: $259.00

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $123.23
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $161.79
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 11 - Differenzinale

1972-1977 Lamborghini Urraco USA Differenzinale (11)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008201002	M10X1 SPECIAL NUT	2 req	Avail to order Our Price: $10.73
2	002308238	DRIVE SHAFT FLANGE	2 req	Avail to order Our Price: $250.66
3	002306406	PLANETARY ADJUSTMENTRING	2 req	Avail to order Our Price: $75.65
4	008100830	SCREW M8X20 UNI 5739/8G/Z	12 req	Current Stock: 19 Our Price: $0.50
5	008400806	WASHER 15X8X1.5 UNI 1750 R40/Z	12 req	Current Stock: 5 Our Price: $0.60
6	002306412	FLANGE	1 req	Avail to order Our Price: $348.04
7	008617003	OIL SEAL	2 req	Current Stock: 2 Our Price: $12.85
8	008609801	O-RING	2 req	Avail to order Our Price: $3.42
9	008100820	SPECIAL SCREW M8X20	10 req	Avail to order Our Price: $10.73
10	008525502	BEARING	1 req	Avail to order Our Price: $241.22
11	002306398	DIFFERENTIAL CROWN WHEEL	1 req	Avail to order Our Price: $798.27
12	002304785	PLANETARY SHIM ADJUSTMENT	2 req	Avail to order Our Price: $94.86
13	002306400	DIFFERENTIAL PLANETARY GEAR	2 req	Avail to order Our Price: $1,369.89
14	002306448	FLANGE PIN WASHER	2 req	Avail to order Our Price: $20.74
15	002306441	DRIVE SHAFT FLANGE PIN	2 req	Avail to order Our Price: $44.01
16	002306396	SATELLITE GEAR PIN	1 req	Avail to order Our Price: $136.43
17	002302026	DIFFERENTIAL SATELLITE GEAR	2 req	Avail to order Our Price: $2,387.41
18	002302132	SATELLITE BUSHING	2 req	Avail to order Our Price: $49.68
19	002313876	SATELLITE RADIUS RING	2 req	Avail to order Our Price: $60.37
20	002306389	DIFFERENTIAL INNER BOX	1 req	Avail to order Our Price: $374.97
21	002306411	FLANGE	1 req	Avail to order Our Price: $458.28
22	008505503	BEARING	1 req	Current Stock: 2 Our Price: $105.74
23	002306433	O-RING	1 req	Current Stock: 1 Our Price: $12.20
24	008585501	O-RING E 55 UNI 7435-75	1 req	Avail to order Our Price: $6.18
25	002306432	O-RING	1 req	Avail to order Our Price: $54.92
26	008100819	SPECIAL SCREW M8X25	2 req	Avail to order Our Price: $6.01
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
