1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $89.23

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $93.28
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,673.17
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $61.66
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $8,315.78
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $733.84

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $306.83

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $40.26

Gaskets

PN	Item
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,898.69
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $3,212.52
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $365.29
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $266.12
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $330.08

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,507.76
001609592	URRACO DISTRIBUTOR CAP URRACO DISTRIBUTOR CAP	Avail to order Our Price: $352.11
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,673.17
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,653.00
001609591	URRACO ROTOR ARM URRACO ROTOR ARM MAGNETTI MARELLI	Avail to order Our Price: $259.00

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $123.23
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $161.79
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 22 - Sospension one Anteriore

1972-1977 Lamborghini Urraco USA Sospension one Anteriore (22)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	005107466	SHOCK ABSORBER UPPERSHIM	2 req	Avail to order Our Price: $54.09
2	008200804	NUT	6 req	Current Stock: 7 Our Price: $1.30
3	005207465	SHOCK ABSORBER NUT STOP	2 req	Avail to order Our Price: $11.39
4	008201405	M14X1.5 SPECIAL NUT	2 req	Avail to order Our Price: $6.18
5	005207464	NLA (NO LONGER AVAILABLE)	8 req	*See Description
6	008200804	NUT	2 req	Current Stock: 7 Our Price: $1.30
7	005108658	FRONT SHOCK ABSORBER PAD	2 req	Avail to order Our Price: $219.48
8	008830119	NLA (NO LONGER AVAILABLE)	2 req	*See Description
9	005108120	SHOCK ABSORBER BELLOWS	2 req	Avail to order Our Price: $134.42
10	008830107	CLAMP D.68/U	4 req	Avail to order Our Price: $21.56
11	008200806	NUT	4 req	Current Stock: 25 Our Price: $0.40
12	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $0.50
13	005107110	BAR ATTACHMENT BRACKET	2 req	Avail to order Our Price: $55.68
14	008921501	ROLL BAR MOUNT D15/U	2 req	Avail to order Our Price: $13.66
15	005108224	TORSION BAR COVER	1 req	Avail to order Our Price: $107.88
16	005107450	FRONT TORSION BAR	4 req	Avail to order Our Price: $450.23
17	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $1.90
18	008200804	NUT	4 req	Current Stock: 7 Our Price: $1.30
19	008800801	BUSHING D.8X14X25 MM	4 req	Avail to order Our Price: $43.84
20	008921603	POSSIBLE NLA OR NEW PART NUMBER -	4 req	*See Description
21	008100842	SCREW M8X45 UNI 5737/8G	2 req	Current Stock: 11 Our Price: $1.63
22	005106980	RH FRONT ROLL BAR TIE-ROD	2 req	Avail to order Our Price: $36.53
23	005110342	LH FRONT TORSION BARTIEROD	2 req	Avail to order Our Price: $36.53
24	005119407	SHOCK ABSORBER CHASSIS MOUNT	2 req	Avail to order Our Price: $185.43
25	005206915	REAR SPRING UPPER BRACKET	2 req	Avail to order Our Price: $26.03
26	005207451	SHOCK ABSORBER SPRING BRACKET	4 req	Avail to order Our Price: $59.46
27	005108657	FRONT SUSPENSION SPRING	2 req	Avail to order Our Price: $581.94
28	N01024230	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $1.90
29	008200804	NUT	4 req	Current Stock: 7 Our Price: $1.30
30	005207821	SUSPENSION LINKAGE	2 req	Avail to order Our Price: $1,284.78
31	008201008	NUT	6 req	Current Stock: 2 Our Price: $1.00
32	008200804	NUT	6 req	Current Stock: 7 Our Price: $1.30
33	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $1.90
34	008101618	SPECIAL SCREW M16X1.5X120	2 req	Avail to order Our Price: $24.00
35	008921602	ESTENBLOCK	2 req	Avail to order Our Price: $137.49
36	005106982	RH/LH FRONT LOWER ARM	2 req	Avail to order Our Price: $380.34
37	008401611	WASHER 17X29X3 5S UNI 16592	2 req	Avail to order Our Price: $14.80
38	008201603	NUT	1 req	Avail to order Our Price: $4.21
39	005106965	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
40	008201008	NUT	4 req	Current Stock: 2 Our Price: $1.00
41	008401006	WASHER	4 req	Current Stock: 1 Our Price: $0.70
42	008101032	SPECIAL SCREW M10X55	4 req	Avail to order Our Price: $7.97
43	008100809	SCREW M8X22 UNI 5739/8G/ZD	6 req	Current Stock: 8 Our Price: $2.68
44	005106906	SUSPENSION JOINT	2 req	Avail to order Our Price: $337.30
45	N90630504	HEX. BOLT WITH	4 req	Current Stock: 10 Our Price: $3.36
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
