1972-1977 Lamborghini Urraco USA Condizionatore (2.45)

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $92.07

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $81.81
002108645	Engine Flywheel & Crown Engine Flywheel & Crown	Avail to order Our Price: $7,290.57
002108646	NLA (No longer Available to order) Clutch Plate	Avail to order Our Price: $642.91
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $63.77
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,729.80

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	Relay Relay		Current Stock: 1 Our Price: $41.54

Gaskets

PN	Item
001526484	Engine Gasket Set Urraco 2000 Engine Gasket Kit Urraco 2000	Avail to order Our Price: $1,665.18
001526486	Engine Gasket Set Uracco 3000 Engine Gasket Kit Uracco 3000	Avail to order Our Price: $2,816.32
001526465	Grommet and Oil Seals Set - Urraco 2400 Grommet and Oil Seals Set Urraco 2400	Avail to order Our Price: $320.01
001526464	Grommet and Oil Seals Set - Urraco 2000 Grommet and Oil Seals Set Urraco 2000	Avail to order Our Price: $274.48
001526466	Grommet and Oil Seals Set - Urraco 3000 Grommet and Oil Seals Set Urraco 3000	Avail to order Our Price: $289.60

Ignition

PN	Item
001609428	Distributor/Spark Plug Wiring Distributor/Spark Plug Wiring	Avail to order Our Price: $1,323.45
001609592	Distributor Cap Cap	Avail to order Our Price: $363.11
001612293	Urraco Wiring Harness - USA Urraco Wiring Harness	Avail to order Our Price: $1,722.65
001611700	Urraco Wiring Harness Urraco Wiring Harness	Avail to order Our Price: $1,708.35

Misc

PN	Item	Diagram
900000382	NLA use PN 400093050D for USA replacement		Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.		Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
002408637	Reverse Switch Switch		Avail to order Our Price: $127.24
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76

Open All

Select Group and TAV

< Previous Next >

TAV: 2.45 - Condizionatore

1972-1977 Lamborghini Urraco USA Condizionatore (2.45)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004708837	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
2	004510450	Blower Switch Control - LOW STOCK DISCONTINUED - NLA	1 req	*See Description
3	004508818	Evaporator Conveyor	1 req	Avail to order Our Price: $59.76
4	008411203	This item is no longer available	1 req
5	004505249	NLA (No Longer Available)	1 req	*See Description
6	004510444	Temperature Adjustment Bracket	1 req	Avail to order Our Price: $69.56
7	004510448	Fan Speed AdjustmentPlate	1 req	Avail to order Our Price: $15.94
8	004708840	NLA (No Longer Available)	1 req	*See Description
9	004708839	Heater Motor	1 req	Avail to order Our Price: $683.35
10	004508820	Evaporator Upper Cover	1 req	Avail to order Our Price: $133.65
11	004708842	Motor/Scroll Seal	1 req	Avail to order Our Price: $26.72
12	004708838	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
13	008410502	Washer D.5.3 Uni 1751/Zd	3 req	Current Stock: 33 Our Price: $2.00
14	N01020717	HEXAGON HEAD BOLT	3 req	Current Stock: 4 Our Price: $2.00
15	008410502	Washer D.5.3 Uni 1751/Zd	3 req	Current Stock: 33 Our Price: $2.00
16	N10689901	HEX.NUT	3 req	Current Stock: 5 Our Price: $2.00
17	008700414	Screw 4.2x6.5 Iso8 Uni6949 -B/	36 req	Avail to order Our Price: $2.65
18	004508822	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
19	004510445	Air Temperature Adjustment Pla	1 req	Avail to order Our Price: $15.94
20	004508829	Evaporator Rh Cover	1 req	Avail to order Our Price: $202.29
21	004506916	NLA (No longer available)	1 req	*See Description
22	006514093	This item is no longer available	1 req
23	004708760	Air Choke	2 req	Avail to order Our Price: $498.10
24	004509501	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
25	N01020717	HEXAGON HEAD BOLT	3 req	Current Stock: 4 Our Price: $2.00
26	008410502	Washer D.5.3 Uni 1751/Zd	3 req	Current Stock: 33 Our Price: $2.00
27	004508826	Scroll Net Retainer	1 req	Avail to order Our Price: $29.38
28	004508825	Scroll Net	1 req	Avail to order Our Price: $25.45
29	N01020717	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $2.00
30	008410502	Washer D.5.3 Uni 1751/Zd	4 req	Current Stock: 33 Our Price: $2.00
31	004510015	Isobar Valve	1 req	Avail to order Our Price: $330.24
32	004510014	Compressor Union Hg 500	1 req	Avail to order Our Price: $80.62
33	004509500	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
34	004508828	Evaporator Lh Cover	1 req	Avail to order Our Price: $180.85
35	WHT002961	WASHER	1 req	Current Stock: 39 Our Price: $2.00
36	008100622	Screw M6x12 Uni 5739/8g	3 req	Avail to order Our Price: $6.29
37	006514094	This item is no longer available	3 req
38	008830901	NLA (No Longer Available)	1 req	*See Description
39	006514090	This item is no longer available	1 req
40	004504548	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
41	004505869	Electromagnetic Clutch	1 req	Avail to order Our Price: $969.26
42	004507641	This item is no longer available	1 req
43	004508806	Compressor Belt	1 req	Avail to order Our Price: $32.01
44	008400504	This item is no longer available	1 req
45	008700509	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
46	004509386	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	10 req	*See Description
47	004506017	This item is no longer available	10 req
48	008300826	see PN WHT003166	1 req	Avail to order Our Price: $11.56
49	004505856	Compressor Bracket	2 req	Avail to order Our Price: $316.65
50	004506114	Compressor Shim	1 req	Avail to order Our Price: $11.73
51	004509499	Cleaner/Expansion Valve Pipe	1 req	Avail to order Our Price: $222.99
52	004508816	Evaporator	1 req	Avail to order Our Price: $784.84
53	004506860	Expansion Valve	1 req	Avail to order Our Price: $99.48
54	004508821	Evaporator Vent Bracket	1 req	Avail to order Our Price: $69.56
55	004508824	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
56	004508819	Evaporator Unit Housing	1 req	Avail to order Our Price: $225.16
57	004508827	Evaporator Front Cover	1 req	Avail to order Our Price: $295.93
58	004509159	Compressor/Isobar Valve Pipe	1 req	Avail to order Our Price: $25.03
59	008411002	SEE PN WHT000768	4 req	Avail to order Our Price: $2.00
60	008100902	Screw 3/8x16ncx25.5 Fontan	4 req	Avail to order Our Price: $8.15
61	008301004	Stud M10x45 Uni 59118gz	2 req	Avail to order Our Price: $32.75
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
