1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $89.23

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $93.28
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $61.66
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,673.17
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $8,315.78
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $733.84

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $306.83

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $40.26

Gaskets

PN	Item
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $266.12
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $365.29
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,898.69
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $3,212.52
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $330.08

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,507.76
001609591	URRACO ROTOR ARM URRACO ROTOR ARM MAGNETTI MARELLI	Avail to order Our Price: $259.00
001609592	URRACO DISTRIBUTOR CAP URRACO DISTRIBUTOR CAP	Avail to order Our Price: $352.11
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,653.00
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,673.17

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $161.79
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $123.23
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 2 - Ditribuzione

1972-1977 Lamborghini Urraco USA Ditribuzione (2)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001207721	LH CAMSHAFT	1 req	Avail to order Our Price: $4,844.76
2	001208521	LH CAM PULLEY	1 req	Avail to order Our Price: $916.48
3	008850601	PIN MM 6X16.5	3 req	Avail to order Our Price: $21.56
4	001209675	TIMING COVER RH BRACKET	1 req	Avail to order Our Price: $25.30
5	001209765	This item is no longer available	1 req
6	008101201	SCREW M12X1.25 UNI 5740 10	3 req	Avail to order Our Price: $24.97
7	008411201	RETAINING SHIM WASHER	3 req	Avail to order Our Price: $6.18
8	008502501	BEARING	4 req	Avail to order Our Price: $57.35
9	008575201	O-RING I 52 UNI 3654	4 req	Current Stock: 22 Our Price: $1.40
10	008202501	25X1.5 SIN SPECIAL NUT	3 req	Avail to order Our Price: $16.11
11	001208533	COVER	3 req	Avail to order Our Price: $9.52
12	008410603	WASHER D.6.4 UNI 1751/ZD	2 req	Avail to order Our Price: $0.10
13	008100625	SCREW M6X16 UNI 5739/8G/Z	2 req	Avail to order Our Price: $126.16
14	N01100637	HEX.NUT	3 req	Current Stock: 18 Our Price: $0.40
15	001209677	TIMING COVER LH BRACKET	1 req	Avail to order Our Price: $25.30
16	WHT001197A	WASHER	5 req	Current Stock: 22 Our Price: $0.30
17	008100622	SCREW M6X12 UNI 5739/8G	5 req	Avail to order Our Price: $6.10
18	001209766	This item is no longer available	1 req
19	001208530	SPECER	1 req	Avail to order Our Price: $19.93
20	001208531	SPECER	1 req	Avail to order Our Price: $19.93
21	001208528	TIMING GUIDE FIXING PIN	1 req	Avail to order Our Price: $100.56
22	008401810	TEMPERED WASHER D.18.25X26X2 C	1 req	Avail to order Our Price: $13.66
23	008581601	O-RING E 18 UNI 7435-75	1 req	Avail to order Our Price: $2.60
24	001205844	TIMING TOOTHED BELT	1 req	Avail to order Our Price: $218.36
25	008701202	GRUB SCREW 12K	1 req	Avail to order Our Price: $6.18
26	001209768	This item is no longer available	1 req
27	001205845	NLA (NO LONGER AVAILABLE)	1 req	*See Description
28	001205843	This item is no longer available	1 req
29	001205929	TIMING BELT TIGHTENER GUIDE	4 req	Avail to order Our Price: $234.55
30	001205862	AUXILIARY GUIDE PIN	1 req	Avail to order Our Price: $75.25
31	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.48
32	001206174	CRANKSHAFT PULLEY	1 req	Avail to order Our Price: $178.09
33	008850603	CYLINDER PIN 6X40 DIN.7979	2 req	Avail to order Our Price: $10.73
34	001205881	TIMING GUIDE PIN	2 req	Avail to order Our Price: $61.66
35	008202503	25X1.58G NUT	1 req	Avail to order Our Price: $16.11
36	008801806	BUSHING 18X20X20 MM	2 req	Avail to order Our Price: $106.80
37	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $1.90
38	WHT001514	SPRING WASHER	1 req	Current Stock: 9 Our Price: $26.48
39	008200811	M8 UNI 5589/8G/ZDNUT	1 req	Avail to order Our Price: $6.10
40	008100845	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
41	008401006	WASHER	1 req	Current Stock: 1 Our Price: $0.70
42	008201010	M10SELF LOCKING NUT	1 req	Avail to order Our Price: $1.60
43	001209777	TIMING GUARD BOLT	2 req	Avail to order Our Price: $28.63
44	001208520	RH CAMSHAFT PULLEY	1 req	Avail to order Our Price: $717.64
45	001208527	GUIDE MOUNT FIXING PIN	1 req	Avail to order Our Price: $84.92
46	001208525	TIGHTENER GUIDE BRACKET	1 req	Avail to order Our Price: $224.46
47	001208524	TIMING BELT TIGHTENER BRACKET	1 req	Avail to order Our Price: $71.91
48	001208529	GUIDE BELT TIGHTENERSHIM	1 req	Avail to order Our Price: $8.78
49	008410812	CORRUGATED WASHER D.8.15 UNI 3	2 req	Current Stock: 38 Our Price: $1.70
50	008100809	SCREW M8X22 UNI 5739/8G/ZD	2 req	Current Stock: 8 Our Price: $2.68
51	001208526	TIMING BELT TIGHTENER SPRING	1 req	Avail to order Our Price: $54.09
52	008301007	STUD M10X50 UNI 59118GZ	1 req	Avail to order Our Price: $2.04
53	001205841	This item is no longer available	1 req
54	001207722	RH CAMSHAFT	1 req	Avail to order Our Price: $4,844.76
55	001208208	INTAKE VALVE	8 req	Avail to order Our Price: $97.71
56	001208516	This item is no longer available	16 req
57	001208245	EXHAUST VALVE	8 req	Avail to order Our Price: $426.24
58	001208517	VALVE SPRING LOWER WASHER	16 req	Avail to order Our Price: $8.78
59	001210198	INNER VALVE SPRING	16 req	Avail to order Our Price: $76.16
60	001210197	OUTER VALVE SPRING	16 req	Avail to order Our Price: $76.16
61	001208248	VALVE SPRING UPPER WASHER	16 req	Avail to order Our Price: $19.93
62	001200233	VALVE RETAINER COTTERS	32 req	Avail to order Our Price: $30.83
63	001208519	VALVE BOWL	16 req	Avail to order Our Price: $98.28
64	001205720	VALVE CLEARANCE ADJUSTMENT SHI	16 req	Avail to order Our Price: $15.45
65	008100630	SCREW M6X14 UNI 5739/8G/Z	2 req	Avail to order Our Price: $0.20
66	WHT001197A	WASHER	2 req	Current Stock: 22 Our Price: $0.30
67	008200806	NUT	2 req	Current Stock: 25 Our Price: $0.40
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
