1972-1977 Urraco - USA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $87.81

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $25.41

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $93.81
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,646.52
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $60.70
002108645	ENGINE FLYWHEEL & CROWN ENGINE FLYWHEEL & CROWN	Avail to order Our Price: $8,365.52
002108646	NLA (NO LONGER AVAILABLE TO ORDER) CLUTCH PLATE	Avail to order Our Price: $738.23

Fuel-Air

PN	Item	Diagram
001310353	URRACO AIR FILTER URRACO AIR FILTER		Avail to order Our Price: $308.68

Fuses-Bulbs-Relays

PN	Item	Diagram
001605819	RELAY RELAY		Current Stock: 1 Our Price: $39.61

Gaskets

PN	Item
001526484	ENGINE GASKET SET URRACO 2000 ENGINE GASKET KIT URRACO 2000	Avail to order Our Price: $1,910.05
001526486	ENGINE GASKET SET URACCO 3000 ENGINE GASKET KIT URACCO 3000	Avail to order Our Price: $3,231.76
001526465	GROMMET AND OIL SEALS SET - URRACO 2400 GROMMET AND OIL SEALS SET URRACO 2400	Avail to order Our Price: $367.50
001526464	GROMMET AND OIL SEALS SET - URRACO 2000 GROMMET AND OIL SEALS SET URRACO 2000	Avail to order Our Price: $261.85
001526466	GROMMET AND OIL SEALS SET - URRACO 3000 GROMMET AND OIL SEALS SET URRACO 3000	Avail to order Our Price: $332.05

Ignition

PN	Item
001609428	DISTRIBUTOR/SPARK PLUG WIRING DISTRIBUTOR/SPARK PLUG WIRING	Avail to order Our Price: $1,516.76
001609592	DISTRIBUTOR CAP CAP	Avail to order Our Price: $346.50
001612293	URRACO WIRING HARNESS - USA URRACO WIRING HARNESS	Avail to order Our Price: $1,646.52
001611700	URRACO WIRING HARNESS URRACO WIRING HARNESS	Avail to order Our Price: $1,626.68

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ML CLEANER FLUID		Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $121.27
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $162.79
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 93 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 18 - Freno A Mano

1972-1977 Lamborghini Urraco USA Freno A Mano (18)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Urraco Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003309377	This item is no longer available	1 req
2	008100618	SCREW M6X20 UNI 5739/8G/ZD	4 req	Current Stock: 44 Our Price: $0.35
3	008410603	WASHER D.6.4 UNI 1751/ZD	4 req	Avail to order Our Price: $0.09
4	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $0.40
5	008400806	WASHER 15X8X1.5 UNI 1750 R40/Z	5 req	Current Stock: 5 Our Price: $0.68
6	008820201	SPLIT PIN	4 req	Current Stock: 19 Our Price: $6.74
7	003309378	HANDBRAKE LH TIEROD	1 req	Avail to order Our Price: $25.92
8	008200607	D 6X1 SIN. 8G NUT	1 req	Avail to order Our Price: $13.23
9	413609206	HANDBRAKE TIEROD ADJUSTMENT	1 req	Avail to order Our Price: $80.80
10	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $0.40
11	003309379	RH HANDBRAKE TIEROD	1 req	Avail to order Our Price: $25.92
12	410609789	PIN	1 req	Avail to order Our Price: $37.54
13	003309423	HANDBRAKE BRACKET	1 req	Avail to order Our Price: $23.35
14	003309382	HANDBRAKE WIRE	1 req	Avail to order Our Price: $349.77
15	003309381	HANDBRAKE SHEATH SLEEVE	2 req	Avail to order Our Price: $307.06
16	008100505	SCREW M5X20 UNI 5739/5S	1 req	Avail to order Our Price: $0.57
17	003309426	HANDBRAKE WIRE RETAINING BAR	1 req	Avail to order Our Price: $11.18
18	008610601	GROMMET 6X10X1.5 MM	1 req	Avail to order Our Price: $6.04
19	003308994	HANDBRAKE WARNING LIGHT SWITCH	1 req	Avail to order Our Price: $38.22
20	008410502	WASHER D.5.3 UNI 1751/ZD	1 req	Current Stock: 33 Our Price: $0.09
21	003309380	HANDBRAKE SHEATH SLEEVE	2 req	Avail to order Our Price: $183.75
22	008100625	SCREW M6X16 UNI 5739/8G/Z	6 req	Avail to order Our Price: $124.18
23	008410603	WASHER D.6.4 UNI 1751/ZD	6 req	Avail to order Our Price: $0.09
24	003309392	HANDBRAKE INSPECTIONCOVER	1 req	Avail to order Our Price: $28.04
25	003309391	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
26	003309383	HANDBRAKE WIRE	1 req	Avail to order Our Price: $349.77
27	003309365	HANDBRAKE SHOE LH INNER UNIT	1 req	Avail to order Our Price: $1,452.28
28	003309364	HANDBRAKE SHOE RH INNER UNIT	1 req	Avail to order Our Price: $322.02
29	003309361	HANDBRAKE SHOE RETAINING PIN	2 req	Avail to order Our Price: $28.04
30	003309363	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
31	003309384	RH HANDBRAKE SHOE CONTROL UNIT	1 req	Avail to order Our Price: $103.81
32	003309385	LH HANDBRAKE SHOE CONTROL UNIT	1 req	Avail to order Our Price: $103.81
33	008573601	O-RING I 36 UNI 3654	2 req	Avail to order Our Price: $0.91
34	003309387	HANDBRAKE SHOE RUBBER WASHER	2 req	Avail to order Our Price: $52.79
35	008401305	WASHER 13X22X* C 72	0 req	Avail to order Our Price: $31.54
36	003309334	HANDBRAKE SHOE	2 req	Avail to order Our Price: $246.64
37	003309388	NLA (NO LONGER AVAILABLE)	4 req	*See Description
39	003309388	NLA (NO LONGER AVAILABLE)	2 req	*See Description
40	008200811	M8 UNI 5589/8G/ZDNUT	2 req	Avail to order Our Price: $6.02
41	008700814	SCREW D.8X25 UNI 2386 8G	2 req	Avail to order Our Price: $7.81
42	008573601	O-RING I 36 UNI 3654	2 req	Avail to order Our Price: $0.91
43	003309362	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
44	N0211963	HEX.HEAD CLAMPING	1 req	Avail to order Our Price: $0.90
45	003309652	HANDBRAKE WIRE LOCK PLATE	1 req	Avail to order Our Price: $11.18
46	003309478	HANDBRAKE SHOE LEVERPIN	2 req	Avail to order Our Price: $19.58
78	008101225	SPECIAL SCREW M12X25	4 req	Avail to order Our Price: $19.24
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
