2011 GALLARDO LP 550-2 COUPE - EUROPE

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $938.30
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $1,031.98

Common repairs and upgrades

PN	Item
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 8 Our Price: $61.26
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $75.82
0R1400313	LP560 AND LP570 SERVICE KIT 1 - AIR-CABIN-OIL FILTERS KIT SERVICE KIT 1 - 2 CABIN, 2 AIR AND 1 OIL FILTER INCLUDES: 1X 079198405E OIL FILTER 2X 420133844D AIR FILTER 1X 4F0898438C POLLEN FILTER 1X N0138322 COPPER WASHER 1X N0138486 COPPER WASHER	Avail to order Our Price: $399.23
0R1400314	GALLARDO 2009-2014 SERVICE KIT - AIR-CABIN-OIL FILTER +PLUGS+BELT KIT AIR-CABIN-OIL FILTER +PLUGS+BELT KIT KIT SERVICE 2 INCLUDES: 1X 079198405E OIL FILTER 2X 420133844D AIR FILTERS 1X 4F0898438C POLLEN FILTER 10X 06H905601A SPARK PLUGS 1X07L903137T ALTERNATOR BELT 1X N0138322 COPPER WASHER 1X N0138486 COPPER WASHER	Avail to order Our Price: $664.29
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
079198405E	OIL FILTER ENGINE ENGINE OIL FILTER GALLARDO LP SERIES AND HURACAN TECNICAS	Current Stock: 6 Our Price: $89.00
086301517	OIL FILTER GEARBOX OIL FILTER FOR GEARBOX	Current Stock: 2 Our Price: $141.07
N0138495	O-RING / WASHER O-RING	Current Stock: 47 Our Price: $3.45

Fuel-Air

PN	Item
420133844D	AIR FILTER GALLARDO LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Current Stock: 1 Our Price: $135.23
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $122.39
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $42.69
4F0201511E	FUEL FILTER - GALLARDO LP 560-4 FUEL FILTER - GALLARDO LP 560-4	Current Stock: 8 Our Price: $87.67
420133844DZ	PAIR HIGH FLOW K&N AIR FILTER GALLARDO LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $227.32
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $133.02

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.16

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $493.18
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $102.38
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL FOR INDIVIDUAL COILS SEE PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $480.17

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $447.76
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $10,988.32
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
7H0906271A-ALT	FUEL PUMP MODULE ASSEMBLY FUEL PUMP MODULE ASSEMBLY 7H0906271A FUEL VAPOR LEAK DETECTION PUMP THE FACTORY IS NO LONGER PROVIDING THE ORIGINAL ITEM. THIS IS A COMPATIBLE REPLACEMENT	Avail to order Our Price: $7,629.44

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $47.65
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $361.59
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62

Tools and Tookits

PN	Item
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237	Avail to order Our Price: $38.70
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL	Current Stock: 2 Our Price: $245.40
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 91 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 845.01.00 - WINDOWS

2011 Lamborghini GALLARDO LP 550-2 COUPE EUROPE WINDOWS (845.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	400831619B	GUIDE RAIL LH LH GUIDE	1 req	Current Stock: 1 Our Price: $624.53
1	400831620B	GUIDE RAIL RIGHT RH GUIDE	1 req	Current Stock: 1 Our Price: $624.53
2	400837461	LIFT BAR LH DOOR WINDOW ASSEMBLY LH POWER WINDOW ASSEMBLY	1 req	Avail to order Our Price: $1,031.11
2	400837462	LIFT BAR RH RIGHT DOOR POWER WINDOW ASSEMBLY	1 req	Avail to order Our Price: $1,031.11
3	400837933	WINDOW GUIDE SEAL BOTTOM,FRONT LH LH GASKET	1 req	Current Stock: 1 Our Price: $43.75
3	400837934	WINDOW GUIDE SEAL BOTTOM,FRONT RH RH GASKET	1 req	Current Stock: 1 Our Price: $43.75
4	400845115A	TRIANGLE WINDOW FIXED FRONT LEFT WINDOW GLASS	1 req	Avail to order Our Price: $799.88
4	400845116A	TRIANGLE WINDOW FIXED FRONT RIGHT WINDOW GLASS	1 req	Avail to order Our Price: $799.88
5	400845201A	DOOR WINDOW, FRONT LEFT DOOR WINDOW	1 req	Avail to order Our Price: $1,517.21
5	400845202A	RIGHT SIDE DOOR WINDOW - GALLARDO COUPE RIGHT DOOR WINDOW	1 req	Avail to order Our Price: $1,517.21
6	408845299C	SIDE WINDOW LH REAR WINDOW	1 req	Avail to order Our Price: $1,026.68
6	408845300C	SIDE WINDOW RH REAR WINDOW	1 req	Avail to order Our Price: $1,026.68
7	408845501A	REAR WINDOW GLASS REAR WINDOW	1 req	Avail to order Our Price: $1,402.26
8	400845099C	FRONT WINDOW WINDSCREEN	1 req	Avail to order Our Price: $5,590.01
9	401959801D	ZKE/DOOR MODULE/MOTOR/MIRROR/LOCK CONTROL-LEFT SIDE LEFT MOTOR (FOR GSX CARS)	1 req	Current Stock: 1 Our Price: $985.41
9	401959802D	ZKE/DOOR MODULE/MOTOR/MIRROR/LOCK CONTROL-RIGHT SIDE RIGHT MOTOR (FOR GSX CARS)	1 req	Avail to order Our Price: $1,035.53
10		PLATE (VALID UP TO MODEL YEAR 04)	0 req
11	8D0857511A	REAR VIEW MIRROR REAR VIEW MIRROR	1 req	Current Stock: 4 Our Price: $135.85
12	400837439	SEAL ROOF LH LH GUIDE	1 req	Avail to order Our Price: $402.15
12	400837440	SEAL ROOF RH RH GUIDE	1 req	Current Stock: 1 Our Price: $402.15
15	400853929A	CLAMP CLIP	2 req	Avail to order Our Price: $59.42
16	8N8853707	CLIPS CLIP	6 req	Avail to order Our Price: $2.56
17	N91019701	BLIND RIVET RIVET	24 req	Avail to order Our Price: $0.95
18	N90986803	FLANGE TAPPING SCREW ST4.2X13	8 req	Current Stock: 1 Our Price: $1.23
20	400853930A	SPRING CLIP	2 req	Avail to order Our Price: $59.42
21		ORNAMENT (VALID UP TO MODEL YEAR 05)	0 req
22	400845235	SPACER SPACER	14 req	Current Stock: 41 Our Price: $0.79
23	N02300212	HEX.NUT W/ FLANGE NUT M6	8 req	Avail to order Our Price: $0.36
24	WHT000127	FLANGE NUT NUT M8	2 req	Avail to order Our Price: $18.77
25	WHT003112	HEXAGON FLANGE NUT NUT M5	2 req	Current Stock: 7 Our Price: $0.83
26	N90944603	HEXALOBULAR SOCKET SCREW M5X12	2 req	Current Stock: 8 Our Price: $1.29
27	WHT000778	SPRING LOCK WASHER WASHER	2 req	Current Stock: 15 Our Price: $0.77
28	8Z0837691C	SCREW SCREW	6 req	Current Stock: 4 Our Price: $1.75
29		RUBBER SHIM (VALID FOR A DIFFERENT MODEL)	0 req
30	WHT001418A	FILLISTER HEAD BOLT SCREW M8X20	2 req	Current Stock: 16 Our Price: $2.30
31	8H0845233	FIXATION PART BRACKET	2 req	Current Stock: 1 Our Price: $6.02
32	8H0845481	PLATE LH BRACKET	2 req	Avail to order Our Price: $21.70
33	N90402503	HEXAGON FLANGE NUT NUT M6	2 req	Avail to order Our Price: $2.04
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
