2011 GALLARDO LP 550-2 COUPE - EUROPE

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $938.30
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $1,031.98

Common repairs and upgrades

PN	Item
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 8 Our Price: $61.26
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $75.82
0R1400313	LP560 AND LP570 SERVICE KIT 1 - AIR-CABIN-OIL FILTERS KIT SERVICE KIT 1 - 2 CABIN, 2 AIR AND 1 OIL FILTER INCLUDES: 1X 079198405E OIL FILTER 2X 420133844D AIR FILTER 1X 4F0898438C POLLEN FILTER 1X N0138322 COPPER WASHER 1X N0138486 COPPER WASHER	Avail to order Our Price: $399.23
0R1400314	GALLARDO 2009-2014 SERVICE KIT - AIR-CABIN-OIL FILTER +PLUGS+BELT KIT AIR-CABIN-OIL FILTER +PLUGS+BELT KIT KIT SERVICE 2 INCLUDES: 1X 079198405E OIL FILTER 2X 420133844D AIR FILTERS 1X 4F0898438C POLLEN FILTER 10X 06H905601A SPARK PLUGS 1X07L903137T ALTERNATOR BELT 1X N0138322 COPPER WASHER 1X N0138486 COPPER WASHER	Avail to order Our Price: $664.29
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
079198405E	OIL FILTER ENGINE ENGINE OIL FILTER GALLARDO LP SERIES AND HURACAN TECNICAS	Current Stock: 6 Our Price: $89.00
086301517	OIL FILTER GEARBOX OIL FILTER FOR GEARBOX	Current Stock: 2 Our Price: $141.07
N0138495	O-RING / WASHER O-RING	Current Stock: 47 Our Price: $3.45

Fuel-Air

PN	Item
420133844D	AIR FILTER GALLARDO LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Current Stock: 1 Our Price: $135.23
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $122.39
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $42.69
4F0201511E	FUEL FILTER - GALLARDO LP 560-4 FUEL FILTER - GALLARDO LP 560-4	Current Stock: 8 Our Price: $87.67
420133844DZ	PAIR HIGH FLOW K&N AIR FILTER GALLARDO LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $227.32
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $133.02

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.16

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $493.18
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $102.38
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL FOR INDIVIDUAL COILS SEE PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $480.17

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $447.76
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $10,988.32
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
7H0906271A-ALT	FUEL PUMP MODULE ASSEMBLY FUEL PUMP MODULE ASSEMBLY 7H0906271A FUEL VAPOR LEAK DETECTION PUMP THE FACTORY IS NO LONGER PROVIDING THE ORIGINAL ITEM. THIS IS A COMPATIBLE REPLACEMENT	Avail to order Our Price: $7,629.44

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $47.65
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $361.59
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62

Tools and Tookits

PN	Item
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237	Avail to order Our Price: $38.70
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL	Current Stock: 2 Our Price: $245.40
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 91 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 863.03.00 - REAR TUNNEL

2011 Lamborghini GALLARDO LP 550-2 COUPE EUROPE REAR TUNNEL (863.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	400863242B	CENTER CONSOLE CENTER TUNNEL ASSEMBLY (NON SMOKING VERSION - CUP HOLDER - LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $5,317.51
1	400863242E	CENTER CONSOLE CENTER TUNNEL ASSEMBLY (NON SMOKING VERSION - LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $1,797.06
1	401863242C	CENTER CONSOLE CENTER TUNNEL ASSEMBLY (CUP HOLDER - SMOKING VERSION - LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $5,884.56
1	401863242G	CENTER CONSOLE CENTER TUNNEL ASSEMBLY (WITHOUT CUP HOLDER - SMOKING VERSION - LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $5,884.56
1	403863242	CENTER CONSOLE CENTER TUNNEL ASSEMBLY	1 req	Avail to order Our Price: $11,614.58
1	403863242B	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT CENTER TUNNEL ASSEMBLY	1 req	*See Description
2	401863849	ASHTRAY FRAME ASHTRAY BEZEL	1 req	Avail to order Our Price: $486.11
2		ASHTRAY BEZEL (NOT FOR SUPERLEGGERA MODEL)	0 req
3	400863843	BRACKET LID FIXING BRACKET	1 req	Avail to order Our Price: $18.42
4	N10569501	HEXALOBULAR SOCKET SCREW M5X16	2 req	Avail to order Our Price: $2.39
5	400863615	BRACKET TUNNEL FIXING BRACKET, REAR	1 req	Avail to order Our Price: $18.06
6	N90847903	HEXAGON FLANGE SCREW M6X15	2 req	Current Stock: 6 Our Price: $1.38
7	N10569501	HEXALOBULAR SOCKET SCREW M5X16	2 req	Avail to order Our Price: $2.39
8	400863345	BRACKET TUNNEL FIXING BRACKET, CENTER	1 req	Avail to order Our Price: $17.71
9	N10569501	HEXALOBULAR SOCKET SCREW M5X16	8 req	Avail to order Our Price: $2.39
10	400863583	BRACKET TUNNEL FIXING BRACKET, FRONT LH	1 req	Avail to order Our Price: $11.34
11	400863584	BRACKET TUNNEL FIXING BRACKET, FRONT RH	1 req	Avail to order Our Price: $11.34
12	N10569501	HEXALOBULAR SOCKET SCREW M5X16	8 req	Avail to order Our Price: $2.39
13	N0902424	HEX. BOLT WITH SCREW M6X20	2 req	Current Stock: 16 Our Price: $0.99
14	N90688101	CABLE TIE BASE CLAMP	3 req	Current Stock: 9 Our Price: $0.99
15		CENTER CONSOLE REAR SECTION ASSY (VALID UP TO MODEL YEAR 05)	0 req
16		SCREW 4.2X9.5 (VALID UP TO MODEL YEAR 05)	0 req
17	400857405B	ASHTRAY ASHTRAY (DECORATIVE INSERTS - SUPPLY VIN)	1 req	Avail to order Our Price: $879.40
17	4B0857405B	ASHTRAY ASHTRAY	1 req	Avail to order 1 Used Available Our Price: $76.78
18	400863300A	TRAY GLOVE BOX (WITHOUT CUP HOLDER - SUPPLY VIN)	1 req	Avail to order Our Price: $133.90
18		GLOVE BOX (NOT FOR SUPERLEGGERA MODEL)	0 req
19	N90562401	SCREW SCREW	3 req	Current Stock: 10 Our Price: $1.94
19		SCREW (NOT FOR SUPERLEGGERA MODEL)	0 req
20	N91092001	RUBBER STOP RUBBER STOP 4.50X2.2X8.60	2 req	Avail to order Our Price: $1.20
20		RUBBER STOP 4.50X2.2X8.60 (NOT FOR SUPERLEGGERA MODEL)	0 req
21	8D0919343	SPRING SPIN 12V ELECTRIC CONNECTION	1 req	Avail to order Our Price: $13.10
22	4B0919305B	CIGAR LIGHTER 12V OUTLET WITH LIGHTER	1 req	Avail to order Our Price: $22.23
22	4B0919305B	CIGAR LIGHTER OUTLET 12V	1 req	Avail to order Our Price: $22.23
23	403863300B	TRAY GLOVE BOX	1 req	Avail to order Our Price: $4,249.56
23		GLOVE BOX (FOR SUPERLEGGERA MODEL)	0 req
24	400868563	CLIP CLIP	1 req	Avail to order Our Price: $0.93
24		CLIP (FOR SUPERLEGGERA MODEL)	0 req
25	400863284	TRAY ASSEMBLY,CENTR.CONS.REAR REAR CONSOLE GLOVE BOX ASSY (LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $1,605.60
25	400863284A	GALLARDO CARBON COVER CENTER CONSOLE REAR CONSOLE GLOVE BOX ASSY (CARBON INTERIOR)	1 req	Avail to order Our Price: $3,244.65
25		REAR CONSOLE GLOVE BOX ASSY (NOT FOR SUPERLEGGERA MODEL)	0 req
26	400863371	TRIM INNER COVER TRIM COVERING, INNER	1 req	Avail to order Our Price: $121.24
26		TRIM COVERING, INNER (NOT FOR SUPERLEGGERA MODEL)	0 req
27	N90562401	SCREW SCREW	6 req	Current Stock: 10 Our Price: $1.94
27		SCREW (NOT FOR SUPERLEGGERA MODEL)	0 req
28	N10569501	HEXALOBULAR SOCKET SCREW M5X16	2 req	Avail to order Our Price: $2.39
28		JOURNAL (NOT FOR SUPERLEGGERA MODEL)	0 req
29	400863285	SPRING LEFT SPRING	1 req	Avail to order Our Price: $40.03
29	400863286	SPRING RIGHT SPRING	1 req	Avail to order Our Price: $40.03
29		LEFT SPRING (NOT FOR SUPERLEGGERA MODEL)	0 req
29		RIGHT SPRING (NOT FOR SUPERLEGGERA MODEL)	0 req
30	N0211963	HEX.HEAD CLAMPING NUT M5	2 req	Avail to order Our Price: $0.90
30		SEAL RING (NOT FOR SUPERLEGGERA MODEL)	0 req
31	400863284G	TRAY COVER TUNNEL HOLDER (CUP HOLDER - LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $1,605.60
31		COVER TUNNEL HOLDER (NOT FOR SUPERLEGGERA MODEL)	0 req
32	400868563	CLIP CLIP	2 req	Avail to order Our Price: $0.93
32		CLIP (NOT FOR SUPERLEGGERA MODEL)	0 req
33	400711461	LINING HAND BRAKE ASS. HAND BRAKE COVERING ASSY WITH MOLDING (SUPPLY VIN)	1 req	Avail to order Our Price: $689.35
33	403711461	LINING,HAND BRAKE HAND BRAKE COVERING ASSY WITH MOLDING (ALCANTARA UPHOLSTERY - SUPPLY VIN)	1 req	Avail to order Our Price: $545.00
34	400863343E	COVER,HAND BRAKE HAND BRAKE LOWER PORTION CLOSING (SMALL LEATHER PACKAGE - SUPPLY VIN)	1 req	Avail to order Our Price: $81.30
34	400863343F	COVER HAND BRAKE HAND BRAKE LOWER PORTION CLOSING (CARBON INTERIOR)	1 req	Avail to order Our Price: $2,846.66
34	400863343G	COVER,HAND BRAKE HAND BRAKE LOWER PORTION CLOSING (LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $1,325.66
34	400863343H	COVER HAND BRAKE HAND BRAKE LOWER PORTION CLOSING (KLAVIERLACK INTERIOR)	1 req	Avail to order Our Price: $589.19
34	403863343	COVER,HAND BREAK HAND BRAKE LOWER PORTION CLOSING	1 req	Avail to order Our Price: $89.45
34	403863343B	COVER,HAND BRAKE HAND BRAKE LOWER PORTION CLOSING	1 req	Avail to order Our Price: $89.45
35	N90485901	WASHER WASHER	10 req	Avail to order Our Price: $15.32
36	N90562401	SCREW SCREW	10 req	Current Stock: 10 Our Price: $1.94
37	N90632303	SCREW SCREW 4.2X9.5 (CARBON INTERIOR)	2 req	Current Stock: 20 Our Price: $2.04
37	N90986803	FLANGE TAPPING SCREW 4.2X13.0 (WITH LEATHER UPHOLSTERY)	2 req	Current Stock: 1 Our Price: $1.23
38	WHT003110	HEXAGON SOCKET SCREW M4X10	1 req	Avail to order Our Price: $6.02
39	7M3919311	CAP PLUG (NON SMOKING VERSION)	1 req	Current Stock: 14 Our Price: $7.79
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
