1991-1993 Diablo 2WD - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item
001725107	ALTERNATOR/COOLANT PUMP BELT UP TO VIN 12582 ALTERNATOR/COOLANT PUMP BELT	Avail to order Our Price: $153.37
001731857	COOLANT PUMP ALTERNATOR BELT AFTER VIN 12583 COOLANT PUMP ALTERNATOR BELT	Current Stock: 1 Our Price: $110.22
004529536	COMPRESSOR BELT UNTIL COMPRESSOR BELT	Avail to order Our Price: $190.86

Brakes

PN	Item
003135292	BRAKE PADS FRONT - JALPA - EARLY DIABLO - PER ROTOR FRONT BRAKE PADS	Avail to order Our Price: $565.64
003235293	BRAKE PAD REAR -EARLY DIABLO - SOLD EACH REAR BRAKE PAD 1991-1993 DIABLO AND 1994 DIABLO SE	Avail to order Our Price: $1,134.43
003331672	EBRAKE PADS SET (1 PAIR) E BRAKE PADS SET (1 PAIR)	Avail to order Our Price: $228.45

Common repairs and upgrades

PN	Item
006329689	HIGH BEAM HEADLIGHT HIGH BEAM HEADLIGHT NLA FROM FACTORY PLEASE CONTACT US FOR CURRENT PRICE AND AVAILABILITY.	Avail to order Our Price: $483.83
0079004387	SHOCK ABSORBER SHOCK ABSORBER FOR ANTERIOR COWLING	Current Stock: 2 Our Price: $150.50
0092004388	SHOCK ABSORBER FOR ENGINE COWLING SHOCK ABSORBER FOR ENGINE COWLING	Current Stock: 4 Our Price: $228.45
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
002132598	CLUTCH MECHANISM - EARLY DIABLO CLUTCH MECHANISM NLA FROM FACTORY PLEASE CHECK WITH US FOR CURRENT PRICE, AVAILABILITY AND ALTERNATIVE OPTIONS	Avail to order Our Price: $1,511.84
002129353	THRUST SLEEVE THRUST SLEEVE - NLA FROM FACTORY PLEASE CHECK WITH US FOR CURRENT PRICE, AVAILABILITY AND ALTERNATIVE OPTIONS	Avail to order Our Price: $1,471.57
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $93.28
002132599	CLUTCH PRESSURE PLATE - DIABLO CLUTCH PLATE - NLA FROM FACTORY PLEASE CHECK WITH US FOR CURRENT PRICE, AVAILABILITY AND ALTERNATIVE OPTIONS	Avail to order Our Price: $1,850.00
002136948	SLAVE CLUTCH CYLINDER DIABLO / COUNTACH SLAVE CLUTCH CYLINDER	Current Stock: 1 Our Price: $144.85
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Current Stock: 1 Our Price: $378.11
001434600	OVERSIZE THRUST WASHER OVERSIZE THRUST WASHER	Avail to order Our Price: $83.14
001434601	OVERSIZED SHOULDER WASHER OVERSIZED SHOULDER WASHER	Avail to order Our Price: $83.14
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,720.09
0017002474	WATER PUMP (2WD WITH POWER STEERING) (1991-1994) COOLANT PUMP 2WD WITH	Current Stock: 1 Our Price: $6,577.25
002132599K	1991 - 1994 DIABLO CLUTCH DISK - KEVLAR HI-PERF 1991 - 1994 DIABLO CLUTCH DISK - KEVLAR HI-PERF - CLUTCHTEX - TZ-3022 T3	Avail to order Our Price: $707.92
005129802	FRONT SHOCK ABSORBER FRONT SHOCK ABSORBER	Current Stock: 4 Our Price: $1,248.19
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 10 Our Price: $201.60
0R1320001	NLA (NO LONGER AVAILABLE) SPEED SENSOR KIT	Avail to order Our Price: $1,014.26

Fuel-Air

PN	Item
07M133843	AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO PLEASE CHECK YOUR PART MANUAL FOR A DESCRIPTION FOR PERFORMANCE FILTERS SEE PN: 07M133843A	Current Stock: 14 Our Price: $28.63
400201511A	FUEL FILTER - DIABLO - GALLARDO - MURCIELAGO FUEL FILTER	Current Stock: 9 Our Price: $264.73
AMAIRD	HI-PERFORMANCE AFE AIR FILTER - DIABLO/MURCIELAGO - SPORT AIR FILTER MURCIELAGO - DIABLO AFTER MARKET AFE AIR FILTER 30-10133	Current Stock: 1 Our Price: $114.44
002024396	FUEL INJECTOR (SOLD EA) MANIFOLD UPPER COVERINJECTOR	Avail to order Our Price: $365.53
002024398	FUEL PUMP FUEL PUMP	Current Stock: 6 Our Price: $820.33
002027648R	PRESSURE REGULATOR VALVE OE SPEC PRESSURE REGULATOR VALVE	Avail to order Our Price: $215.19
07M133843A	AIR FILTER - SPORT PERFORMANCE FILTER PERFORMANCE FILTER REPLACEMENT FOR 07M133843 AIR FILTER - MURCIELAGO SV LP 670-4	Avail to order Our Price: $706.90
07M133843KN	K&N AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO K&N'S REPLACEMENT AIR FILTERS ARE DESIGNED TO INCREASE HORSEPOWER AND ACCELERATION WHILE PROVIDING EXCELLENT FILTRATION. THESE FILTERS ARE WASHABLE AND REUSABLE AND ARE CUSTOM DESIGNED TO FIT INTO YOUR EXISTING FACTORY AIR BOX. THEIR DROP-IN DESIGN MEANS ADDING PERFORMANCE IS SIMPLE.	Avail to order Our Price: $55.37

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $10.00
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.20
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $8.94
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.12
006329696	FRONT TURN SIGNAL BULB FRONT TURN SIGNAL BULB	Current Stock: 6 Our Price: $3.01
006329695	BULB FOR FOGLIGHT BULB FOR FOGLIGHT	Current Stock: 1 Our Price: $17.49
006329694	HEADLIGHT BULB HEADLIGHT BULB	Avail to order Our Price: $57.51
006311155	RELAY RELAY	Avail to order Our Price: $60.68
006311154	RELAY RELAY	Avail to order Our Price: $50.59
006030676	LIGHT RELAY LIGHT RELAY	Current Stock: 3 Our Price: $165.97
006329698	BULB BULB	Avail to order Our Price: $8.13
410947413	RED DOOR LIGHT RED DOOR LIGHT - NLA (NO LONGER AVAILABLE) TO ORDER FROM FACTORY PLEASE CONTACT US FOR OTHER OPTIONS. PRICING IS NOT UPDATED ONCE IT GOES TO NLA STATUS. CHECK FOR CURRRENT PRICE AND AVAILABILITY	Avail to order Our Price: $91.93

Gaskets

PN	Item	Diagram
001532102	GROMMET AND OIL SEALS SET - DIABLO 1991-1996 GROMMET AND OIL SEALS SET - DIABLO 1991-1996		Avail to order Our Price: $237.95
0R1320002	DIABLO REAR DIFFERENTIAL SEAL KIT DIF SEAL KIT		Current Stock: 1 Our Price: $43.77

Ignition

PN	Item
001630289	SPARK PLUG - DIABLO SPARK PLUG	Current Stock: 38 Our Price: $29.61
DiabloWireSet	SPARK PLUG WIRES 1991-1995 DIABLO - AFTERMARKET SPARK PLUG WIRES 1991 THROUGH 1995 ONLY FOR SYSTEMS USING A DISTRIBUTOR CAP	Avail to order Our Price: $644.69
001627728	DISTRIBUTOR CAP 1991-1995 DIABLO CAP DISTRIBUTOR CAP 1991 - 1995 NO LONGER AVAILABLE TO ORDER FROM FACTORY THIS IS OE SPEC OPTION	Current Stock: 3 Our Price: $590.00
006134023	SPARK PLUG WIRES SPARK PLUG WIRES ONLY FOR SYSTEMS USING DISTRIBUTOR CAP. NLA (NO LONGER AVAILABLE) FROM LAMBORGHINI PLEASE CHECK CURRENT PRICE AND AVAILABILITY AS PRICING IS NOT UPDATED ON NLA PARTS DEPENDING ON PRODUCTION YEAR MAY REQUIRE DIFFERENT SET: SEE PN: 006134279 & 001134281	Avail to order Our Price: $583.96
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA FOR FACTORY WE HAVE EXACT OE REPLACEMENT	Current Stock: 1 Our Price: $289.00
001630792N	COIL PACK OE SPEC REPLACEMENT COIL PACK OE SPEC REPLACEMENT	Avail to order Our Price: $1,538.13

Misc

PN	Item
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.53
009420126	WINDSHIELD WIPER BLADE WINDSHIELD WIPER BLADE	Current Stock: 1 Our Price: $32.87
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39

Sensors

PN	Item
001327641	POTENTIOMETER TPS THROTTLE POSITION SENSOR DIABLO POTENTIOMETER TPS THROTTLE POSITION SENSOR DIABLO	Avail to order Our Price: $180.12
004526663	CABIN AIR TEMPERATURE SENSOR TEMPERATURE SENSOR	Avail to order Our Price: $2,115.02
07M919529	ENGINE AIR TEMPERATURE SENSOR ENGINE AIR TEMPERATURE SENSOR	Avail to order Our Price: $304.91
001536755	OIL TEMPERATURE THERMOSTAT OIL TEMPERATURE THERMOSTAT - ALSO USED ON DIABLO 91-93 2WD AND 94	Current Stock: 1 Our Price: $490.50
0017006576	THERMOSTAT FOR DIABLO OE APPROVED REPLACEMENT WATER THERMOSTAT - -NLA (NO LONGER AVAILABLE) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES. WE HAVE APPROVED THERMOSTAT FOR SALE	Current Stock: 3 Our Price: $99.99
001724565	FAN MOTOR THERMAL CONTACT FAN MOTOR THERMAL CONTACT	Avail to order Our Price: $263.59
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $123.23
07L919501A	WATER TEMPERATURE SENSOR WATER TEMPERATURE SENSOR	Current Stock: 3 Our Price: $371.24
07M905381	PHASE SENSOR PHASE SENSOR	Avail to order Our Price: $751.44
0R1470226	LAMBDA (O2 OXYGEN) SENSOR - DIABLO - EARLY MURCIELAGO LAMBDA (O2 OXYGEN) SENSOR - DIABLO - EARLY MURCIELAGO	Current Stock: 9 Our Price: $220.65

Tools and Tookits

PN	Item	Diagram
004129973	DIABLO FRONT TOW HITCH ASSEMBLY DIABLO FRONT TOW HITCH ASSEMBLY		Avail to order Our Price: $1,377.52
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 16.01.00 - Ignition Distributor and Phase Sensors

1991-1993 Lamborghini Diablo 2WD USA Ignition Distributor and Phase Sensors (16.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001625447	SPARK DISTRIBUTION DRIVE	1 req	Avail to order Our Price: $277.51
2	008573202	O-RING I 30 UNI 3654	2 req	Avail to order Our Price: $5.85
3	008611604	OIL SEAL	1 req	Current Stock: 13 Our Price: $27.45
4	001625446	SPARK DISTRIBUTOR CAP RADIAL BEARING GENUINE	1 req	Avail to order Our Price: $203.63
5	008604601	O-RING	1 req	Current Stock: 3 Our Price: $2.76
6	001625303	DISTRIBUTOR CAP BRACKET	1 req	Avail to order Our Price: $892.32
7	001629805	SHEET	1 req	Avail to order Our Price: $27.25
8	008100506	SCREW M5X14 UNI 5739	1 req	Avail to order Our Price: $10.73
9	001627730	DIABLO IGNITION ROTOR	1 req	Current Stock: 1 2 Used Available Our Price: $289.00
10	008850201	PIN UNI 1707H11 Z.5X8	1 req	Avail to order Our Price: $46.85
11	001627729	DISTRIBUTOR SEAL	1 req	Current Stock: 2 Our Price: $16.11
12	001627728	DISTRIBUTOR CAP 1991-1995 DIABLO	1 req	Current Stock: 3 Our Price: $590.00
13	001625445	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
14	008100508	SCREW M5X10 UNI 5739/5S/Z	2 req	Avail to order Our Price: $6.10
15	008410502	WASHER	2 req	Current Stock: 33 Our Price: $0.10
16	008200509	This item is no longer available	1 req
17	008410503	WASHER DIN 137A 5.3X10 ZGD.	2 req	Avail to order Our Price: $0.20
18	008400507	This item is no longer available	1 req
19	008573202	O-RING I 30 UNI 3654	1 req	Avail to order Our Price: $5.85
20	001624409	P.T.O. SLEEVE	1 req	Avail to order Our Price: $310.85
21	001629249	PHONIC WHEEL SHAFT	1 req	Avail to order Our Price: $432.73
22	008860301	KEY 3X5X13	1 req	Avail to order Our Price: $1.30
23	07M109381	O-RING SEAL RING	1 req	Current Stock: 26 Our Price: $1.77
24	410109264	BEARING	2 req	Current Stock: 9 Our Price: $30.02
25	001629776	PICK-UP BRACKET	1 req	Avail to order Our Price: $598.05
26	001632285	TDC SENSOR BRUSH	1 req	Avail to order Our Price: $374.97
27	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $1.90
28	008200819	8X1X8.5 UNI 7474/5S/ZCNU	1 req	Avail to order Our Price: $6.10
29	001629246	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
30	008700501	SCREW M5X10 UNI 5933/12K/F	2 req	Current Stock: 3 Our Price: $2.84
31	008700608	SCREW 6X40 UNI 5931/8G/Z	4 req	Avail to order Our Price: $0.70
32	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $0.30
33	WHT002963	SPRING LOCK WASHER	4 req	Current Stock: 26 Our Price: $0.20
34	07M905381	PHASE SENSOR	2 req	Avail to order Our Price: $751.44
35	001628404	PEG	1 req	Avail to order Our Price: $2.76
36	N10648502	HEXALOBULAR SOCKET	4 req	Avail to order Our Price: $1.60
37	008410502	WASHER	4 req	Current Stock: 33 Our Price: $0.10
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
