TAV: 24.03.01 - Gearbox

1991-1993 Lamborghini Diablo 2WD USA Gearbox (24.03.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002431479	Gearbox Fixed Part Front Mount	1 req	Avail to order Our Price: $524.80
2	N01100637	HEX.NUT	6 req	Current Stock: 18 Our Price: $2.00
3	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
4	002425638	Gearbox Cover	1 req	Avail to order Our Price: $73.95
5	008300602	Stud	6 req	Avail to order Our Price: $7.75
6	86311621	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
7	008611605	Oil Seal 16x24x5 mm	1 req	Avail to order Our Price: $18.56
8	002424900	Gearbox Upper Cover	1 req	Avail to order Our Price: $642.58
9	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $46.98
10	008300862	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
11	008100604	Screw M6x14 Uni 5739/5s/Z	4 req	Avail to order Our Price: $2.91
12	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
13	002428645	Gearbox Breather Cover	1 req	Current Stock: 1 Our Price: $148.20
14	002428643	Breather Pipe	4 req	Avail to order Our Price: $24.15
15	008830204	Clamp	1 req	Avail to order Our Price: $10.06
16	86301472	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
17	008200806	M8 Uni 5588/8g/Z Nut	10 req	Current Stock: 25 Our Price: $2.00
18	WHT001514	SPRING WASHER	10 req	Current Stock: 9 Our Price: $26.80
19	008300825	Stud M8x22 Uni 5911 10k Z	9 req	Avail to order Our Price: $15.26
20	008100826	Screw M8x16 Uni 5739/8g/Z	1 req	Avail to order Our Price: $2.00
21	008400802	Copper Washer 8.4x16x1.5	1 req	Avail to order Our Price: $2.00
22	002425223	Dowel	2 req	Avail to order Our Price: $32.65
23	002425224	Central Rod Strut	1 req	Current Stock: 1 Our Price: $33.55
24	WHT001514	SPRING WASHER	12 req	Current Stock: 9 Our Price: $26.80
25	008200806	M8 Uni 5588/8g/Z Nut	12 req	Current Stock: 25 Our Price: $2.00
26	008300894	Stud M8x25 Uni 5914 8g	2 req	Avail to order Our Price: $45.55
27	008300889	Special Stud M8x122	1 req	Avail to order Our Price: $33.77
28	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $46.98
29	008300892	Stud M8x50 Uni 5914 8g	7 req	Avail to order Our Price: $40.03
30	008300896	Stud M8x100 Uni 59148g	1 req	Avail to order Our Price: $28.89
31	008300895	Stud M8x65 Uni 5914 8g	1 req	Avail to order Our Price: $9.39
32	086301141A	Magnetic Plug 22x1.5	1 req	Avail to order Our Price: $39.91
33	002428586	Gearbox Side Cover	1 req	Avail to order Our Price: $1,355.24
34	WHT001197A	WASHER	11 req	Current Stock: 2 Our Price: $2.00
35	N10546402	HEXALOBULAR SOCKET	11 req	Current Stock: 5 Our Price: $2.00
36	01S409965	PLUG	1 req	Current Stock: 5 Our Price: $188.34
37	410813761A	REINF.PLATE	5 req	Current Stock: 5 Our Price: $46.98
38	008101430	Screw 14x2x80uni57378g Zg	2 req	Current Stock: 3 Our Price: $4.10
39	N01033520	HEXAGON HEAD BOLT	4 req	Current Stock: 6 Our Price: $2.00
40	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
41	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	4 req	Current Stock: 5 Our Price: $2.00
42	004131478	Gearbox Front Mount	1 req	Avail to order Our Price: $445.90
43	WHT003614	This item is no longer available	4 req
44	004130884	Mobile Gearbox FrontMount Shim	4 req	Avail to order Our Price: $49.43
45	0B9501144	SILENTBLOC	2 req	Avail to order Our Price: $262.02
46	002429421	Gearbox	1 req	Avail to order Our Price: $4,800.73
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
