TAV: 18.03.01 - Oil Sump

1991-1993 Lamborghini Diablo 2WD USA Oil Sump (18.03.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001831041	NLA (No Longer Available)	1 req	*See Description
2	WHT003057	O-RING	1 req	Current Stock: 11 Our Price: $2.00
3	001831138	Oil Dipstick Pipe Assembly	1 req	Avail to order Our Price: $727.57
4	008300839	Stud M8x28 Uni 5911 8g Z	8 req	Avail to order Our Price: $8.18
4	008300806	Stud M8x70 Uni 5911 9g Z	6 req	Avail to order Our Price: $6.49
4	008300897	Stud M8x106 8g	4 req	Avail to order Our Price: $17.38
5	WHT001514	SPRING WASHER	18 req	Current Stock: 9 Our Price: $26.80
6	N01100845	HEX.NUT	18 req	Current Stock: 17 Our Price: $2.09
7	N01118312	HEX.HEAD CLAMPING NUT	3 req	Avail to order Our Price: $2.17
8	N01152427	WASHER	3 req	Current Stock: 16 Our Price: $2.00
9	001830006	Oil Dipstick Pipe Seal	1 req	Avail to order Our Price: $8.33
10	008300601	Stud M6x20 Uni 5911/8g/Zd	3 req	Current Stock: 5 Our Price: $9.16
11	WHT003078	Reference Pin 8h7x16C40	1 req	Avail to order Our Price: $46.98
12	001826521	Oil Sump Cover Seal	1 req	Avail to order Our Price: $145.07
13	001831852	NLA (No Longer Available)	1 req	*See Description
14	008300615	Stud 6x22 Uni 5911/8g/Z	20 req	Avail to order Our Price: $23.56
15	WHT001197A	WASHER	20 req	Current Stock: 2 Our Price: $2.00
16	008200605	Simmon Nut for urama	20 req	Current Stock: 50 Our Price: $3.06
17	WHT002222	O-RING	1 req	Current Stock: 9 Our Price: $14.15
18	001832017	Oil Sump Intake Terminal	1 req	Avail to order Our Price: $381.68
19	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
20	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
21	008100604	Screw M6x14 Uni 5739/5s/Z	4 req	Avail to order Our Price: $2.91
22	008402207	Annealed Copper Washer 22.1x2x	1 req	Current Stock: 31 Our Price: $11.53
23	008932211	Plug Din 908 M22x1.5/Z	1 req	Avail to order Our Price: $25.76
24	008100604	Screw M6x14 Uni 5739/5s/Z	8 req	Avail to order Our Price: $2.91
25	008410603	Washer D.6.4 Uni 1751/Zd	8 req	Avail to order Our Price: $2.00
26	001827775	Oil Sump Bulkhead	1 req	Avail to order Our Price: $99.75
27	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $46.98
28	086301047D	Breather pipe	1 req	Avail to order Our Price: $15.49
29	001825337	This item is no longer available	1 req
29	450132002	Machined oil sump/rearDiff	1 req	Avail to order Our Price: $11,181.80
30	008301033	Zinc Special Stud 10x70	8 req	Avail to order Our Price: $42.57
30	008301002	Stud M10x75 Uni 59118gz	2 req	Avail to order Our Price: $38.55
31	WHT000768	SPRING WASHER	10 req	Current Stock: 17 Our Price: $2.09
32	N10155210	HEX.NUT	10 req	Current Stock: 38 Our Price: $2.17
33	001825336	No Description - Please Check your book	1 req	Avail to order Our Price: $787.21
34	410971250	Engine/Chassis/Exhaust Pipe Ea	2 req	Avail to order Our Price: $72.58
35	086301141A	Magnetic Plug 22x1.5	2 req	Avail to order Our Price: $39.91
36	01S409965	PLUG	1 req	Current Stock: 5 Our Price: $188.34
37	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $46.98
38	008101430	Screw 14x2x80uni57378g Zg	1 req	Current Stock: 3 Our Price: $4.10
39	004126765	Rear Differential Frame Mount	2 req	Avail to order Our Price: $319.80
40	0B9501144	SILENTBLOC	1 req	Avail to order Our Price: $262.02
41	WHT003614	This item is no longer available	1 req
42	410813761A	REINF.PLATE	1 req	Current Stock: 5 Our Price: $46.98
43	N01024230	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $2.00
44	008410801	Check Washer	4 req	Current Stock: 16 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
