1991-1993 Lamborghini Diablo 2WD USA Fuel System 3 (62.02.00)

Maintenance Parts:

Belts

PN	Item
001725107	Alternator/Coolant Pump Belt UP TO VIN 12582 Alternator/Coolant Pump Belt	Avail to order Our Price: $138.08
001731857	Coolant Pump Alternator Belt after VIN 12583 Coolant Pump Alternator Belt	Avail to order Our Price: $118.68
004529536	Compressor Belt Until Compressor Belt	Avail to order Our Price: $205.00

Brakes

PN	Item
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads	Avail to order Our Price: $509.81
003235293	Brake Pad Rear -Early Diablo - Sold Each Rear Brake Pad 1991-1993 Diablo and 1994 Diablo SE	Avail to order Our Price: $207.35
003331672	Ebrake Pads Set (1 pair) E Brake Pads Set (1 pair)	Avail to order Our Price: $196.80

Drivetrain

PN	Item
002132598	Clutch Mechanism - Early Diablo Clutch Mechanism	Avail to order Our Price: $1,625.09
002129353	Thrust Sleeve Throw out bearing Thrust Sleeve	Avail to order Our Price: $1,580.36
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $83.98
002132599	NLA (No Longer Available) Clutch Plate	Avail to order Our Price: $3,712.36
002136948	Slave Clutch Cylinder Diablo // Countach Slave Clutch Cylinder	Avail to order Our Price: $130.36
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $341.11
0017002473	Water Pump (2WD w/o Power Stearing) (1991-1994) Coolant Pump 2WD W/o	Avail to order Our Price: $5,150.06
0017002474	Water Pump (2WD With Power Steering) (1991-1994) Coolant Pump 2WD With	Current Stock: 1 Our Price: $5,922.94
0R1320001	NLA (No Longer Available) SPEED SENSOR KIT	Avail to order Our Price: $912.59
002132599K	1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF 1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF - Clutchtex - TZ-3022 T3	Current Stock: 1 Our Price: $900.97
001434601	Oversized Shoulder Washer Oversized Shoulder Washer	Avail to order Our Price: $74.77
001434600	Oversize Thrust Washer Oversize Thrust Washer	Avail to order Our Price: $74.77
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 2 Our Price: $50.22

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 1 Our Price: $30.73
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $284.18
AMAIRD	Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT Air Filter Murcielago - Diablo After Market aFe Air Filter 30-10133	Current Stock: 1 Our Price: $145.65
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $393.61
002024398	Fuel Pump Fuel Pump	Current Stock: 1 Our Price: $738.70
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $273.87
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $70.48
400201511AZ	OE Spec Aftermarket Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $91.69
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $758.80

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.71
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $13.10
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.60
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.09
006329696	Bulb 5w Front Turn Signal 5w Bulb front turn signal	Current Stock: 6 Our Price: $3.21
006329695	Bulb foglight Bulb foglight	Current Stock: 1 Our Price: $18.79
006329694	Bulb Headlight Bulb headlight	Avail to order Our Price: $61.95
006311155	Relay Relay	Avail to order Our Price: $65.38
006311154	Relay Relay	Avail to order Our Price: $54.49
006030676	Light Relay Light Relay	Current Stock: 3 Our Price: $178.17
006329698	Bulb Bulb	Avail to order Our Price: $8.80

Gaskets

PN	Item	Diagram
001532102	Grommet and Oil Seals Set - Diablo 1991-1996 Diablo Grommet and oil seals Set Diablo 1991-1996		Avail to order Our Price: $214.03
0R1320002	Diablo REAR Differential Seal Kit Dif Seal Kit		Current Stock: 1 Our Price: $47.11

Ignition

PN	Item
001630289	Spark Plug - Diablo Spark Plug Champion A59GC	Avail to order Our Price: $31.91
DiabloWireSet	Spark Plug Wires 1991-1995 Diablo - Aftermarket Spark Plug Wires 1991 through 1995 ONLY for systems using a Distributor cap	Avail to order Our Price: $820.50
001627728	NLA (No Longer Available) Cap Distributor Cap 1991 - 1993 SEE PN 001627728N for OE SPEC OPTION	Avail to order Our Price: $1,523.47
006134023	NLA (No Longer Available) Spark Plug Wires ONLY for systems using distributor cap. Depending on production year may require different set: SEE PN: 006134279 & 001134281	Avail to order Our Price: $743.20
001627730	NLA (No Longer Available) Rotor	Avail to order Our Price: $1,902.48
001627728N	OE SPEC Distributor Cap Diablo 1991 - 1993 & Countach OE SPEC Aftermarket option can be used on Countach and 91-93 Diablo For Countach Applications: On the 2-valve engine you use the center coil terminal. There is no need to cap or plug the second terminal as it does nothing. On the 4-valve engine connect the two coils as you would on the Countach cap to both the center and the offset coil terminals.	Avail to order Our Price: $684.42
001627730R	Rotor Brush 1991 - 1994 Diablos OE Spec - Rotating Brush	Avail to order Our Price: $319.40
001630792N	Coil pack OE SPEC REPLACEMENT Coil pack OE SPEC REPLACEMENT	Avail to order Our Price: $1,957.58

Misc

PN	Item
009420126	Windshield Wiper Blade Windshield Wiper Blade	Avail to order Our Price: $35.41
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
001327641	Potentiometer TPS Throttle Position Sensor Diablos Potentiometer	Avail to order Our Price: $193.82
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $262.34
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Current Stock: 1 Our Price: $298.50
001536755	Oil Temperature Thermostat Oil Temperature Snsor also used on Diablo 91-93 2wd and 94	Current Stock: 1 Our Price: $529.28
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $364.01
0017006576	NLA (No Longer Available) WATER THERMOSTAT	Avail to order Our Price: $524.67
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $676.27
002408637	Reverse Switch Switch	Avail to order Our Price: $132.69
004429307	SEE PN 0R1470226 Lambda Sensor	Avail to order Our Price: $420.63
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $237.07

Open All

Select Group and TAV

< Previous Next >

TAV: 62.02.00 - Fuel System 3

1991-1993 Lamborghini Diablo 2WD USA Fuel System 3 (62.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	410201449	Fuel Filter Seal Clamp	1 req	Avail to order Our Price: $53.60
2	410201349	Aerstop Fa Cn/20	1 req	Avail to order Our Price: $34.25
3	N01118312	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 4 Our Price: $2.09
4	WHT002961	WASHER	2 req	Current Stock: 39 Our Price: $0.41
5	400201149B	NIPPLE	2 req	Avail to order Our Price: $120.15
6	008603703	Or Ring	2 req	Current Stock: 1 Our Price: $23.56
7	005122740	Union	2 req	Avail to order Our Price: $99.30
8	006227630	Union	2 req	Avail to order Our Price: $14.49
9	008830902	NLA (No Longer Available)	2 req	*See Description
10	006231554	Fuel Filter Pipe Set 7-12	1 req	Avail to order Our Price: $146.55
10	006231552	Fuel Filter Pipe Set 1-6	1 req	Avail to order Our Price: $249.71
11	400201511A	Fuel Filter - Diablo - Gallardo - Murcielago	2 req	Avail to order Our Price: $284.18
12	410201196	Aerstop Fa Cn/20	1 req	Current Stock: 4 Our Price: $5.21
13	006230218	Pump/Fuel Filter Pipe	2 req	Avail to order Our Price: $56.66
14	008831117	Clamp	2 req	Avail to order Our Price: $8.47
15	006130194	Fuel Pump Wiring	1 req	Current Stock: 3 Our Price: $47.27
16	WHT003167	TAP END STUD	2 req	Current Stock: 1 Our Price: $10.94
17	001701495	Supplementary Reservoir Bracket	2 req	Current Stock: 1 Our Price: $56.71
18	001701592	Radiator Shim	2 req	Avail to order Our Price: $20.14
19	WHT001189	RUBBER WASHER MOUNT	2 req	Avail to order Our Price: $4.10
20	WHT001942	WASHER	2 req	Current Stock: 13 Our Price: $3.43
21	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.31
22	006229532	Fuel Pump Tank Clip	1 req	Avail to order Our Price: $52.33
23	006226900	Fuel Pump Rubber Band	2 req	Avail to order Our Price: $25.86
24	006229533	Fuel Pump Tank Clip	8 req	Current Stock: 1 Our Price: $68.96
25	002024398	Fuel Pump	2 req	Current Stock: 1 Our Price: $738.70
26	008831320	Clamp	2 req	Avail to order Our Price: $3.58
27	006230225	Additional Fuel Filter/Pump Pi	2 req	Avail to order Our Price: $21.70
28	006229221	NLA (No Longer Available)	2 req	*See Description
29	006230226	NLA (No Longer Available) LIMITED STOCK	2 req	*See Description
30	006230175	Fuel Priming Pipe Set	2 req	Avail to order Our Price: $417.46
31	008402007	Annealed Copper Washer D.21x27	2 req	Current Stock: 8 Our Price: $0.64
32	006229580	FILTER - READ DESCRIPTION	2 req	Current Stock: 2 Our Price: $1,215.57
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
