1991-1993 Lamborghini Diablo 2WD USA Differential (23.01.01)

Maintenance Parts:

Belts

PN	Item
001725107	Alternator/Coolant Pump Belt UP TO VIN 12582 Alternator/Coolant Pump Belt	Avail to order Our Price: $134.52
001731857	Coolant Pump Alternator Belt after VIN 12583 Coolant Pump Alternator Belt	Avail to order Our Price: $113.80
004529536	Compressor Belt Until Compressor Belt	Avail to order Our Price: $196.57

Brakes

PN	Item
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads	Avail to order Our Price: $496.66
003235293	Brake Pad Rear -Early Diablo - Sold Each Rear Brake Pad 1991-1993 Diablo and 1994 Diablo SE	Avail to order Our Price: $202.00
003331672	Ebrake Pads Set (1 pair) E Brake Pads Set (1 pair)	Avail to order Our Price: $188.71

Drivetrain

PN	Item
002132598	Clutch Mechanism - Early Diablo Clutch Mechanism	Avail to order Our Price: $1,558.25
002129353	Thrust Sleeve Throw out bearing Thrust Sleeve	Avail to order Our Price: $1,515.36
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $81.81
002132599	NLA (No Longer Available) Clutch Plate	Avail to order Our Price: $3,559.65
001434600	Oversize Thrust Washer Oversize Thrust Washer	Avail to order Our Price: $72.84
001434601	Oversized Shoulder Washer Oversized Shoulder Washer	Avail to order Our Price: $72.84
0017002473	Water Pump (2WD w/o Power Stearing) (1991-1994) Coolant Pump 2WD W/o	Avail to order Our Price: $5,017.25
0017002474	Water Pump (2WD With Power Steering) (1991-1994) Coolant Pump 2WD With	Current Stock: 1 Our Price: $5,770.19
002132599K	1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF 1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF - Clutchtex - TZ-3022 T3	Current Stock: 1 Our Price: $868.50
002136948	Slave Clutch Cylinder Diablo // Countach Slave Clutch Cylinder	Avail to order Our Price: $126.99
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $332.32
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 2 Our Price: $48.56
0R1320001	NLA (No Longer Available) SPEED SENSOR KIT	Avail to order Our Price: $889.06

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 1 Our Price: $29.72
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $274.81
AMAIRD	Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT Air Filter Murcielago - Diablo After Market aFe Air Filter 30-10133	Current Stock: 1 Our Price: $140.40
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $377.42
002024398	Fuel Pump Fuel Pump	Current Stock: 1 Our Price: $719.65
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $264.00
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $733.78
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $67.93
400201511AZ	OE Spec Aftermarket Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $88.39

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.36
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $12.67
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
006329696	Bulb 5w Front Turn Signal 5w Bulb front turn signal	Current Stock: 6 Our Price: $3.08
006329695	Bulb foglight Bulb foglight	Current Stock: 1 Our Price: $18.01
006329694	Bulb Headlight Bulb headlight	Avail to order Our Price: $59.40
006311155	Relay Relay	Avail to order Our Price: $62.69
006311154	Relay Relay	Avail to order Our Price: $52.25
006030676	Light Relay Light Relay	Current Stock: 3 Our Price: $170.84
006329698	Bulb Bulb	Avail to order Our Price: $8.44

Gaskets

PN	Item	Diagram
001532102	Grommet and Oil Seals Set - Diablo 1991-1996 Diablo Grommet and oil seals Set Diablo 1991-1996		Avail to order Our Price: $208.51
0R1320002	Diablo REAR Differential Seal Kit Dif Seal Kit		Current Stock: 1 Our Price: $45.17

Ignition

PN	Item
001630289	Spark Plug - Diablo Spark Plug Champion A59GC	Avail to order Our Price: $30.60
DiabloWireSet	Spark Plug Wires 1991-1995 Diablo - Aftermarket Spark Plug Wires 1991 through 1995 ONLY for systems using a Distributor cap	Avail to order Our Price: $790.92
001627728	NLA (No Longer Available) Cap Distributor Cap 1991 - 1993 SEE PN 001627728N for OE SPEC OPTION	Avail to order Our Price: $1,484.18
006134023	NLA (No Longer Available) Spark Plug Wires ONLY for systems using distributor cap. Depending on production year may require different set: SEE PN: 006134279 & 001134281	Avail to order Our Price: $716.41
001627728N	OE SPEC Distributor Cap Diablo 1991 - 1993 & Countach OE SPEC Aftermarket option can be used on Countach and 91-93 Diablo For Countach Applications: On the 2-valve engine you use the center coil terminal. There is no need to cap or plug the second terminal as it does nothing. On the 4-valve engine connect the two coils as you would on the Countach cap to both the center and the offset coil terminals.	Avail to order Our Price: $659.75
001627730	NLA (No Longer Available) Rotor	Avail to order Our Price: $1,853.41
001627730R	Rotor Brush 1991 - 1994 Diablos OE Spec - Rotating Brush	Avail to order Our Price: $307.89
001630792N	Coil pack OE SPEC REPLACEMENT Coil pack OE SPEC REPLACEMENT	Avail to order Our Price: $1,887.02

Misc

PN	Item
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
009420126	Windshield Wiper Blade Windshield Wiper Blade	Avail to order Our Price: $33.96
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item
001327641	Potentiometer TPS Throttle Position Sensor Diablos Potentiometer	Avail to order Our Price: $185.85
001536755	Oil Temperature Thermostat Oil Temperature Snsor also used on Diablo 91-93 2wd and 94	Current Stock: 1 Our Price: $507.51
0017006576	NLA (No Longer Available) WATER THERMOSTAT	Avail to order Our Price: $511.14
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $230.95
002408637	Reverse Switch Switch	Avail to order Our Price: $127.24
004429307	SEE PN 0R1470226 Lambda Sensor	Avail to order Our Price: $409.78
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $255.57
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $350.89
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $658.83
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Current Stock: 1 Our Price: $287.75

Open All

Select Group and TAV

< Previous Next >

TAV: 23.01.01 - Differential

1991-1993 Lamborghini Diablo 2WD USA Differential (23.01.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008575501	O-Ring I 55 Uni 3654	2 req	Current Stock: 9 Our Price: $2.00
2	410103520	Bearing	1 req	Avail to order Our Price: $70.18
3	002331406	Rear Differential Propeller Sh	1 req	Avail to order Our Price: $3,105.91
4	008613510	Ring 35x55x10 mm	1 req	Current Stock: 1 Our Price: $50.26
5	008503010	Bearing	1 req	Avail to order Our Price: $23.66
6	002324939	Spacer	1 req	Current Stock: 14 Our Price: $42.14
7	002324938	Sleeve	1 req	Avail to order Our Price: $760.19
8	008410815	Washer 8.4x15x0.5 Din137/B C70	4 req	Current Stock: 28 Our Price: $2.00
9	002330693	Rear Differential Adjustment S	1 req	Current Stock: 12 Our Price: $26.67
9	002330694	Rear Differential Adjustment S	1 req	Current Stock: 7 Our Price: $38.52
9	002330695	Rear Differential Adjustment S	1 req	Current Stock: 11 Our Price: $38.52
9	002330696	Rear Differential Adjustment S	1 req	Current Stock: 9 Our Price: $38.52
9	002330697	SPES.REGOL.DIFF.POST.0,15	1 req	Current Stock: 14 Our Price: $26.67
10	002328764	Shim	1 req	Avail to order Our Price: $67.48
11	008100803	SEE PN N01024230	4 req	Avail to order Our Price: $2.00
12	008545004	Bearing	2 req	Avail to order Our Price: $146.25
13	002334682	Bevel Gear	1 req	Avail to order Our Price: $5,205.48
14	002325117	Fifth wheel	2 req	Avail to order Our Price: $90.07
15	008545002	Taper Roller Bearing50x88x22	2 req	Avail to order Our Price: $498.93
16	002324942	DISCONTINUED - NLA - LIMITED QTY AVAILABLE	1 req	*See Description
17	002324452	Flange	1 req	Avail to order Our Price: $275.92
18	008301022	Special Stud M10x28	6 req	Avail to order Our Price: $13.02
19	008614507	Oil Seal 45x65x8 mm	2 req	Current Stock: 2 Our Price: $53.97
20	008411002	SEE PN WHT000768	6 req	Avail to order Our Price: $2.00
21	N10155210	HEX.NUT	6 req	Current Stock: 38 Our Price: $2.01
22	002335028	Drive Shaft Diff Flange	2 req	Avail to order Our Price: $964.97
23	002332653	Washer	2 req	Avail to order Our Price: $115.56
24	002332652	Washer	2 req	Avail to order Our Price: $10.51
25	002332651	Screw	1 req	Avail to order Our Price: $24.31
26	008583502	Circlip	1 req	Avail to order Our Price: $2.00
27	008523514	NLA (No Longer Available)	1 req	*See Description
28	008575000	O-Ring I 50 Uni 3654	1 req	Avail to order Our Price: $2.00
29	008254503	M45x1.5 Special RingNut	1 req	Avail to order Our Price: $183.18
30	002331917	Spacer	1 req	Current Stock: 17 Our Price: $27.01
30	002331918	Spacer	1 req	Current Stock: 10 Our Price: $26.67
30	002331919	Spacer	1 req	Current Stock: 8 Our Price: $26.67
30	002331920	Spacer	1 req	Current Stock: 16 Our Price: $26.67
30	002331921	Spacer	1 req	Current Stock: 50 Our Price: $26.67
31	002324940	Bushing	1 req	Avail to order Our Price: $252.67
32	002332650	Screw	1 req	Avail to order Our Price: $29.59
33	008900503	Elastic Pin 5x36 Din1481	1 req	Current Stock: 18 Our Price: $2.00
34	002334682	Bevel Gear	1 req	Avail to order Our Price: $5,205.48
35	0B9517021	Rear Differential	1 req	Avail to order Our Price: $7,491.21
36	002324935	Propeller Shaft Sleeve	1 req	Avail to order Our Price: $363.44
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
