TAV: 32.01.01 - Rear Brakes

1991-1993 Lamborghini Diablo 2WD USA Rear Brakes (32.01.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003229882	Brake Line	2 req	Avail to order Our Price: $194.57
2	003113907	Bolt	2 req	Avail to order Our Price: $31.84
3	003113906	Washer	2 req	Avail to order Our Price: $20.67
4	003113904	Brake Banjo Fitting	2 req	Avail to order Our Price: $162.75
5	003113905	WASHER 3.3502.3000.1/03	2 req	Current Stock: 3 Our Price: $2.61
6	003230719	Washer Shim 0.05	1 req	Avail to order Our Price: $2.00
6	003230720	Washer Shim 0.1	1 req	Avail to order Our Price: $7.76
6	003230721	Washer Shim 0.2	1 req	Avail to order Our Price: $2.00
6	WHT000697	WASHER	1 req	Current Stock: 18 Our Price: $2.00
6	003230723	Washer Shim 0.4	1 req	Avail to order Our Price: $2.00
6	003230724	Washer Shim 0.5	1 req	Avail to order Our Price: $2.00
6	003230725	Washer Shim 0.6	1 req	Avail to order Our Price: $2.00
6	003230726	Washer Shim 0.8	1 req	Avail to order Our Price: $2.00
6	003230727	Washer Shim 1.	1 req	Avail to order Our Price: $3.73
7	003235293	Brake Pad Rear -Early Diablo - Sold Each	4 req	Avail to order Our Price: $1,052.31
8	003226352	Brake Caliper 1991-1993 Diablo LEFT	1 req	Avail to order Our Price: $2,088.26
8	003226353	Brake Caliper 1991-1993 Diablo RIGHT	1 req	Avail to order Our Price: $2,088.26
9	008100826	Screw M8x16 Uni 5739/8g/Z	6 req	Avail to order Our Price: $2.00
10	003234862	Rear Brake Disc	2 req	Avail to order Our Price: $3,277.31
11	008401217	Washer12 Allen Screw5s	4 req	Current Stock: 3 Our Price: $6.79
12	008101247	Screw M12x22 Ch19 10k Bon.	4 req	Avail to order Our Price: $8.05
13	WHT003055	Washer 13x24x1.2 Din137/B C72	4 req	Current Stock: 10 Our Price: $2.00
14	008101246	Bolt D.M12x1.5x30 10k Bon	4 req	Avail to order Our Price: $71.35
15	003331672	Ebrake Pads Set (1 pair)	1 req	Avail to order Our Price: $202.76
16	003327754	Handbrake Lh Shoe Caliper up to chassis # 12620	1 req	Avail to order Our Price: $1,258.33
16	003333273	LH Handbrake Shoe from chassis # 12621	1 req	Avail to order Our Price: $2,981.82
16	003327753	RH Caliper up to chassis # 12620	1 req	Avail to order Our Price: $2,310.91
16	003333274	NLA (no longer available)	1 req	*See Description
17	008900204	Elastic Pin 2.5x18 Din 1481	2 req	Avail to order Our Price: $2.00
18	410609774	Nylon Bushing	2 req	Avail to order Our Price: $115.24
19	003319644	NLA	2 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
