TAV: 31.01.02 - Front Brakes

1991-1993 Lamborghini Diablo 2WD USA Front Brakes (31.01.02)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008836302	Clamp	4 req	Avail to order Our Price: $13.22
2	009453128	Brake Air Delivery Pipe	2 req	Avail to order Our Price: $199.21
3	N01020717	HEXAGON HEAD BOLT	6 req	Current Stock: 4 Our Price: $2.00
4	WHT003364	SERRATED LOCK	6 req	Avail to order Our Price: $2.43
5	008400509	Flat Washer 5.3x11x1uni1734	6 req	Avail to order Our Price: $2.00
6	003129881	Front Shoe Pipe	1 req	Avail to order Our Price: $117.39
7	003129778	Front Shoe Hose Bolt	2 req	Avail to order Our Price: $69.14
8	003113905	WASHER 3.3502.3000.1/03	2 req	Current Stock: 3 Our Price: $2.63
9	003113904	Brake Banjo Fitting	2 req	Avail to order Our Price: $162.76
10	003113906	Washer	4 req	Avail to order Our Price: $20.65
11	003129777	NLA (No Longer Available)	2 req	*See Description
12	008101219	NLA (No Longer Available)	4 req	*See Description
13	008401217	Washer12 Allen Screw5s	4 req	Current Stock: 3 Our Price: $6.81
14	003230719	Washer Shim 0.05	1 req	Avail to order Our Price: $2.00
14	003230720	Washer Shim 0.1	1 req	Avail to order Our Price: $7.78
14	003230721	Washer Shim 0.2	1 req	Avail to order Our Price: $2.00
14	WHT000697	WASHER	1 req	Current Stock: 18 Our Price: $2.00
14	003230723	Washer Shim 0.4	1 req	Avail to order Our Price: $2.00
14	003230724	Washer Shim 0.5	1 req	Avail to order Our Price: $2.00
14	003230725	Washer Shim 0.6	1 req	Avail to order Our Price: $2.00
14	003230726	Washer Shim 0.8	1 req	Avail to order Our Price: $2.00
14	003230727	Washer Shim 1.	1 req	Avail to order Our Price: $3.70
15	003132825	Rh Mudguard	1 req	Avail to order Our Price: $377.19
15	003132826	Lh Mudguard	1 req	Avail to order Our Price: $377.19
16	003129435	Shoe SX, SIN (Right Side) Brake caliper	1 req	Avail to order Our Price: $2,095.75
16	003129436	Shoe DX (Left Side) Brake caliper	1 req	Avail to order Our Price: $2,095.75
17	003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor	2 req	Avail to order Our Price: $524.64
18	008100825	Special Screw M8x16	6 req	Avail to order Our Price: $8.85
19	003126969	Front Rotor Disc	2 req	Avail to order Our Price: $1,684.78
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
