TAV: 21.02.00 - Clutch Control Lever

1991-1993 Lamborghini Diablo 2WD USA Clutch Control Lever (21.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004219984	Master Clutch Cylinder	1 req	Avail to order Our Price: $332.32
2	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
3	008100830	Screw M8x20 Uni 5739/8g/Z	2 req	Current Stock: 19 Our Price: $2.00
4	008200811	M8 Uni 5589/8g/ZdNut	1 req	Avail to order Our Price: $6.29
5	N0111849	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 5 Our Price: $2.23
6	WHT002962	WASHER	1 req	Current Stock: 12 Our Price: $2.00
7	410721213	Brake Cylinder Control Fork	1 req	Current Stock: 1 Our Price: $63.37
8	008400819	Washer 8x12x1 Bv.0005096.A	1 req	Current Stock: 1 Our Price: $2.00
9	WHT002962	WASHER	1 req	Current Stock: 12 Our Price: $2.00
10	002129460	Clutch Cylinder ForkPin	1 req	Current Stock: 1 Our Price: $35.17
11	008900503	Elastic Pin 5x36 Din1481	2 req	Current Stock: 18 Our Price: $2.00
12	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	1 req	Current Stock: 5 Our Price: $2.00
13	WHT002952	HEXAGON HEAD BOLT	1 req	Current Stock: 2 Our Price: $5.03
14	002125925	Clutch Drive Shaft	1 req	Avail to order Our Price: $533.24
15	008900802	Pin Din 1481 8x36x1.5	2 req	Current Stock: 1 Our Price: $8.15
16	N01100845	HEX.NUT	11 req	Current Stock: 16 Our Price: $1.94
17	WHT001514	SPRING WASHER	11 req	Current Stock: 9 Our Price: $25.05
18	008300808	Stud M8x35 Uni 5911 8g Z	9 req	Avail to order Our Price: $5.86
19	008522204	Code 30030200270	3 req	Current Stock: 1 Our Price: $21.73
20	008576601	O-Ring I 62 Uni 3654	2 req	Avail to order Our Price: $2.00
21	008605600	Or Ring	1 req	Avail to order Our Price: $42.65
22	002424858	Secondary Shaft Cover	1 req	Avail to order Our Price: $152.97
23	002130853	Clutch Cylinder Pipe/Rear Pipe	1 req	Avail to order Our Price: $258.04
24	WHT002952	HEXAGON HEAD BOLT	1 req	Current Stock: 2 Our Price: $5.03
25	410721427	Servo Spring Tierod	1 req	Avail to order Our Price: $78.36
26	002129457	Clutch Lever	1 req	Current Stock: 1 Our Price: $518.38
27	WHT002962	WASHER	1 req	Current Stock: 12 Our Price: $2.00
28	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $2.00
29	N01100845	HEX.NUT	1 req	Current Stock: 16 Our Price: $1.94
30	002131194	Union	1 req	Avail to order Our Price: $150.11
31	008583701	O-Ring E 37 Uni 7435-75	1 req	Current Stock: 8 Our Price: $2.00
32	002129128	Clutch Cylinder Shim	2 req	Avail to order Our Price: $57.78
33	002121672	Cylinder Fork	1 req	Avail to order Our Price: $109.08
34	008200811	M8 Uni 5589/8g/ZdNut	1 req	Avail to order Our Price: $6.29
35	WHT003078	Reference Pin 8h7x16C40	1 req	Avail to order Our Price: $17.16
36	002121345	Clutch Cylinder Rod	1 req	Current Stock: 1 Our Price: $337.39
37	002131528	Clutch Pipe	1 req	Avail to order Our Price: $168.70
38	002136948	Slave Clutch Cylinder Diablo // Countach	1 req	Avail to order Our Price: $126.99
39	002110618	Clutch Pipe	1 req	Avail to order Our Price: $90.07
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
