1991-1993 Lamborghini Diablo 2WD USA Pedals Assembly (42.01.01)

Maintenance Parts:

Belts

PN	Item
001725107	Alternator/Coolant Pump Belt UP TO VIN 12582 Alternator/Coolant Pump Belt	Avail to order Our Price: $142.24
001731857	Coolant Pump Alternator Belt after VIN 12583 Coolant Pump Alternator Belt	Current Stock: 1 Our Price: $122.08
004529536	Compressor Belt Until Compressor Belt	Avail to order Our Price: $211.71

Brakes

PN	Item
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads	Avail to order Our Price: $524.67
003235293	Brake Pad Rear -Early Diablo - Sold Each Rear Brake Pad 1991-1993 Diablo and 1994 Diablo SE	Avail to order Our Price: $1,052.31
003331672	Ebrake Pads Set (1 pair) E Brake Pads Set (1 pair)	Avail to order Our Price: $202.76

Common repairs and upgrades

PN	Item
006329689	HIGH BEAM HEADLIGHT HIGH BEAM HEADLIGHT	Avail to order Our Price: $535.96
0079004387	SHOCK ABSORBER SHOCK ABSORBER FOR ANTERIOR COWLING	Current Stock: 2 Our Price: $139.79
0092004388	shock absorber for engine cowling shock absorber for engine cowling	Current Stock: 4 Our Price: $253.09
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002132598	Clutch Mechanism - Early Diablo Clutch Mechanism	Avail to order Our Price: $1,674.86
002129353	THRUST SLEEVE THRUST SLEEVE - NLA (No Longer AVAILABLE) FROM FACTORY. PLEASE CHECK WITH US FOR ALTERNATIVES	Avail to order Our Price: $1,630.19
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
0017002473	WATER PUMP (2WD W/O POWER STEARING) (1991-1994) WATER PUMP (2WD W/O POWER STEARING) (1991-1994)	Avail to order Our Price: $5,306.12
0017002474	Water Pump (2WD With Power Steering) (1991-1994) Coolant Pump 2WD With	Current Stock: 1 Our Price: $6,101.30
002132599	CLUTCH PRESSURE PLATE - DIABLO CLUTCH PLATE - NLA (No Longer AVAILABLE) FROM FACTORY. PLEASE CHECK WITH US FOR ALTERNATIVES - ABOUT 2 WEEK LEAD TIME	Avail to order Our Price: $1,850.00
002136948	Slave Clutch Cylinder Diablo / Countach Slave Clutch Cylinder	Current Stock: 5 Our Price: $134.59
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
0R1320001	NLA (No Longer Available) SPEED SENSOR KIT	Avail to order Our Price: $940.84
001434600	Oversize Thrust Washer Oversize Thrust Washer	Avail to order Our Price: $77.14
001434601	Oversized Shoulder Washer Oversized Shoulder Washer	Avail to order Our Price: $77.14
002132599K	1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF 1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF - Clutchtex - TZ-3022 T3	Avail to order Our Price: $900.97
005129802	Front Shock Absorber Front Shock Absorber	Current Stock: 4 Our Price: $1,159.75
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Avail to order Our Price: $104.15

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Avail to order Our Price: $31.69
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.29
AMAIRD	Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT Air Filter Murcielago - Diablo After Market aFe Air Filter 30-10133	Current Stock: 1 Our Price: $145.65
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.53
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $762.25
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $273.87
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $782.61
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $70.48

Fuses-Bulbs-Relays

PN	Item
006030676	Light Relay Light Relay	Current Stock: 3 Our Price: $184.13
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006311155	Relay Relay	Avail to order Our Price: $67.32
006329694	Bulb Headlight Bulb headlight	Avail to order Our Price: $63.82
006329695	BULB FOR FOGLIGHT BULB FOR FOGLIGHT	Current Stock: 1 Our Price: $19.36
006329696	Bulb 5w Front Turn Signal 5w Bulb front turn signal	Current Stock: 6 Our Price: $3.35
006329698	Bulb Bulb	Avail to order Our Price: $9.02
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
410947413	RED DOOR LIGHT RED DOOR LIGHT - NLA (No Longer Available) TO ORDER FROM FACTORY PLEASE CONTACT US FOR OTHER OPTIONS.	Avail to order Our Price: $92.91

Gaskets

PN	Item	Diagram
001532102	GROMMET AND OIL SEALS SET - DIABLO 1991-1996 GROMMET AND OIL SEALS SET - DIABLO 1991-1996		Avail to order Our Price: $220.72
0R1320002	Diablo REAR Differential Seal Kit Dif Seal Kit		Current Stock: 1 Our Price: $48.53

Ignition

PN	Item
001630289	Spark Plug - Diablo Spark Plug	Current Stock: 50 Our Price: $32.83
DiabloWireSet	Spark Plug Wires 1991-1995 Diablo - Aftermarket Spark Plug Wires 1991 through 1995 ONLY for systems using a Distributor cap	Avail to order Our Price: $820.50
001627728	DISTRIBUTOR CAP !991-1993 DIABLO Cap Distributor Cap 1991 - 1993 NO LONGER AVAILABLE TO ORDER FROM FACTORY THIS IS OE SPEC OPTION	Current Stock: 3 Our Price: $340.00
001627730	DIABLO IGNITION ROTOR DIABLO IGNITION ROTOR - NLA for FACTORY we have exact OE Replacement	Current Stock: 2 Our Price: $289.00
006134023	SPARK PLUG WIRES Spark Plug Wires ONLY for systems using distributor cap. NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY Depending on production year may require different set: SEE PN: 006134279 & 001134281	Avail to order Our Price: $743.20
001630792N	Coil pack OE SPEC REPLACEMENT Coil pack OE SPEC REPLACEMENT	Avail to order Our Price: $1,957.58

Misc

PN	Item
009420126	WINDSHIELD WIPER BLADE WINDSHIELD WIPER BLADE	Avail to order Our Price: $36.40
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98

Sensors

PN	Item
001327641	Potentiometer TPS Throttle Position Sensor Diablos Potentiometer	Avail to order Our Price: $199.79
001536755	OIL TEMPERATURE THERMOSTAT OIL TEMPERATURE THERMOSTAT - also used on Diablo 91-93 2wd and 94	Current Stock: 1 Our Price: $544.18
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $295.00
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $1,965.17
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $375.18
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.09
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Avail to order Our Price: $308.18
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $244.50
0R1470226	Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO Lambda (O2 Oxygen) Sensor - DIABLO - EARLY MURCIELAGO	Current Stock: 4 Our Price: $393.04

Tools and Tookits

PN	Item	Diagram
004129973	DIABLO FRONT TOW HITCH ASSEMBLY DIABLO FRONT TOW HITCH ASSEMBLY		Avail to order Our Price: $1,525.98

Open All

Select Group and TAV

< Previous Next >

TAV: 42.01.01 - Pedals Assembly

1991-1993 Lamborghini Diablo 2WD USA Pedals Assembly (42.01.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001321270	Throttle Lever Return Spring	2 req	Current Stock: 3 Our Price: $9.77
2	008802501	Bushing 25x28x15 mm	2 req	Avail to order Our Price: $25.50
3	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
4	004210834	Brake/Clutch Pedal Adjustment	2 req	Avail to order Our Price: $5.22
5	008900803	Elastic Pin 8x40 Uni1481	2 req	Avail to order Our Price: $2.00
6	004227889	Servo Clutch Pedal Spring	1 req	Avail to order Our Price: $87.97
7	004225066	NLA (No Longer Available)	1 req	*See Description
8	WHT002962	WASHER	3 req	Current Stock: 11 Our Price: $2.00
9	410721427	Servo Spring Tierod	2 req	Avail to order Our Price: $96.32
10	N0111849	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 5 Our Price: $2.39
11	WHT002952	HEXAGON HEAD BOLT	1 req	Current Stock: 2 Our Price: $5.36
12	008400819	Washer 8x12x1 Bv.0005096.A	2 req	Current Stock: 1 Our Price: $2.00
13	413721325	Brake/Clutch Pedal Pin	1 req	Avail to order Our Price: $3,714.46
14	004230089	Accelerator Pedal Wire Assembl	1 req	Avail to order Our Price: $1,337.35
15	004230143	Accelerator Pedal Assembly	1 req	Avail to order Our Price: $638.11
16	004231965	Clutch Pedal	1 req	Avail to order Our Price: $362.66
17	0042005210	Pedal Cover (Clutch or Brake)	1 req	Avail to order Our Price: $80.51
18	004230144	Brake Pedal	1 req	Avail to order 1 Used Available Our Price: $599.35
19	0042005210	Pedal Cover (Clutch or Brake)	1 req	Avail to order Our Price: $80.51
20	N01100845	HEX.NUT	2 req	Current Stock: 17 Our Price: $2.09
21	008100828	Screw M8x45 Uni 5739/5s/Z	1 req	Avail to order Our Price: $2.00
22	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.39
23	008581101	O-Ring E 12 Uni 7435-75	1 req	Avail to order Our Price: $6.79
24	008401220	Washer 12.4x22x1/Aq45	2 req	Avail to order Our Price: $6.93
25	008521205	BEARING	2 req	Current Stock: 2 Our Price: $12.81
26	004231811	Accelerator Pedal Bracket	1 req	Avail to order Our Price: $292.96
27	004238042	Accelerator Wire Lever	1 req	Avail to order Our Price: $39.74
28	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $2.00
29	008410819	Snap Ring D.8 Din 7980	1 req	Current Stock: 8 Our Price: $2.68
30	008900305	Door handle cable Pin	2 req	Current Stock: 10 Our Price: $2.00
31	004225062	Brake Booster Lever Rod	1 req	Avail to order Our Price: $76.34
32	410721965	Brake Booster Control Lever Pi	1 req	Avail to order Our Price: $32.01
33	008401007	Washer 21.5x10.4x2 Uni 6592/5s	6 req	Avail to order Our Price: $2.00
34	004232621	Brake Booster & Pedal Board Pi	2 req	Avail to order Our Price: $43.91
35	008581004	Clip	3 req	Avail to order Our Price: $10.89
36	004225060	Brake Booster Lever	1 req	Avail to order Our Price: $87.82
37	008801209	Bushing 12x14x20 mm	1 req	Avail to order Our Price: $11.11
38	004225061	Brake Booster Lever Rod	1 req	Avail to order Our Price: $79.62
39	004232622	Pin On Brake Pedal For Cap	1 req	Avail to order Our Price: $30.94
40	N10155210	HEX.NUT	1 req	Current Stock: 38 Our Price: $2.17
41	004233379	Clutch Pedal Spring Bracket	1 req	Avail to order Our Price: $65.25
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
