1994 Lamborghini Diablo SE USA Climate Control (45.01.00)

Maintenance Parts:

Belts

PN	Item
001731857	Coolant Pump Alternator Belt after VIN 12583 Coolant Pump Alternator Belt	Avail to order Our Price: $113.80
001736517	Coolant Pump Alternator Belt (From SE VIN 12043) Coolant Pump Alternator Belt	Avail to order Our Price: $305.53
004529536	Compressor Belt Until Compressor Belt	Avail to order Our Price: $196.57
004534071	Compressor Belt Compressor Belt	Avail to order Our Price: $134.52

Brakes

PN	Item
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads	Avail to order Our Price: $496.66
003235293	Brake Pad Rear -Early Diablo - Sold Each Rear Brake Pad 1991-1993 Diablo and 1994 Diablo SE	Avail to order Our Price: $202.00
003331672	Ebrake Pads Set (1 pair) E Brake Pads Set (1 pair)	Avail to order Our Price: $188.71

Drivetrain

PN	Item
0017002473	Water Pump (2WD w/o Power Stearing) (1991-1994) Coolant Pump 2WD W/o	Avail to order Our Price: $5,017.25
0017002474	Water Pump (2WD With Power Steering) (1991-1994) Coolant Pump 2WD With	Current Stock: 1 Our Price: $5,770.19
002129353	Thrust Sleeve Throw out bearing Thrust Sleeve	Avail to order Our Price: $1,515.36
002132598	Clutch Mechanism - Early Diablo Clutch Mechanism	Avail to order Our Price: $1,558.25
002132599	NLA (No Longer Available) Clutch Plate	Avail to order Our Price: $3,559.65
002132599K	1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF 1991 - 1994 Diablo Clutch Disk - KEVLAR HI-PERF - Clutchtex - TZ-3022 T3	Current Stock: 1 Our Price: $868.50
002136948	Slave Clutch Cylinder Diablo // Countach Slave Clutch Cylinder	Avail to order Our Price: $126.99
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $332.32
07M115561	see PN 07M115561B Oil Filter Cartridge	Avail to order Our Price: $48.56
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 2 Our Price: $48.56
0R1320001	NLA (No Longer Available) SPEED SENSOR KIT	Avail to order Our Price: $889.06

Fuel-Air

PN	Item
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $377.42
002024398	Fuel Pump Fuel Pump	Current Stock: 1 Our Price: $719.65
002027648R	Pressure Regulator Valve OE SPEC Pressure Regulator Valve	Avail to order Our Price: $264.00
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 1 Our Price: $29.72
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $733.78
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $67.93
07M906031	Fuel Injector (sold ea) Please Check your Part Manual for a Description	Avail to order Our Price: $1,277.24
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $274.81
400201511AZ	OE Spec Aftermarket Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $88.39
AMAIRD	Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT Air Filter Murcielago - Diablo After Market aFe Air Filter 30-10133	Current Stock: 1 Our Price: $140.40

Fuses-Bulbs-Relays

PN	Item
006030676	Light Relay Light Relay	Current Stock: 3 Our Price: $170.84
006034961	Relay Relay	Current Stock: 4 Our Price: $24.48
006036296	NLA (No Longer Available) Relay	Avail to order Our Price: $22.95
006036297	NLA (No Longer Available) Relay	Avail to order Our Price: $43.47
006311155	Relay Relay	Avail to order Our Price: $62.69
006329694	Bulb Headlight Bulb headlight	Avail to order Our Price: $59.40
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $12.67
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.36
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01

Gaskets

PN	Item
001536079	Engine Gasket Set Diablo SE S.E. Engine Gasket Kit- See PN 1536080 for Grommet and oil Kit	Avail to order Our Price: $2,816.32
001536080	Grommet and Oil Seals Set - Diablo SE Grommet and Oil Seals Set - Diablo SE	Avail to order Our Price: $266.43
0R1320002	Diablo REAR Differential Seal Kit Dif Seal Kit	Current Stock: 1 Our Price: $45.17
600940141L	latch Gasket Left latch Gasket Set Left This is the rubber/plastic gasket that is located on the Left side between the outer door latch and the door frame	Current Stock: 5 Our Price: $23.40

Ignition

PN	Item
001627728	NLA (No Longer Available) Cap Distributor Cap 1991 - 1993 SEE PN 001627728N for OE SPEC OPTION	Avail to order Our Price: $1,484.18
001627730	NLA (No Longer Available) Rotor	Avail to order Our Price: $1,853.41
001627730R	Rotor Brush 1991 - 1994 Diablos OE Spec - Rotating Brush	Avail to order Our Price: $307.89
001630289	Spark Plug - Diablo Spark Plug Champion A59GC	Avail to order Our Price: $30.60
001630792N	Coil pack OE SPEC REPLACEMENT Coil pack OE SPEC REPLACEMENT	Avail to order Our Price: $1,887.02
DiabloWireSet	Spark Plug Wires 1991-1995 Diablo - Aftermarket Spark Plug Wires 1991 through 1995 ONLY for systems using a Distributor cap	Avail to order Our Price: $790.92

Misc

PN	Item
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
009420126	Windshield Wiper Blade Windshield Wiper Blade	Avail to order Our Price: $33.96
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item
001327641	Potentiometer TPS Throttle Position Sensor Diablos Potentiometer	Avail to order Our Price: $185.85
001536755	Oil Temperature Thermostat Oil Temperature Snsor also used on Diablo 91-93 2wd and 94	Current Stock: 1 Our Price: $507.51
0017006576	NLA (No Longer Available) WATER THERMOSTAT	Avail to order Our Price: $511.14
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $230.95
002408637	Reverse Switch Switch	Avail to order Our Price: $127.24
004429307	SEE PN 0R1470226 Lambda Sensor	Avail to order Our Price: $409.78
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $255.57
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $350.89
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $658.83
07M919529	Engine Air Temperature Sensor Engine Air Temperature Sensor	Current Stock: 1 Our Price: $287.75

Open All

Select Group and TAV

< Previous Next >

TAV: 45.01.00 - Climate Control

1994 Lamborghini Diablo SE USA Climate Control (45.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	006132546	One-Pin Connector	1 req	Avail to order Our Price: $19.52
2	006132584	Therm. Amp 282110-1	1 req	Avail to order Our Price: $8.58
3	006133204	Connector Secondary Lock	1 req	Current Stock: 17 Our Price: $2.00
4	008701008	Screw 10x55 Uni5931 Dacrom	1 req	Avail to order Our Price: $3.26
5	008411002	SEE PN WHT000768	4 req	Avail to order Our Price: $2.00
6	008201008	Nut	4 req	Current Stock: 2 Our Price: $2.00
7	004529645	Compressor Mount Tierod	1 req	Avail to order Our Price: $39.82
8	N01100845	HEX.NUT	2 req	Current Stock: 16 Our Price: $1.94
9	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
10	008701017	Screw M10x35 Uni 5931/8g/Z D	1 req	Avail to order Our Price: $2.00
11	004529535	Conditioner Compressor Bracket	1 req	Avail to order Our Price: $611.86
12	008401028	Washer 22x10.5x2.5 Uni 1734/5s	1 req	Avail to order Our Price: $6.29
13	004529646	Adjustment Shim	1 req	Avail to order Our Price: $26.88
14	008100620	Screw M6x12 Uni 5739/5s/Z	2 req	Avail to order Our Price: $6.29
15	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $2.00
16	008400605	Fibre Washer D.6.4x13x1	2 req	Avail to order Our Price: $2.65
17	004532221	Compressor Heat Guard	1 req	Avail to order Our Price: $920.65
18	N01033520	HEXAGON HEAD BOLT	2 req	Current Stock: 6 Our Price: $2.00
19	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
20	WHT002952	HEXAGON HEAD BOLT	2 req	Current Stock: 2 Our Price: $5.03
21	004530198	Air Condition Compressor (1991-1995 Diablo)	1 req	Avail to order Our Price: $1,491.42
22	004534071	Compressor Belt	1 req	Avail to order Our Price: $134.52
22	004529536	Compressor Belt Until	1 req	Avail to order Our Price: $196.57
23	008700841	Screw M8x70 Uni 5925/12k	1 req	Avail to order Our Price: $2.43
24	N01100845	HEX.NUT	1 req	Current Stock: 16 Our Price: $1.94
25	008701020	Screw M10x50 Uni 5931/8g/Z D	1 req	Current Stock: 8 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
