TAV: 15.02.00 - Engine Oil System

1994 Lamborghini Diablo SE USA Engine Oil System (15.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001535078	Oil Cartridge Bracket Union Pi	1 req	Current Stock: 1 Our Price: $628.27
2	001535076	Engine Union Pipe To Radiator	1 req	Current Stock: 1 Our Price: $948.35
3	001531827	Oil Delivery Pipe ToThermostat	1 req	Avail to order Our Price: $371.58
4	001531859	Engine Oil Return Pipe	1 req	Current Stock: 1 Our Price: $336.46
5	008100830	Screw M8x20 Uni 5739/8g/Z	2 req	Current Stock: 19 Our Price: $2.00
6	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
7	WHT003062	O-RING	1 req	Avail to order Our Price: $7.08
8	008403006	Copper Washer 30x40x0,04513888	1 req	Current Stock: 18 Our Price: $11.85
9	001529610	Thermostat Valve Union	1 req	Current Stock: 1 Our Price: $55.66
10	004133013	Oil Radiator BracketRod	1 req	Avail to order Our Price: $119.27
11	0015001970	Hose	1 req	Avail to order Our Price: $879.90
12	004133295	Oil Radiator Side Bracket	1 req	Avail to order Our Price: $133.78
13	07M117021	Engine Oil Radiator	1 req	Avail to order Our Price: $4,659.83
14	410813585	Oil Radiator Rubber Mount On B	1 req	Current Stock: 1 Our Price: $15.04
15	004133292	Oil Radiator BracketAssembly	1 req	Avail to order Our Price: $481.57
16	008700663	Screw M6	2 req	Current Stock: 11 Our Price: $2.00
17	N10718801	HEXAGON FLANGE BOLT	1 req	Current Stock: 4 Our Price: $2.00
18	001533284	Upper Oil Radiator Bracket	1 req	Avail to order Our Price: $45.78
19	N90327506	SPEED NUT	1 req	Current Stock: 43 Our Price: $2.00
20	008920604	Rubber Support	1 req	Avail to order Our Price: $22.52
21	N01508213	HEXAGON FLANGE NUT	2 req	Current Stock: 4 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
