TAV: 51.02.00 - Front Suspension

1994 Lamborghini Diablo SE USA Front Suspension (51.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	WHT003355	clamping nut	4 req	Current Stock: 13 Our Price: $23.53
2	410512383	Extendible 012 X 042X 46 X 35	4 req	Avail to order Our Price: $631.24
3	008101259	Screw 12x1.25x70uni5738zg8g	2 req	Avail to order Our Price: $18.05
4	005131484	Shock Absorber Top Shim	2 req	Avail to order Our Price: $41.23
5	410512385	Shock Absorber Bulkhead	4 req	Avail to order 1 Used Available Our Price: $57.40
6	005135181	Front Suspension Spring	2 req	Avail to order Our Price: $99.89
7	005133344	Rh Upper Wishbone	1 req	Avail to order Our Price: $1,672.10
7	005133345	Lh Upper Wishbone	1 req	Avail to order 1 Used Available Our Price: $1,753.85
8	005134057	Front Torsion Bar	1 req	Avail to order Our Price: $517.35
9	008101269	Screw M12x1.25x75 Uni 5738	4 req	Avail to order Our Price: $5.13
10	410407295D	SPACER RING	req	Current Stock: 11 Our Price: $31.94
10	410407295	SPACER RING	req	Current Stock: 27 Our Price: $4.85
10	410407295A	SPACER RING	req	Current Stock: 15 Our Price: $7.30
10	005133489	Lock Flange Adjustment Shim 2	req	Current Stock: 8 Our Price: $4.31
10	410407295C	SPACER RING (Previosly PN 005133490)	req	Current Stock: 15 Our Price: $7.89
11	008921206	Flanbloc	8 req	Avail to order Our Price: $50.09
12	005238302	Torsion Bar Bushing	2 req	Avail to order Our Price: $163.26
13	005230258	Torsion Bar Bracket Assembly	2 req	Current Stock: 2 Our Price: $362.51
14	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
15	008700609	Screw 6x45 Uni 5931/8g/Zd	4 req	Avail to order Our Price: $2.00
16	WHT003355	clamping nut	8 req	Current Stock: 13 Our Price: $23.53
17	005109714	Sway bar joint Boot	4 req	Avail to order Our Price: $30.64
18	005227297	Ball Joint Bushing	8 req	Current Stock: 2 Our Price: $32.26
19	008100810	Screw 8x1.25x45 BLACK FLANGE	4 req	Current Stock: 94 Our Price: $2.00
20	417801931A	STRAP JOINT	2 req	Avail to order Our Price: $284.36
21	008201014	M10x1x6 Uni 5589/5s/Z Nut	2 req	Current Stock: 1 Our Price: $7.16
22	005209770	NLA (No Longer Available)	2 req	*See Description
23	008201016	10x1x6 S Left Nut	2 req	Avail to order Our Price: $26.55
24	005227295	Ball Joint (reverse thread)	2 req	Avail to order Our Price: $151.85
25	410407135A	ECCENTRIC BUSH	4 req	Current Stock: 2 Our Price: $88.89
26	410407127A	ECCENTRIC	4 req	Avail to order Our Price: $1,079.35
27	005133038	Rh Lower Wishbone	1 req	Current Stock: 1 1 Used Available Our Price: $1,300.53
27	005133039	Lh Lower Wishbone	1 req	Avail to order 2 Used Available Our Price: $1,300.53
28	008700606	Screw Ei M6x1x10 12kd	4 req	Current Stock: 37 Our Price: $2.00
29	410407361B	LOCATING LINKAGE	2 req	Avail to order Our Price: $1,354.78
30	410407171	Arm Bracket Sleeve	4 req	Avail to order Our Price: $107.94
31	N01100845	HEX.NUT	2 req	Current Stock: 17 Our Price: $2.09
32	008401230	Washer	2 req	Avail to order Our Price: $57.97
33	005129541	Steering Arm Joint Sleeve	2 req	Avail to order Our Price: $55.24
34	N90840401	WASHER	12 req	Current Stock: 21 Our Price: $2.00
35	005129802	Front Shock Absorber	2 req	Current Stock: 4 Our Price: $1,159.75
36	005133229	Front Shock AbsorberBolts	2 req	Avail to order Our Price: $8.80
37	005135183	Lower Spring Plate Shim	2 req	Avail to order Our Price: $130.21
38	410407365	JOINT	2 req	Avail to order Our Price: $282.12
39	008200804	Nut	4 req	Current Stock: 7 Our Price: $2.00
40	005227298	Torsion Bar Adapter Bushing	4 req	Avail to order Our Price: $20.51
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
