TAV: 15.01.00 - Engine Oil Pump

1994 Lamborghini Diablo SE USA Engine Oil Pump (15.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001521899	Gear Torsion Bar From Shaft	1 req	Avail to order Our Price: $702.22
2	008582501	O-Ring E 25 Uni 7435-75	1 req	Avail to order Our Price: $6.79
3	008575001	O-Ring I 47 Uni 3654	1 req	Current Stock: 10 Our Price: $2.00
4	008700624	Screw 5931 6x1x20 8gZg	6 req	Current Stock: 10 Our Price: $2.00
5	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
6	008603503	Or Ring	1 req	Current Stock: 283 Our Price: $4.85
7	WHT003057	O-RING	1 req	Current Stock: 11 Our Price: $2.00
8	008502515	Bearing	1 req	Avail to order Our Price: $1,237.46
9	001530837	Oil Pump Cover	1 req	Avail to order Our Price: $3,846.54
10	001530839	Idle Gear	1 req	Avail to order Our Price: $836.80
11	WHT003577	Reference Pin 6h6x16C40	1 req	Avail to order Our Price: $2.09
12	001532497	Oil Pump Idle Gear	1 req	Avail to order Our Price: $1,058.26
13	008860508	Key Unim 99 5x6.5 I N C40	1 req	Avail to order Our Price: $2.00
14	001531819	Oil Pump Drive Gear Shaft	1 req	Avail to order Our Price: $813.02
15	008860808	Tab 8x7x22 Unim 92 C40/B	1 req	Avail to order Our Price: $2.00
16	008602603	Ring 27 mm Or	1 req	Current Stock: 19 Our Price: $2.00
17	008403006	Copper Washer 30x40x0,04513888	1 req	Current Stock: 18 Our Price: $11.85
18	008933002	Plug	1 req	Avail to order Our Price: $38.50
19	008523513	Code 300207200	1 req	Avail to order Our Price: $28.26
20	008574502	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
21	008613507	Oil Seal 35x50x7 mm	1 req	Avail to order Our Price: $7.31
22	008575000	O-Ring I 50 Uni 3654	1 req	Avail to order Our Price: $2.00
23	001228118	Plunger Sleeve	1 req	Current Stock: 2 Our Price: $131.06
24	001526871	Lock Pin	1 req	Avail to order Our Price: $50.55
25	001519888	Lock Pin Spring	1 req	Avail to order Our Price: $29.15
26	008402604	Copper Washer	1 req	Current Stock: 17 Our Price: $4.32
27	001524378	Plug Oil Pressure Adjustment S	1 req	Avail to order Our Price: $37.51
28	001524375	Spindle & Cap Assembly	1 req	Avail to order Our Price: $75.00
29	001531818	Oil Seal Race	1 req	Avail to order Our Price: $484.55
30	001525193	Torsion Bar Damper Shim	1 req	Avail to order Our Price: $120.92
31	008601301	Ring 13 mm Or	1 req	Avail to order Our Price: $2.00
32	008571901	O-Ring I 19 Uni 3654	1 req	Avail to order Our Price: $6.79
33	001525032	Accessory Drive Pulley	1 req	Avail to order Our Price: $1,351.06
34	008253001	M30x1.5x44 Ring Nut	1 req	Avail to order Our Price: $69.25
35	N0138481	WASHER	1 req	Current Stock: 20 Our Price: $2.00
36	008931607	Casting Plug	1 req	Current Stock: 3 Our Price: $5.88
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
