TAV: 12.01.00 - Timing System

1994 Lamborghini Diablo SE USA Timing System (12.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001229931	Chain Link	2 req	Avail to order Our Price: $6.19
2	001231564	Upper Timing Chain	2 req	Avail to order Our Price: $717.14
3	001131089	Guide For Timing Chain	2 req	Avail to order Our Price: $369.01
4	001224809	Camshaft Drive Gear	4 req	Avail to order Our Price: $4,020.47
5	008200605	Simmon Nut for urama	4 req	Current Stock: 50 Our Price: $3.06
6	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
7	WHT003041	Soft Copper Washer 6.4x12x1.5	4 req	Current Stock: 14 Our Price: $2.00
8	008700661	Screw M6x20 Uni 6107-67/8g/Z	4 req	Avail to order Our Price: $14.84
9	001219762	Screw Lock Plate	4 req	Avail to order Our Price: $51.29
10	001201964	Dowel	4 req	Avail to order Our Price: $53.31
11	001225448	Spin T. Gear & DriveFastening	1 req	Current Stock: 2 Our Price: $572.51
12	001219761	Washer	3 req	Avail to order Our Price: $108.25
13	001225771	Oil Breather Gear & Rotor Fast	2 req	Current Stock: 3 Our Price: $347.39
14	001228419	Oil Pump Camshaft Gear Screw	1 req	Current Stock: 1 Our Price: $505.42
15	001234659	NLA (No Longer Available)	2 req	*See Description
16	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
17	008700829	Screw M8x45 Uni 5931/8g/B	4 req	Avail to order Our Price: $6.79
18	N90840401	WASHER	2 req	Current Stock: 21 Our Price: $2.00
19	001231691	Rh Upper Chain Tightener Brack	1 req	Avail to order Our Price: $463.73
20	008601303	Ring 14 mm Or	2 req	Current Stock: 14 Our Price: $2.00
21	001232021	Chain Tightener Pin	1 req	Avail to order Our Price: $342.17
22	001231719	Rh Head Upper Chain Shoe	1 req	Avail to order Our Price: $69.26
23	001225046	Idle Gear Shim On Pin	2 req	Avail to order Our Price: $36.98
24	001224991	Upper Rh Chain Idle Gear	2 req	Avail to order Our Price: $557.37
25	008501204	Bearing	2 req	Avail to order Our Price: $7.83
26	008573203	O-Ring I 32 Uni 3654	2 req	Avail to order Our Price: $7.01
27	008601103	Ring 11 mm Or	2 req	Current Stock: 19 Our Price: $12.30
28	001228095	Upper Chain Idle Gear Pin	2 req	Avail to order Our Price: $535.24
29	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
30	008100607	Screw M6x18 Uni 5739/5s/Z	4 req	Avail to order Our Price: $6.79
31	001231690	Lh Upper Chain Tightener Brack	1 req	Avail to order Our Price: $463.73
32	001231695	Upper Chain Tightener Gear	2 req	Avail to order Our Price: $2,645.63
33	008522208	Needle Case 22x28x16	2 req	Avail to order Our Price: $44.22
34	008581701	Snap Ring	2 req	Avail to order Our Price: $2.00
35	008801702	Bushing 17x22x16 mm Ir	2 req	Avail to order Our Price: $40.43
36	001232020	Chain Tightener Pin	1 req	Avail to order Our Price: $342.17
37	008700844	Screw M8x30 Uni 5931/8g/B	6 req	Avail to order Our Price: $2.00
38	008410820	Snap Ring D.8 Din 7980	6 req	Current Stock: 50 Our Price: $2.00
39	WHT003543	Flat Washer 13 x 8.1-8.2 x 1.5	6 req	Avail to order Our Price: $12.95
40	001231087	Chain Shoe Mounting Bushing	6 req	Avail to order Our Price: $12.01
41	001231720	NLA (No Longer Available)	1 req	*See Description
42	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	6 req	Current Stock: 5 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
