TAV: 13.01.00 - Intake Manifold

1994 Lamborghini Diablo SE USA Intake Manifold (13.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001334565	Intake Manifold Rh Cover	1 req	Avail to order Our Price: $1,560.63
2	001323717	Intake Plenum Gasket	2 req	Current Stock: 1 Our Price: $57.92
3	001336467	Shim Between Manifold & Rh/Lh	4 req	Avail to order Our Price: $111.93
4	008401025	Washer 20x10.5x0.5	4 req	Avail to order Our Price: $38.85
5	001335012	This item is no longer available	1 req
6	WHT003165	TAP END STUD	10 req	Current Stock: 3 Our Price: $2.00
7	008200605	Simmon Nut for urama	10 req	Current Stock: 50 Our Price: $3.06
8	N01152427	WASHER	6 req	Current Stock: 16 Our Price: $2.00
9	001334566	Intake Manifold Lh Cover	1 req	Avail to order Our Price: $1,560.63
10	003101513	Copper Washer 16.2x24x1	6 req	Avail to order Our Price: $2.00
11	001328002	Rh/Lh Cover Union	2 req	Current Stock: 1 Our Price: $68.52
12	001328722	Screw	2 req	Current Stock: 1 Our Price: $188.61
13	001330455	Fairlead Bolt 5 mm	1 req	Avail to order Our Price: $38.62
14	008700541	Screw Fr M5 Tb 12x10	6 req	Avail to order Our Price: $3.66
15	008400511	Washer	6 req	Current Stock: 8 Our Price: $2.00
16	001335305	Lh Throttle Casing Cover	1 req	Avail to order Our Price: $481.57
17	001335307	Throttle Casing Cover Bracket	2 req	Avail to order Our Price: $32.28
18	008201006	M10Self Locking Nut	4 req	Avail to order Our Price: $8.80
19	008401022	Copper Washer D.10.2x14x1	4 req	Current Stock: 18 Our Price: $2.00
20	07M133119	Intake Manifold PipeInlet	1 req	Avail to order Our Price: $74.22
21	008301030	Special Stud M10x20	4 req	Avail to order Our Price: $40.78
22	001326311	Throttle Body Gasket	2 req	Current Stock: 2 Our Price: $25.62
23	001326181	Left Side Throttle Body	1 req	Avail to order Our Price: $1,300.53
24	WHT003028	TAP END STUD	7 req	Avail to order Our Price: $22.23
25	WHT002962	WASHER	8 req	Current Stock: 11 Our Price: $2.00
26	N0152785	WASHER	8 req	Current Stock: 71 Our Price: $2.00
27	N01100845	HEX.NUT	8 req	Current Stock: 17 Our Price: $2.09
28	001335306	Rh Throttle Casing Cover	1 req	Avail to order Our Price: $426.41
29	WHT003577	Reference Pin 6h6x16C40	4 req	Avail to order Our Price: $2.09
30	001327641	Potentiometer TPS Throttle Position Sensor Diablos	1 req	Avail to order Our Price: $199.79
31	001326293	Right Side Throttle Body w/TPS	1 req	Avail to order Our Price: $1,654.91
32	008300913	S.Plug Fix.Special Stud	1 req	Avail to order Our Price: $55.32
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
