1989 Lamborghini Countach 25th USA Door Frame (051.00)

Maintenance Parts:

Brakes

PN	Item	Diagram
003113912	Brake Pad Front and Rear Countach Brake Pad		Avail to order Our Price: $44.90

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $81.81
002136948	Slave Clutch Cylinder Diablo // Countach Slave Clutch Cylinder	Avail to order Our Price: $126.99
002121294	NLA (No Longer Available) Clutch Mechanism	Avail to order Our Price: $6,624.49
002121675	COUNTACH THOWOUT BEARING Thrust Sleeve	Current Stock: 1 Our Price: $8,034.23
001529245	COUNTACH 25th USA Gasket Kit Countach USA Gasket Kit See 001529243 for Grommets and seals	Avail to order Our Price: $2,106.81

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 1 Our Price: $29.72
002021140	Warm Up Regulator Heat Regulator 0438140004 (043 8140 004)	Avail to order Our Price: $1,608.28
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)	Avail to order Our Price: $825.35
002021173	Fuel Dampers Dampers	Avail to order Our Price: $483.20
002021146	Cold Start Injector Starter Injector	Current Stock: 4 Our Price: $331.59
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)	Avail to order Our Price: $5,502.31
002021174	Countach Injection EFI ECU ECU	Avail to order Our Price: $4,410.25
002021141	Countach EFI Fuel Injection Pump SEE ALSO PN 002021141B Fuel Pump	Avail to order Our Price: $1,486.77
002021147	Countach Fuel Injector Injector	Current Stock: 11 Our Price: $295.93
002021176	Lambda O2 Sensor (READ DESCRIPTION) Lambda Sensor The Exact OEM replacement for this is PN 002021176OE you can save by simply using your existing connector.	Avail to order Our Price: $803.43
002021141B	Countach EFI Fuel Injection Pump OEM This is the original and SAME fuel pump used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Current Stock: 1 Our Price: $117.00
001628130	NLA (No Longer Available) Relay/Printed Board Box Unit. This unit is not longer available from the factory.	Avail to order Our Price: $1,164.18
002021145	Accumulator Accumulators	Current Stock: 1 Our Price: $606.71
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability	Current Stock: 1 Our Price: $37.39
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $327.60
002021176OE	Lambda Sensors Original Equipment Lambda Sensors	Current Stock: 2 Our Price: $121.63
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $67.93
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $15.04
006223973	Fuel Filter Cartridge Fuel Filter Cartridge	Avail to order Our Price: $49.54
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $733.78

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.36
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $12.67
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
006319225	55w Bulb foglight 55w Bulb	Current Stock: 4 Our Price: $95.79
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
007021256	Power door lock ECU/relay Control Unit Deadlock Electr. C. U.	Current Stock: 1 Our Price: $413.16

Gaskets

PN	Item
001526489	Engine Gasket Set - Countach Quatro 5000 Carbureted Engine Gasket Kit - Countach Quatro 5000 Carbureted see pn 001526469 for seals	Avail to order Our Price: $2,106.81
001526469	Grommet and Oil Seals Set - Countach Quatro 5000 Carbureted Grommet and Oil Seals Set Countach Quatro 5000 Carbureted	Avail to order Our Price: $146.98
001529244	Countach 25th EURO - Gasket Kit Countach Europe Gasket Kit see PN 001529243 for seals kit	Avail to order Our Price: $2,114.05
001529243	Countach Grommet Kit - EURO/USA Countach Grommet Kit	Avail to order Our Price: $184.62

Ignition

PN	Item	Diagram
001630009	Spark Plug - 12mm Spark Plug		Avail to order Our Price: $36.53
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,801.84

Misc

PN	Item
006111300	Long Wiper Blade Long Wiper Blade	Avail to order Our Price: $50.47
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)	Current Stock: 1 Our Price: $18.73
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $255.57
002409895	NLA (No Longer Available) Reverse Switch	Avail to order Our Price: $120.91
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer	Avail to order Our Price: $141.76
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $825.35
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $230.95

Open All

Select Group and TAV

< Previous Next >

TAV: 051.00 - Door Frame

1989 Lamborghini Countach 25th USA Door Frame (051.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	007021110	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	6 req	*See Description
2	007021108	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
3	007021107	75 cm Velour Channel	4 req	Avail to order Our Price: $107.30
4	007021114	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
5	007021115	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
6	007021109	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
7	007021111	Side Velour Channel	4 req	Avail to order Our Price: $129.89
8	007021286	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
9	007021282	Rh Door Panel	1 req	Avail to order Our Price: $540.10
9	007021283	Lh Door Panel	1 req	Avail to order Our Price: $540.10
10	007021292	Speak.Net On Door Panel	2 req	Avail to order Our Price: $53.65
11	007021120	Door Pocket Assembly	1 req	Avail to order Our Price: $807.72
11	007021121	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
12	007021064	Trunk Moulding Unit	1 req	Avail to order Our Price: $514.66
12	007021065	Trunk Moulding Unit	1 req	Avail to order Our Price: $514.66
13	007021062	Rh Door Strik.	1 req	Avail to order Our Price: $268.76
13	007021063	Lh Door Striker	1 req	Avail to order Our Price: $268.76
14	007021146	Int.Panel Fix.Bracket	2 req	Avail to order Our Price: $72.98
15	007021035	Window Lift.Cable Plate	4 req	Avail to order Our Price: $80.77
16	007021041	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
17	007021034	Mov.Glass Support	2 req	Avail to order Our Price: $404.58
18	007021068	Bracket	1 req	Avail to order Our Price: $64.12
18	007021187	Rh Bracket	1 req	Avail to order Our Price: $64.12
19	007021060	Rh Door Ledge	1 req	Avail to order Our Price: $270.05
19	007021061	Lh Door Ledge	1 req	Avail to order Our Price: $270.05
20	007021167	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
21	007021069	Left Door Side Moulding Unit	1 req	Avail to order Our Price: $641.88
21	007021070	Right Door Side Moulding Unit.	1 req	Avail to order Our Price: $641.88
22	007021208	Shock Absorber SecurPin Assemb	2 req	Current Stock: 4 Our Price: $64.12
23	007021195	Shock Absorber Countach Door	2 req	Avail to order Our Price: $117.95
24	007021299	Spacer X Spring Fix.Pin	2 req	Avail to order Our Price: $18.61
25	007021287	Right Door Hinge Assembly	1 req	Avail to order Our Price: $1,210.86
25	007021288	Left Door Hinge Assembly	1 req	Avail to order Our Price: $1,600.02
26	007021271	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
26	007021272	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
27	007021092	Window Frame Molding	1 req	Avail to order Our Price: $641.88
27	007021093	Window Frame Molding	1 req	Avail to order Our Price: $641.88
28	008140867	Screw M8x42x17 Special	2 req	Current Stock: 8 Our Price: $2.43
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
