1989 Lamborghini Countach 25th USA Water Pump

Maintenance Parts:

Brakes

PN	Item	Diagram
003113912	Brake Pad Brake Pad Set NLA from Lamborghini warehouse - Secondary Source		Avail to order Our Price: $48.16

Common repairs and upgrades

PN	Item
007021195	Shock Absorber Countach Door Shock Absorber Without Internal Parts you may also need N02214812 x1 HEX.HEAD 007021193 x1 SHOCK ABSOR.FIX.PIN TO DO 007021208 x1 SHOCK ABSORBER SECURPIN A 008580801 x1 O-RING E 8 UNI 7535-75 N01118410 x1 HEX.HEAD CLAMPING NUT WHT002962 x3 WASHER	Current Stock: 7 Our Price: $126.40
007029005	Bonnet Lifter Bonnet Lifter	Current Stock: 4 Our Price: $114.79
007029006	Trunk Lifter Strut Trunk Lifter With Stab.	Current Stock: 4 Our Price: $89.03
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
002136948	Slave Clutch Cylinder Diablo / Countach Slave Clutch Cylinder	Current Stock: 5 Our Price: $134.59
001529245	COUNTACH 25th USA Gasket Kit Countach USA Gasket Kit See 001529243 for Grommets and seals	Avail to order Our Price: $2,229.46
002121294	CLUTCH MECHANISM Clutch Mechanism NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $7,012.07
002121675	COUNTACH THOWOUT BEARING Thrust Sleeve	Current Stock: 1 Our Price: $8,632.35

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Avail to order Our Price: $31.69
001628130	NLA (No Longer Available) Relay/Printed Board Box Unit. This unit is not longer available from the factory.	Avail to order Our Price: $1,232.16
002021140	WARM UP REGULATOR / HEAT REGULATOR WARM UP REGULATOR / HEAT REGULATOR	Avail to order Our Price: $1,729.45
002021141	Countach EFI Fuel Injection Pump Fuel Pump	Avail to order Our Price: $799.00
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability	Avail to order Our Price: $38.79
002021145	Accumulator Accumulators	Current Stock: 1 Our Price: $642.09
002021146	Cold Start Injector Starter Injector	Current Stock: 4 Our Price: $350.78
002021147	Countach Fuel Injector Injector	Current Stock: 11 Our Price: $318.32
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.47
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)	Avail to order Our Price: $872.47
002021173	Fuel Dampers Dampers	Avail to order Our Price: $518.84
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $339.85
002021174	Countach Injection EFI ECU ECU	Avail to order Our Price: $4,741.09
002021176	Lambda O2 Sensor Lambda Sensor *may need to use your existing connector	Current Stock: 4 Our Price: $862.00
002021176OE	Lambda Sensors Original Equipment Lambda Sensors	Current Stock: 2 Our Price: $126.18
006223973	Fuel Filter Cartridge Fuel Filter Cartridge	Avail to order Our Price: $53.23
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $70.48
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.00
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $782.61

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
006319225	55w Bulb foglight 55w Bulb	Current Stock: 4 Our Price: $102.88
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
007021256	Power door lock ECU/relay Control Unit Deadlock Electr. C. U.	Current Stock: 1 Our Price: $444.30

Gaskets

PN	Item
001526489	Engine Gasket Set - Countach Quatro 5000 Carbureted Engine Gasket Kit - Countach Quatro 5000 Carbureted see pn 001526469 for seals	Avail to order Our Price: $2,229.46
001526469	Grommet and Oil Seals Set - Countach Quatro 5000 Carbureted Grommet and Oil Seals Set Countach Quatro 5000 Carbureted	Avail to order Our Price: $156.06
001529243	Countach Grommet Kit - EURO/USA Countach Grommet Kit	Avail to order Our Price: $195.45
001529244	Countach 25th EURO - Gasket Kit Countach Europe Gasket Kit see PN 001529243 for seals kit	Avail to order Our Price: $2,236.90

Ignition

PN	Item	Diagram
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,876.01
001630009	Spark Plug - 12mm Spark Plug		Avail to order Our Price: $39.29

Misc

PN	Item
006111300	Long Wiper Blade Long Wiper Blade	Current Stock: 1 Our Price: $54.20
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98

Sensors

PN	Item
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $1,965.17
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $312.98
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $244.50
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.47
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Open All

Select Group and TAV

< Previous Next >

TAV: 010.00 - Water Pump - Therm

1989 Lamborghini Countach 25th USA Water Pump - Therm (010.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001121252	Outlet Hole Closing Flange	1 req	Avail to order Our Price: $29.51
2	001121254	Flange Seal	4 req	Avail to order Our Price: $9.30
3	WHT003165	TAP END STUD	4 req	Current Stock: 3 Our Price: $2.00
4	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
5	008200605	Simmon Nut for urama	4 req	Current Stock: 50 Our Price: $3.06
6	001722783	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
7	008832602	Clamp	2 req	Avail to order Our Price: $2.62
8	001722787	Lh Head Assembly Pipe	1 req	Avail to order Our Price: $44.89
9	001726817	Heater Pipe Union	1 req	Avail to order Our Price: $260.17
10	008300615	Stud 6x22 Uni 5911/8g/Z	3 req	Avail to order Our Price: $23.56
11	001726199	NLA (No Longer Available)	1 req	*See Description
12	WHT001197A	WASHER	7 req	Current Stock: 2 Our Price: $2.00
13	008200605	Simmon Nut for urama	3 req	Current Stock: 50 Our Price: $3.06
14	001721917	Thermostat Casing & Cover Seal	1 req	Current Stock: 5 Our Price: $7.60
15	001721862	Thermostat Casing Cover	1 req	Avail to order Our Price: $2,877.46
16	008400802	Copper Washer 8.4x16x1.5	1 req	Avail to order Our Price: $2.00
17	008100864	Special Screw M8x10	1 req	Avail to order Our Price: $3.80
18	WHT003080	Stainless Steel Clamp	4 req	Avail to order Our Price: $6.48
19	001728705	Three-Way Terminal Cover Conne	1 req	Avail to order Our Price: $243.02
20	001725623	COOLANT PUMP SLEEVE	1 req	Avail to order Our Price: $44.00
21	001727388	Seal 0.50 mm	3 req	Avail to order Our Price: $2.00
21	001727389	Seal 1 mm	3 req	Avail to order Our Price: $2.00
21	001727390	Seal 1.20 mm	3 req	Avail to order Our Price: $15.81
22	001605218	NLA (No longer Available to order)	1 req	*See Description
23	008700815	Screw	2 req	Current Stock: 18 Our Price: $2.00
24	001723758	Coolant Outlet Pipe Seal	1 req	Current Stock: 17 Our Price: $3.51
25	WHT003165	TAP END STUD	2 req	Current Stock: 3 Our Price: $2.00
26	WHT001197A	WASHER	2 req	Current Stock: 2 Our Price: $2.00
27	008200605	Simmon Nut for urama	2 req	Current Stock: 50 Our Price: $3.06
28	001801333	OIL & COOLANT TEMPERATURE THERMOMETER	1 req	Avail to order Our Price: $150.37
29	008401610	Annealed Copper Washer 16x22x0	1 req	Current Stock: 25 Our Price: $11.23
30	001724005	Thermostat /ManifoldHousing	1 req	Avail to order Our Price: $550.15
31	008300806	Stud M8x70 Uni 5911 9g Z	2 req	Avail to order Our Price: $6.49
32	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.80
33	WHT003022	NUT	2 req	Avail to order Our Price: $138.61
34	001723756	Coolant Outlet Pipe	1 req	Avail to order Our Price: $65.38
35	001728832	Pipe From Intermediate Joint T	1 req	Avail to order Our Price: $108.99
36	001724140	Seal Between Casing & Cover	1 req	Current Stock: 18 Our Price: $27.66
37	001724139	Coolant Pump Shaft	1 req	Avail to order Our Price: $492.01
38	008860302	Key	1 req	Current Stock: 1 Our Price: $6.79
39	008581801	O-Ring E 20 Uni 7435-75	1 req	Current Stock: 18 Our Price: $2.00
40	008574501	O-Ring I 42 Uni 3654	1 req	Current Stock: 7 Our Price: $2.01
41	008502008	BEARING	1 req	Current Stock: 7 Our Price: $14.37
42	001724136	Coolant Pump Casing	1 req	Avail to order Our Price: $3,046.93
43	008450602	NLA (No Longer Available)	0 req	*See Description
44	008740624	Dowel / BOLT	0 req	Current Stock: 1 Our Price: $6.87
45	001719683	COOLANT PUMP MECHANICAL FRONT	0 req	Avail to order Our Price: $453.25
46	001726343	Coolant Pump Washer	0 req	Avail to order Our Price: $457.71
47	001724138	Coolant Pump Impeller	0 req	Avail to order Our Price: $2,534.55
48	001728563	COOLANT PUMP COVER	0 req	Avail to order Our Price: $463.01
49	001723085	Rubber Hose From Union On Casi	0 req	Avail to order Our Price: $205.75
50	WHT001197A	WASHER	0 req	Current Stock: 2 Our Price: $2.00
51	008700624	Screw 5931 6x1x20 8gZg	0 req	Current Stock: 10 Our Price: $2.00
52	008608802	Ring 89 mm Or	0 req	Current Stock: 16 Our Price: $2.00
53	008612002	Oil Seal 20x35x7 mm	0 req	Current Stock: 2 Our Price: $4.18
54	001726334	Coolant Pump Rotor Plate	0 req	Current Stock: 1 Our Price: $333.22
55	001724142	Pump Rotor Shim	0 req	Avail to order Our Price: $104.07
56	WHT000768	SPRING WASHER	0 req	Current Stock: 17 Our Price: $2.09
57	008201005	M10 Uni 5721-65 Special Nu	0 req	Avail to order Our Price: $13.60
58	008401804	Annealed Copper Washer 18.2x30	0 req	Avail to order Our Price: $4.70
59	001723285	Union Drilled Screw On Pump	0 req	Avail to order Our Price: $35.86
60	001723284	Eye Union	0 req	Avail to order Our Price: $22.59
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
