1989 Lamborghini Countach 25th USA Lever Set (018.00)

Maintenance Parts:

Brakes

PN	Item	Diagram
003113912	Brake Pad Brake Pad Set NLA from Lamborghini warehouse - Secondary Source		Avail to order Our Price: $48.23

Common repairs and upgrades

PN	Item
007021195	Shock Absorber Countach Door Shock Absorber Without Internal Parts you may also need N02214812 x1 HEX.HEAD 007021193 x1 SHOCK ABSOR.FIX.PIN TO DO 007021208 x1 SHOCK ABSORBER SECURPIN A 008580801 x1 O-RING E 8 UNI 7535-75 N01118410 x1 HEX.HEAD CLAMPING NUT WHT002962 x3 WASHER	Current Stock: 7 Our Price: $126.61
007029005	Bonnet Lifter Bonnet Lifter	Current Stock: 4 Our Price: $114.94
007029006	Trunk Lifter Strut Trunk Lifter With Stab.	Current Stock: 4 Our Price: $89.17
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 20 Our Price: $86.47
002136948	Slave Clutch Cylinder Diablo / Countach Slave Clutch Cylinder	Current Stock: 5 Our Price: $134.36
002121294	CLUTCH MECHANISM Clutch Mechanism NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $7,000.52
002121675	COUNTACH THOWOUT BEARING Thrust Sleeve	Current Stock: 1 Our Price: $8,632.38
001529245	COUNTACH 25th USA Gasket Kit Countach USA Gasket Kit See 001529243 for Grommets and seals	Avail to order Our Price: $2,229.43

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 4 Our Price: $31.73
002021140	WARM UP REGULATOR / HEAT REGULATOR WARM UP REGULATOR / HEAT REGULATOR	Avail to order Our Price: $1,729.41
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)	Avail to order Our Price: $872.46
002021173	Fuel Dampers Dampers	Avail to order Our Price: $518.87
002021146	Cold Start Injector Starter Injector	Current Stock: 4 Our Price: $350.83
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.46
002021174	Countach Injection EFI ECU ECU	Avail to order Our Price: $4,741.13
002021141	Countach EFI Fuel Injection Pump Fuel Pump	Avail to order Our Price: $799.00
002021147	Countach Fuel Injector Injector	Current Stock: 11 Our Price: $318.36
002021176	Lambda O2 Sensor Lambda Sensor *may need to use your existing connector	Current Stock: 4 Our Price: $863.20
001628130	NLA (No Longer Available) Relay/Printed Board Box Unit. This unit is not longer available from the factory.	Avail to order Our Price: $1,232.20
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability	Avail to order Our Price: $38.79
002021145	Accumulator Accumulators	Current Stock: 1 Our Price: $642.13
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $339.85
002021176OE	Lambda Sensors Original Equipment Lambda Sensors	Current Stock: 2 Our Price: $126.18
006223973	Fuel Filter Cartridge Fuel Filter Cartridge	Avail to order Our Price: $53.19
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $782.63
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $70.48
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
006319225	55w Bulb foglight 55w Bulb	Current Stock: 4 Our Price: $102.88
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
007021256	Power door lock ECU/relay Control Unit Deadlock Electr. C. U.	Current Stock: 1 Our Price: $444.29

Gaskets

PN	Item
001526489	Engine Gasket Set - Countach Quatro 5000 Carbureted Engine Gasket Kit - Countach Quatro 5000 Carbureted see pn 001526469 for seals	Avail to order Our Price: $2,229.43
001526469	Grommet and Oil Seals Set - Countach Quatro 5000 Carbureted Grommet and Oil Seals Set Countach Quatro 5000 Carbureted	Avail to order Our Price: $156.07
001529244	Countach 25th EURO - Gasket Kit Countach Europe Gasket Kit see PN 001529243 for seals kit	Avail to order Our Price: $2,236.89
001529243	Countach Grommet Kit - EURO/USA Countach Grommet Kit	Avail to order Our Price: $195.43

Ignition

PN	Item	Diagram
001630009	Spark Plug - 12mm Spark Plug		Avail to order Our Price: $39.29
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,876.02

Misc

PN	Item
006111300	Long Wiper Blade Long Wiper Blade	Current Stock: 1 Our Price: $54.16
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98

Sensors

PN	Item
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $1,961.97
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $127.96
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.46
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $244.48
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.04
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $177.89

Open All

Select Group and TAV

< Previous Next >

TAV: 018.00 - Lever Set

1989 Lamborghini Countach 25th USA Lever Set (018.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002428311	Gear Lever Knob	1 req	Avail to order Our Price: $795.20
2	002432932	Gear Lever Knob Adapter	1 req	Avail to order Our Price: $90.63
3	002410440	NLA (No longer Available to order)	1 req	*See Description
4	008700635	Gear Selector Screw M6x1x30	1 req	Avail to order Our Price: $26.74
5	002410634	NLA (No Longer Available)	1 req	*See Description
6	002403369	Reverse Lever Lock Spring	1 req	Avail to order Our Price: $38.51
7	WHT001197A	WASHER	1 req	Current Stock: 2 Our Price: $2.00
8	N01118312	HEX.HEAD CLAMPING NUT	1 req	Avail to order Our Price: $2.14
9	002403702	GEAR LEVER GUIDE BUSHING	2 req	Avail to order Our Price: $76.24
10	002409875	Gear Lever Ball	1 req	Avail to order Our Price: $207.22
11	008700634	Gear Selector Fastening Screw	3 req	Avail to order Our Price: $42.59
12	002409437	Gear Lever Shift Ring	1 req	Avail to order Our Price: $520.33
13	008700506	Screw Knip 4.8x16din7971 Black	4 req	Current Stock: 4 Our Price: $2.00
14	002409438	Lever Outer Boot Ring	1 req	Avail to order Our Price: $16.63
15	002409922	Gearbox Boot Ring	1 req	Avail to order Our Price: $103.76
16	002412243	Plate	4 req	Current Stock: 1 Our Price: $3.99
17	002410638	Gear Mount Outer Boot	1 req	Avail to order Our Price: $78.52
18	002410637	Lever Inner Boot Ring	1 req	Avail to order Our Price: $22.56
19	002412784	GEAR LEVER UPPER BOOT	1 req	Avail to order Our Price: $72.83
20	002412670	Transmission Boot Snap Ring	1 req	Avail to order Our Price: $28.30
21	002410636	Gear Mount Inner Boot	2 req	Avail to order Our Price: $84.70
22	002412671	Gearbox Cap Retaining Segment	2 req	Avail to order Our Price: $26.74
23	002409896	Rod Retaining Ball Sleeve	2 req	Avail to order Our Price: $364.55
24	002423993	Ball Spring Pad	3 req	Avail to order Our Price: $5.25
25	86311249	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	3 req	*See Description
26	N10439201	Ball Rb 7.938/11 RivSkf	4 req	Current Stock: 19 Our Price: $2.00
27	002407979	Gearbox Side Pin Rod	2 req	Avail to order Our Price: $35.88
28	002409897	Central Pin Stop Rod	1 req	Avail to order Our Price: $308.46
29	002422165	2nd/3rd Speed Rod	1 req	Avail to order Our Price: $1,107.76
30	002422164	1st Speed/Reverse Rod	1 req	Avail to order Our Price: $990.00
31	002401765	Gear Lever Ball Bushing	1 req	Avail to order Our Price: $20.32
32	002422166	4th/5th Speed Rod	1 req	Avail to order Our Price: $958.69
33	002420397	4th/5th Speed Fork	1 req	Avail to order Our Price: $752.93
34	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
35	WHT002950	BOLT	4 req	Avail to order Our Price: $116.33
36	008200806	M8 Uni 5588/8g/Z Nut	1 req	Current Stock: 25 Our Price: $2.00
37	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $2.00
38	002420396	2nd/3rd Speed Fork	1 req	Avail to order Our Price: $928.84
39	002420395	1st Speed/Reverse Fork	1 req	Avail to order Our Price: $739.51
40	002403246	Gearbox Shaft Ball Spring	1 req	Avail to order Our Price: $6.71
41	002403245	Gearbox Shaft Ball Bushing	1 req	Avail to order Our Price: $62.53
42	002402934	Gear Lever Screw	1 req	Avail to order Our Price: $33.74
43	002420394	Rod Centring Pin	1 req	Avail to order Our Price: $184.85
44	002410314	Gear Lever Bracket	1 req	Avail to order Our Price: $639.64
45	008403302	Gear Lever Spring Washer	0 req	Avail to order Our Price: $17.89
46	002410451	Gear Lever Return Spring	0 req	Avail to order Our Price: $56.69
47	008402601	Flat Washer D.26x3.3x40 3 th.	0 req	Current Stock: 6 Our Price: $27.71
47	008402610	Flat Washer D.26x3.3x40 3.25 t	0 req	Avail to order Our Price: $26.64
47	008402611	Flat Washer D.26x3.3x40 3.50 t	0 req	Avail to order Our Price: $26.64
48	WHT003057	O-RING	0 req	Current Stock: 11 Our Price: $2.00
49	008602101	Ring 22 mm Or	0 req	Current Stock: 2 Our Price: $2.92
50	008402602	Washer 26x35x2-2.1-2.2-2.3	0 req	Current Stock: 6 Our Price: $12.93
51	008582601	O-Ring E 26 Uni 7435-75	0 req	Avail to order Our Price: $6.81
52	002409791	Gearbox Rod Upper Shim	0 req	Avail to order Our Price: $430.87
53	002409887	Gear Lever	0 req	Avail to order Our Price: $985.53
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
