1989 Lamborghini Countach 25th USA Camshafts and Valves (002.00)

Maintenance Parts:

Brakes

PN	Item	Diagram
003113912	Brake Pad Brake Pad Set NLA from Lamborghini warehouse - Secondary Source		Avail to order Our Price: $48.23

Common repairs and upgrades

PN	Item
007021195	Shock Absorber Countach Door Shock Absorber Without Internal Parts you may also need N02214812 x1 HEX.HEAD 007021193 x1 SHOCK ABSOR.FIX.PIN TO DO 007021208 x1 SHOCK ABSORBER SECURPIN A 008580801 x1 O-RING E 8 UNI 7535-75 N01118410 x1 HEX.HEAD CLAMPING NUT WHT002962 x3 WASHER	Current Stock: 7 Our Price: $126.61
007029005	Bonnet Lifter Bonnet Lifter	Current Stock: 4 Our Price: $114.94
007029006	Trunk Lifter Strut Trunk Lifter With Stab.	Current Stock: 4 Our Price: $89.17
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 20 Our Price: $86.47
002136948	Slave Clutch Cylinder Diablo / Countach Slave Clutch Cylinder	Current Stock: 5 Our Price: $134.36
002121294	CLUTCH MECHANISM Clutch Mechanism NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $7,000.52
002121675	COUNTACH THOWOUT BEARING Thrust Sleeve	Current Stock: 1 Our Price: $8,632.38
001529245	COUNTACH 25th USA Gasket Kit Countach USA Gasket Kit See 001529243 for Grommets and seals	Avail to order Our Price: $2,229.43

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 4 Our Price: $31.73
002021140	WARM UP REGULATOR / HEAT REGULATOR WARM UP REGULATOR / HEAT REGULATOR	Avail to order Our Price: $1,729.41
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)	Avail to order Our Price: $872.46
002021173	Fuel Dampers Dampers	Avail to order Our Price: $518.87
002021146	Cold Start Injector Starter Injector	Current Stock: 4 Our Price: $350.83
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.46
002021174	Countach Injection EFI ECU ECU	Avail to order Our Price: $4,741.13
002021141	Countach EFI Fuel Injection Pump Fuel Pump	Avail to order Our Price: $799.00
002021147	Countach Fuel Injector Injector	Current Stock: 11 Our Price: $318.36
002021176	Lambda O2 Sensor Lambda Sensor *may need to use your existing connector	Current Stock: 4 Our Price: $863.20
001628130	NLA (No Longer Available) Relay/Printed Board Box Unit. This unit is not longer available from the factory.	Avail to order Our Price: $1,232.20
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability	Avail to order Our Price: $38.79
002021145	Accumulator Accumulators	Current Stock: 1 Our Price: $642.13
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $339.85
002021176OE	Lambda Sensors Original Equipment Lambda Sensors	Current Stock: 2 Our Price: $126.18
006223973	Fuel Filter Cartridge Fuel Filter Cartridge	Avail to order Our Price: $53.19
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $782.63
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $70.48
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
006319225	55w Bulb foglight 55w Bulb	Current Stock: 4 Our Price: $102.88
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
007021256	Power door lock ECU/relay Control Unit Deadlock Electr. C. U.	Current Stock: 1 Our Price: $444.29

Gaskets

PN	Item
001526489	Engine Gasket Set - Countach Quatro 5000 Carbureted Engine Gasket Kit - Countach Quatro 5000 Carbureted see pn 001526469 for seals	Avail to order Our Price: $2,229.43
001526469	Grommet and Oil Seals Set - Countach Quatro 5000 Carbureted Grommet and Oil Seals Set Countach Quatro 5000 Carbureted	Avail to order Our Price: $156.07
001529244	Countach 25th EURO - Gasket Kit Countach Europe Gasket Kit see PN 001529243 for seals kit	Avail to order Our Price: $2,236.89
001529243	Countach Grommet Kit - EURO/USA Countach Grommet Kit	Avail to order Our Price: $195.43

Ignition

PN	Item	Diagram
001630009	Spark Plug - 12mm Spark Plug		Avail to order Our Price: $39.29
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,876.02

Misc

PN	Item
006111300	Long Wiper Blade Long Wiper Blade	Current Stock: 1 Our Price: $54.16
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98

Sensors

PN	Item
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $1,961.97
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $127.96
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.46
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $244.48
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.04
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $177.89

Open All

Select Group and TAV

< Previous Next >

TAV: 002.00 - Camshafts and Valves

1989 Lamborghini Countach 25th USA Camshafts and Valves (002.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001220848	Lh Exhaust Head Camshaft	1 req	Avail to order Our Price: $2,876.02
2	001220847	Lh Intake Head Camshaft	1 req	Avail to order Our Price: $2,281.06
3	001221996	This item is no longer available	2 req
3	001227248	Timing Chain	2 req	Current Stock: 1 Our Price: $246.80
4	001201964	Dowel	4 req	Avail to order Our Price: $96.75
5	001221296	Oil Breather Rotor Assembly	1 req	Avail to order Our Price: $438.46
6	001219762	Screw Lock Plate	4 req	Avail to order Our Price: $51.34
7	001220990	SEE PN: 008701031 AND 001237892	3 req	Avail to order Our Price: $40.94
8	001724139	Coolant Pump Shaft	1 req	Avail to order Our Price: $492.03
9	001219424	Drive Spindle Guide Gear	1 req	Avail to order Our Price: $736.50
10	001220845	Rh Intake Head Camshaft	1 req	Avail to order Our Price: $2,876.02
11	008522202	NLA (No Longer Available)	4 req	*See Description
12	001222085	Camshaft Drive End	1 req	Avail to order Our Price: $101.42
13	001220846	Rh Exhaust Head Camshaft	1 req	Avail to order Our Price: $2,876.02
14	001220849	Camshaft Driving Gear	4 req	Avail to order Our Price: $323.52
15	001219761	Washer	3 req	Avail to order Our Price: $108.23
16	001220989	Camshaft & Drive Gear Fastenin	1 req	Avail to order Our Price: $371.94
17	07M109320	Valve Adjustment Shim 3.25 mm	48 req	Current Stock: 51 Our Price: $12.04
17	07M109320A	Valve Adjustment Shim 3.30 mm	48 req	Current Stock: 67 Our Price: $12.04
17	07M109320B	Valve Adjustment Shim 3.35 mm	48 req	Current Stock: 60 Our Price: $59.91
17	07M109320C	Valve Adjustment Shim 3.40 mm	48 req	Current Stock: 55 Our Price: $56.71
17	07M109320D	Valve Adjustment Shim 3.45 mm	48 req	Current Stock: 35 Our Price: $12.04
17	07M109320E	Valve Adjustment Shim 3.50 mm	48 req	Current Stock: 58 Our Price: $59.91
17	07M109320F	Valve Adjustment Shim 3.55	48 req	Current Stock: 3 Our Price: $12.04
17	07M109320G	Valve Adjustment Shim 3.60 mm	48 req	Current Stock: 1 Our Price: $59.91
17	07M109320H	Valve Adjustment Shim 3.65 mm	48 req	Current Stock: 6 Our Price: $62.24
17	07M109320J	Valve Adjustment Shim 3.70	48 req	Current Stock: 6 Our Price: $59.91
17	07M109320K	Valve Adjustment Shim 3.75 mm	48 req	Avail to order Our Price: $59.91
17	07M109320L	Valve Adjustment Shim 3.80 mm	48 req	Current Stock: 56 Our Price: $59.91
17	07M109320M	Valve Adjustment Shim 3.85	48 req	Current Stock: 24 Our Price: $12.04
17	07M109320N	Valve Adjustment Shim 3.90 mm	48 req	Current Stock: 32 Our Price: $59.91
17	07M109320P	Valve Adjustment Shim 3.95 mm	48 req	Current Stock: 29 Our Price: $59.91
17	07M109320Q	Valve Adjustment Shim 4.00 mm	48 req	Current Stock: 43 Our Price: $88.17
17	07M109320R	Valve Adjustment Shim 4.05 mm	48 req	Current Stock: 25 Our Price: $12.04
17	07M109320S	Valve Adjustment Shim 4.10 mm	48 req	Current Stock: 43 Our Price: $59.91
17	07M109320T	Valve Adjustment Shim 4.15 mm	48 req	Current Stock: 40 Our Price: $12.04
17	07M109320AA	Valve Adjustment Shim 4.20 mm	48 req	Current Stock: 59 Our Price: $12.04
17	07M109320AB	Valve Adjustment Shim 4.25 mm	48 req	Current Stock: 83 Our Price: $12.04
17	07M109320AC	Valve Adjustment Shim 4.30 mm	48 req	Current Stock: 50 Our Price: $12.04
17	07M109320AD	Valve Adjustment Shim 4.35 mm	48 req	Current Stock: 70 Our Price: $12.04
17	07M109320AE	Valve Adjustment Shim 4.40 mm	48 req	Current Stock: 73 Our Price: $59.91
17	07M109320AF	Valve Adjustment Shim 4.45 mm	48 req	Current Stock: 58 Our Price: $12.04
17	07M109320AG	Valve Adjustment Shim 4.50 mm	48 req	Current Stock: 62 Our Price: $12.04
17	07M109320AH	Valve Adjustment Shim 4.55 mm	48 req	Current Stock: 69 Our Price: $12.04
17	07M109320AJ	Valve Adjustment Shim 4.60	48 req	Current Stock: 17 Our Price: $12.04
17	07M109320AK	Valve Adjustment Shim 4.65	48 req	Current Stock: 28 Our Price: $12.04
17	07M109320AL	Valve Adjustment Shim 4,70 mm	48 req	Current Stock: 33 Our Price: $12.04
18	07M109309	Valve Bowl	0 req	Avail to order Our Price: $39.42
19	001220843	Valve Seal Cotter OnPlate	0 req	Avail to order Our Price: $8.95
20	07M109641	Spring Upper Washer	0 req	Avail to order Our Price: $20.59
21	07M109623A	Valve Spring	0 req	Avail to order Our Price: $20.59
22	07M109642	Spring Lower Washer	0 req	Avail to order Our Price: $19.03
23	07M109675	Valve Guide Rubber Pad	0 req	Current Stock: 51 Our Price: $16.90
24	001222483	Intake/Exhaust ValveGuide Stop	0 req	Avail to order Our Price: $35.98
25	001222476	Exhaust Valve Guide - QV EFI	0 req	Avail to order Our Price: $84.99
26	001220823	Exhaust Valve Seat	0 req	Current Stock: 2 Our Price: $19.64
27	001220819	Exhaust Valve	0 req	Avail to order Our Price: $1,595.32
28	001219428	Guide Gear Shaft	0 req	Avail to order Our Price: $535.21
29	001219421	Guide Gear	0 req	Avail to order Our Price: $706.74
30	008604201	Ring 43 mm Or	0 req	Current Stock: 9 Our Price: $2.00
31	001200336	Cover	0 req	Avail to order Our Price: $421.92
32	008300613	Stud M6x14 Uni 5911 8g/Z	0 req	Avail to order Our Price: $5.74
33	008200605	Simmon Nut for urama	0 req	Current Stock: 50 Our Price: $3.10
34	008401813	Washer	0 req	Avail to order Our Price: $21.39
35	008803001	Bushing 30x34x23 mm	0 req	Avail to order Our Price: $77.69
36	001219423	Tightener Gear	0 req	Avail to order Our Price: $177.46
37	001219425	Tightener Pin	0 req	Avail to order Our Price: $243.80
38	008604401	Ring 44 mm Or	0 req	Current Stock: 4 Our Price: $2.00
39	001219426	Tightener AdjustmentBracket	0 req	Avail to order Our Price: $761.88
40	008300613	Stud M6x14 Uni 5911 8g/Z	0 req	Avail to order Our Price: $5.74
41	008200605	Simmon Nut for urama	0 req	Current Stock: 50 Our Price: $3.10
42	008601702	Ring 18 mm Or	0 req	Current Stock: 7 Our Price: $3.70
43	001200343	Distribution Adjustment Dowel	0 req	Avail to order Our Price: $31.12
44	001202447	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	0 req	*See Description
45	001200345	Tightener Dowel Check Washer	0 req	Avail to order Our Price: $88.39
46	008411303	Snap Ring 21x13x2.5 Uni 175 1	0 req	Current Stock: 6 Our Price: $3.31
47	008201213	12 Uni 210 8g Nut	0 req	Avail to order Our Price: $6.22
48	008521704	Bearing	0 req	Avail to order Our Price: $114.55
49	001209449	Spacer	0 req	Avail to order Our Price: $109.40
50	001219211	Reducing Gear	0 req	Avail to order Our Price: $784.24
51	008502006	Bearing	0 req	Avail to order Our Price: $50.95
52	001209448	Bushing	0 req	Avail to order Our Price: $154.32
53	008575201	O-Ring I 52 Uni 3654	0 req	Current Stock: 22 Our Price: $2.00
54	008601801	Ring 19 mm Or	0 req	Avail to order Our Price: $12.41
55	001209447	Reducer Gear Shaft	0 req	Avail to order Our Price: $809.62
56	008700613	Screw M6x14 Uni 5933/8g/Zb	0 req	Avail to order Our Price: $2.00
57	001222475	Intake Valve Guide - QV EFI	24 req	Avail to order Our Price: $84.99
58	001220822	Intake Valve Seat	24 req	Avail to order Our Price: $71.18
59	001220818	Intake Valve	24 req	Avail to order Our Price: $435.45
60	001227249	Chain Joint Assembly	2 req	Avail to order Our Price: $76.24
61	07M109633A	Inner Valve Spring	48 req	Avail to order Our Price: $6.70
62	008600703	Ring 7x1.50 mm Or	24 req	Avail to order Our Price: $2.00
63	001219761	Washer	1 req	Avail to order Our Price: $108.23
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
