1989 Lamborghini Countach 25th USA Pedal (027.00)

Maintenance Parts:

Brakes

PN	Item	Diagram
003113912	Brake Pad Brake Pad Set NLA from Lamborghini warehouse - Secondary Source		Avail to order Our Price: $48.16

Common repairs and upgrades

PN	Item
007021195	Shock Absorber Countach Door Shock Absorber Without Internal Parts you may also need N02214812 x1 HEX.HEAD 007021193 x1 SHOCK ABSOR.FIX.PIN TO DO 007021208 x1 SHOCK ABSORBER SECURPIN A 008580801 x1 O-RING E 8 UNI 7535-75 N01118410 x1 HEX.HEAD CLAMPING NUT WHT002962 x3 WASHER	Current Stock: 7 Our Price: $126.40
007029005	Bonnet Lifter Bonnet Lifter	Current Stock: 4 Our Price: $114.79
007029006	Trunk Lifter Strut Trunk Lifter With Stab.	Current Stock: 4 Our Price: $89.03
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
002136948	Slave Clutch Cylinder Diablo / Countach Slave Clutch Cylinder	Current Stock: 5 Our Price: $134.59
001529245	COUNTACH 25th USA Gasket Kit Countach USA Gasket Kit See 001529243 for Grommets and seals	Avail to order Our Price: $2,229.46
002121294	CLUTCH MECHANISM Clutch Mechanism NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $7,012.07
002121675	COUNTACH THOWOUT BEARING Thrust Sleeve	Current Stock: 1 Our Price: $8,632.35

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Avail to order Our Price: $31.69
001628130	NLA (No Longer Available) Relay/Printed Board Box Unit. This unit is not longer available from the factory.	Avail to order Our Price: $1,232.16
002021140	WARM UP REGULATOR / HEAT REGULATOR WARM UP REGULATOR / HEAT REGULATOR	Avail to order Our Price: $1,729.45
002021141	Countach EFI Fuel Injection Pump Fuel Pump	Avail to order Our Price: $799.00
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability	Avail to order Our Price: $38.79
002021145	Accumulator Accumulators	Current Stock: 1 Our Price: $642.09
002021146	Cold Start Injector Starter Injector	Current Stock: 4 Our Price: $350.78
002021147	Countach Fuel Injector Injector	Current Stock: 11 Our Price: $318.32
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.47
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)	Avail to order Our Price: $872.47
002021173	Fuel Dampers Dampers	Avail to order Our Price: $518.84
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $339.85
002021174	Countach Injection EFI ECU ECU	Avail to order Our Price: $4,741.09
002021176	Lambda O2 Sensor Lambda Sensor *may need to use your existing connector	Current Stock: 4 Our Price: $862.00
002021176OE	Lambda Sensors Original Equipment Lambda Sensors	Current Stock: 2 Our Price: $126.18
006223973	Fuel Filter Cartridge Fuel Filter Cartridge	Avail to order Our Price: $53.23
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $70.48
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.00
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $782.61

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
006319225	55w Bulb foglight 55w Bulb	Current Stock: 4 Our Price: $102.88
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
007021256	Power door lock ECU/relay Control Unit Deadlock Electr. C. U.	Current Stock: 1 Our Price: $444.30

Gaskets

PN	Item
001526489	Engine Gasket Set - Countach Quatro 5000 Carbureted Engine Gasket Kit - Countach Quatro 5000 Carbureted see pn 001526469 for seals	Avail to order Our Price: $2,229.46
001526469	Grommet and Oil Seals Set - Countach Quatro 5000 Carbureted Grommet and Oil Seals Set Countach Quatro 5000 Carbureted	Avail to order Our Price: $156.06
001529243	Countach Grommet Kit - EURO/USA Countach Grommet Kit	Avail to order Our Price: $195.45
001529244	Countach 25th EURO - Gasket Kit Countach Europe Gasket Kit see PN 001529243 for seals kit	Avail to order Our Price: $2,236.90

Ignition

PN	Item	Diagram
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,876.01
001630009	Spark Plug - 12mm Spark Plug		Avail to order Our Price: $39.29

Misc

PN	Item
006111300	Long Wiper Blade Long Wiper Blade	Current Stock: 1 Our Price: $54.20
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98

Sensors

PN	Item
004526663	Cabin Air Temperature Sensor Temperature Sensor	Avail to order Our Price: $1,965.17
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $312.98
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $244.50
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.47
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Open All

Select Group and TAV

< Previous Next >

TAV: 027.00 - Pedal

1989 Lamborghini Countach 25th USA Pedal (027.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	004228343	This item is no longer available	1 req
1	008401018	Pump Fitting Washer	2 req	Avail to order Our Price: $2.00
2	004119287	Brake Booster Attachment Plate	1 req	Avail to order Our Price: $207.99
3	004220287	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
4	004219984	Master Clutch Cylinder	1 req	Avail to order Our Price: $350.78
5	004213632	Clutch Cylinder Cover	2 req	Avail to order Our Price: $9.92
6	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
7	003219278	DISCONTINUED - NLA - CONTACT US	2 req	*See Description
8	008100822	Screw M8x60 Uni 57378g/Zd	2 req	Avail to order Our Price: $6.87
9	410721213	Brake Cylinder Control Fork	1 req	Current Stock: 1 Our Price: $67.75
10	004210745	Clutch Pedal Fork Pin	3 req	Avail to order Our Price: $42.57
11	008200811	M8 Uni 5589/8g/ZdNut	1 req	Avail to order Our Price: $6.79
12	004207085	Brake Cylinder Pin Stopper	4 req	Avail to order Our Price: $85.47
13	004210742	Clutch Pedal Bracket	1 req	Avail to order Our Price: $1,647.46
14	004210744	Clutch Pedal Mount Pin	1 req	Avail to order Our Price: $93.78
15	008801501	Bushing 15x17x25 mm	6 req	Avail to order Our Price: $21.69
16	004210746	Clutch Gear Lever Mount Pin	1 req	Avail to order Our Price: $89.31
17	004210747	Clutch Pedal Link Rod	2 req	Avail to order Our Price: $51.22
18	008800803	Bushing 8x12x8 mm	5 req	Avail to order Our Price: $7.08
19	004210743	Clutch Pedal Transmission Leve	1 req	Avail to order Our Price: $302.66
20	N10738501	Elastic Pin 3x32 Din1481	3 req	Current Stock: 9 Our Price: $2.00
21	004228348	Clutch Pedal	1 req	Avail to order Our Price: $390.62
22	0042005210	Pedal Cover (Clutch or Brake)	1 req	Avail to order Our Price: $80.51
23	004213407	Clutch Pedal Return Spring	1 req	Avail to order Our Price: $50.10
24	410721381	Brake Clutch Pedal Stop	2 req	Avail to order Our Price: $91.26
25	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
26	004210834	Brake/Clutch Pedal Adjustment	2 req	Avail to order Our Price: $5.22
27	N90179103	WASHER	12 req	Current Stock: 5 Our Price: $2.00
28	008200804	Nut	8 req	Current Stock: 7 Our Price: $2.00
29	004213618	Brake Pedal Bracket	1 req	Avail to order Our Price: $827.45
30	004213406	Brake Pedal Return Spring	1 req	Avail to order Our Price: $76.19
31	004219271	NLA (No Longer Available)	1 req	*See Description
32	008201021	Power Brake MountingNut	4 req	Avail to order Our Price: $14.09
33	008201014	M10x1x6 Uni 5589/5s/Z Nut	1 req	Current Stock: 1 Our Price: $7.16
34	004219276	Brake Cylinder Control Fork	1 req	Avail to order Our Price: $292.96
35	004208714	Brake & Clutch Cylinder Pin	1 req	Avail to order Our Price: $428.06
36	004222887	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
37	004228350	Brake Pedal	1 req	Avail to order Our Price: $390.62
38	0042005210	Pedal Cover (Clutch or Brake)	1 req	Avail to order Our Price: $80.51
39	008100651	Special Screw M6x52	1 req	Avail to order Our Price: $6.87
40	004223260	Accelerator Pedal Adjustment M	1 req	Avail to order Our Price: $2.00
41	001612232	Union Nut	1 req	Avail to order Our Price: $8.13
42	008410605	Corrugated Washer D 6	1 req	Avail to order Our Price: $2.91
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
