TAV: 006.00 - Oil Pump, Oil Circuit

1989 Lamborghini Countach 25th USA Oil Pump, Oil Circuit (006.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	001529243	Countach Grommet Kit - EURO/USA	1 req	Avail to order Our Price: $184.62
0	001529244	Countach 25th EURO - Gasket Kit	1 req	Avail to order Our Price: $2,114.05
1	008700608	Screw 6x40 Uni 5931/8g/Z	4 req	Avail to order Our Price: $2.00
2	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
3	001521894	Low Pressure Oil Pump Casing	1 req	Avail to order Our Price: $4,611.81
4	008402007	Annealed Copper Washer D.21x27	3 req	Current Stock: 8 Our Price: $2.00
5	001525429	Nipple On Low Pressure Oil Pum	1 req	Avail to order Our Price: $19.02
6	008801609	Driven Gear Bushing	1 req	Avail to order Our Price: $25.81
7	001508565	NLA (No Longer Available)	1 req	*See Description
8	001510474	Oil Thermostat Union	2 req	Avail to order 1 Used Available Our Price: $130.90
9	008402604	Copper Washer 26.25x35x1.5	2 req	Current Stock: 21 Our Price: $4.01
10	008401408	Annealed Copper Washer 21x14x1	1 req	Current Stock: 41 Our Price: $2.00
11	001806009	Oil Pressure Transmission Redu	1 req	Avail to order Our Price: $28.95
14	001520320	Oil Pump Outer Rotor	1 req	Avail to order Our Price: $431.74
15	001520325	Oil Pump Inner Rotor	1 req	Avail to order Our Price: $431.74
16	001521893	Low Pressure Oil Pump Casing B	1 req	Avail to order Our Price: $423.16
17	008605301	Ring 54 mm Or	1 req	Current Stock: 1 Our Price: $2.00
18	001522086	Inner Rotor Shaft	1 req	Avail to order Our Price: $122.67
19	001520335	Cross Coupling	1 req	Avail to order Our Price: $30.88
20	001528273	Hose On Low PressureOil Pump	1 req	Avail to order Our Price: $384.56
21	001500898	Pump Seal	1 req	Avail to order Our Price: $30.60
22	001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa	1 req	Avail to order Our Price: $81.81
23	001522118	Oil Filter Bracket	1 req	Avail to order Our Price: $667.62
24	001523587	Threaded Bushing	1 req	Avail to order Our Price: $34.89
28	001522505	Eye Fixing Drilled Screw	1 req	Avail to order Our Price: $19.02
29	001528226	Pipe From Oil Low Pressure Pum	1 req	Avail to order Our Price: $263.05
30	001528230	Oil Return Hose To Sump	1 req	Avail to order Our Price: $300.93
32	001528232	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
33	001528252	Pipe From Oil FilterTo Crankca	1 req	Avail to order Our Price: $758.74
34	008602304	O-RING	2 req	Avail to order Our Price: $9.56
35	N01152427	WASHER	4 req	Avail to order Our Price: $2.00
36	N01021626	HEXAGON HEAD BOLT	2 req	Current Stock: 8 Our Price: $2.00
37	001528242	Pipe From Pump To Filter	1 req	Avail to order Our Price: $1,135.22
39	001509930	Engine Output Shaft	1 req	Avail to order Our Price: $644.75
39	001519442	Output Shaft From Engine	1 req	Avail to order Our Price: $1,204.72
40	008860502	Tab 5x5x18	1 req	Current Stock: 9 Our Price: $2.00
40	410109445	Tab 15x5x5 Uni 92/C40	1 req	Current Stock: 9 Our Price: $2.00
41	008860602	Tab 6x6x30 Unim 92	0 req	Current Stock: 6 Our Price: $44.45
42	008300623	Stud M6x18 Uni 5917 8g Zd	0 req	Avail to order Our Price: $18.16
43	001509933	Oil Pump Cover	0 req	Avail to order Our Price: $433.17
44	001509938	Idle Gear Pin	0 req	Avail to order Our Price: $47.53
45	001504499	Idle Gear	0 req	Avail to order Our Price: $3,127.64
45	001519445	Oil Pump Idle Gear	0 req	Avail to order Our Price: $446.03
46	001519035	Oil Pump Casing	0 req	Avail to order Our Price: $8,123.15
46	001519443	Oil Pump Casing	0 req	Avail to order Our Price: $2,599.12
47	008700608	Screw 6x40 Uni 5931/8g/Z	0 req	Avail to order Our Price: $2.00
48	008100615	Screw M6x50 Uni 5737/8g	0 req	Avail to order Our Price: $6.29
49	008613002	Oil Seal 30x40x7 mm	0 req	Avail to order Our Price: $3.79
50	001509939	Oil Seal Gasket	0 req	Avail to order Our Price: $9.65
51	001528051	Oil Seal Housing	0 req	Avail to order Our Price: $328.70
52	001513746	Compressor Drive Pulley	0 req	Avail to order Our Price: $706.62
53	008410603	Washer D.6.4 Uni 1751/Zd	0 req	Avail to order Our Price: $2.00
54	008100625	Screw M6x16 Uni 5739/8g/Z	0 req	Avail to order Our Price: $130.24
55	N01100637	HEX.NUT	0 req	Current Stock: 18 Our Price: $2.00
56	008410606	Washer 7x3.5x18 Uni 5961-67	0 req	Avail to order Our Price: $2.65
57	008300625	Stud M6x20 Uni 5917 8g Zd	0 req	Avail to order Our Price: $18.16
58	WHT003079	Reference Pin 8h7x6.25x10	0 req	Avail to order Our Price: $33.17
59	008522401	Needle Bearing	0 req	Avail to order Our Price: $82.83
60	001509932	Oil Pump Drive Gear	0 req	Avail to order Our Price: $247.32
60	001519444	Oil Pump Drive Gear	0 req	Avail to order Our Price: $348.82
61	001520345	Oil Radiator	0 req	Avail to order Our Price: $625.53
64	001528233	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	0 req	*See Description
65	001500927	Oil Pressure Valve Spring	0 req	Avail to order Our Price: $14.66
66	WHT003079	Reference Pin 8h7x6.25x10	0 req	Avail to order Our Price: $33.17
67	001519446	Pressure Piston	0 req	Avail to order Our Price: $77.77
68	008401804	Annealed Copper Washer 18.2x30	0 req	Current Stock: 1 Our Price: $4.36
69	001509934	Oil Pressure Valve Plug	0 req	Avail to order Our Price: $335.95
70	008700612	Screw M6x25 Uni 5931/8g/Zd	0 req	Avail to order Our Price: $2.00
71	WHT001197A	WASHER	0 req	Current Stock: 2 Our Price: $2.00
72	008700624	Screw 5931 6x1x20 8gZg	0 req	Current Stock: 10 Our Price: $2.00
73	008402003	Washer	0 req	Avail to order Our Price: $14.52
74	008502001	Bearing	0 req	Avail to order Our Price: $40.39
75	008700610	Screw 6x22 Uni 5933/8g/Zd	0 req	Current Stock: 36 Our Price: $2.00
76	001527418	Pulley On Oil Pump Shaft	0 req	Avail to order Our Price: $378.84
77	008401801	Tempered Flat Washer18x30x2 C4	0 req	Avail to order Our Price: $24.81
78	008251801	M18x1.5x28 Self-Locking Ring N	1 req	Avail to order Our Price: $39.10
79	007011280	Air Duct	1 req	Avail to order Our Price: $86.35
80	007011281	Bulkhead	1 req	Avail to order Our Price: $80.77
81	007090093	This item is no longer available	1 req
82	007090101	Radiator Air Conv. Seal	1 req	Avail to order Our Price: $55.25
82	007090102	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
