2016 AVENTADOR SV LP750-4 ROADSTER - CANADA

Group :

Tav :

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 8 Our Price: $61.26
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 4 Our Price: $58.32
G052529A2	TRANSMISSION FLUID TRANSMISSION FLUID	Current Stock: 14 Our Price: $71.47

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 9 Our Price: $201.60

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 2 Our Price: $157.26

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $99.97
470905619C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $100.13

Misc

PN	Item
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $61.49
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $79.44
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 22 Our Price: $153.21
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73

Tools and Tookits

PN	Item
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Avail to order Our Price: $611.31
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $434.20
69195290	TOOL KIT FOR REMOVING THE GRILLE TOOL KIT FOR REMOVING THE GRILLE BUMPER NET TOOL	Avail to order Our Price: $474.62
61195080	TOOL FOR TOP DEAD CENTER LP700 TOP DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $314.66
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 91 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 701.02.00 - TRIM FRAME FRONT PART

2016 Lamborghini AVENTADOR SV LP750-4 ROADSTER CANADA TRIM FRAME FRONT PART (701.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
3	470806812D	BRACKET SCHEINWERFER ARM (CONTACT YOUR AREA MANAGER-RIGHT FRONT)	1 req	Avail to order Our Price: $948.57
4	470805099D	UPPER SIDE MEMBER SIDE MEMBER (CONTACT YOUR AREA MANAGER-LEFT FRONT)	1 req	Avail to order Our Price: $543.49
4	470805100D	UPPER SIDE MEMBER SIDE MEMBER (CONTACT YOUR AREA MANAGER-RIGHT FRONT)	1 req	Avail to order Our Price: $550.93
5	N91000203	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (10X18-M8X25-H)	10 req	Avail to order Our Price: $12.31
6	N90900401	HEXALOBULAR SOCKET HEX SOCKET OVAL HEAD COLLARED (M6X20)	6 req	Current Stock: 10 Our Price: $1.49
7	8H0806221	ADJUSTMENT PART COMPENSATING PIECE	8 req	Avail to order Our Price: $11.86
8	N10738101	HEXALOBULAR SOCKET HEX SOCKET HEAD BOLT (COMBI) (M5X16)	4 req	Current Stock: 6 Our Price: $0.99
9	N90981701	SPEED NUT SPEED NUT (M5X21.0X15.3)	2 req	Current Stock: 20 Our Price: $1.04
10	470807147A	BRACKET,SIDE CRASH PART ARM (CONTACT YOUR AREA MANAGER)	2 req	Avail to order Our Price: $59.25
11	470807135D	BRACKET STF VORN/BIW BRACKET (CONTACT YOUR AREA MANAGER-LEFT FRONT)	1 req	Avail to order Our Price: $20.81
11	470807135D	BRACKET STF VORN/BIW BRACKET (CONTACT YOUR AREA MANAGER-LEFT FRONT-LEFT FRONT)	1 req	Avail to order Our Price: $20.81
11	470807136D	BRACKET STF VORN/BIW BRACKET (CONTACT YOUR AREA MANAGER-RIGHT FRONT)	1 req	Avail to order Our Price: $20.81
11	470807136D	BRACKET STF VORN/BIW BRACKET (CONTACT YOUR AREA MANAGER-RIGHT FRONT-RIGHT FRONT)	1 req	Avail to order Our Price: $20.81
12	N0402936	HEX.HD.SCREW HEXAGON BOLT (M5X16)	4 req	Current Stock: 14 Our Price: $2.04
13	WHT000778	SPRING LOCK WASHER WASHER (30X36X1)	4 req	Current Stock: 15 Our Price: $0.77
14	N90698605	SCREW HEXAGON SOCKET HEAD PANEL BOLT (ST4,2X16)	2 req	Current Stock: 2 Our Price: $1.83
14	N91054101	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X25)	2 req	Current Stock: 19 Our Price: $1.24
15	470805327B	BRACKET ARM (LEFT FRONT)	1 req	Avail to order Our Price: $321.83
15	470805328B	BRACKET ARM (RIGHT FRONT)	1 req	Avail to order Our Price: $55.53
16	470807165	REINFORCEMENT FRONT SPOILER (FRONT)	1 req	Avail to order Our Price: $88.65
17	475955195	BRACKET ARM	1 req	Avail to order Our Price: $66.77
18	N90749002	HEX.HEAD SCREW W. HEXAGON HEAD BOLT (COMBI)	2 req	Avail to order Our Price: $1.46
19	N0154487	SPEED NUT SPEED NUT (4,2X16,3X11)	2 req	Current Stock: 10 Our Price: $0.61
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
