2012 GALLARDO LP 550-2 COUPE - AUSTRALIA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96

Ignition

PN	Item	Diagram
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 853.01.00 - EXTERNAL SIDE MEMBER

2012 Lamborghini GALLARDO LP 550-2 COUPE AUSTRALIA EXTERNAL SIDE MEMBER (853.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	WHT000778	SPRING LOCK WASHER WASHER	12 req	Current Stock: 15 Our Price: $2.00
2	400807286	BRACKET BUMPER SIDE BRACKET	6 req	Current Stock: 1 Our Price: $97.88
3	400853373	GALLARDO SILL SCUFF PLATE SCUFF PLATE	2 req	Avail to order Our Price: $108.65
3	400853373C	SCUFF PLATE (OPTIONAL MADE OF STAINLESS STEEL) SCUFF PLATE (OPTIONAL MADE OF STAINLESS STEEL)	2 req	Avail to order Our Price: $244.47
4	400853491C	SCUFF PLATE LH SIDE MEMBER MOLDING	1 req	Avail to order Our Price: $215.99
4	400853492C	SCUFF PLATE RH SIDE MEMBER MOLDING	1 req	Avail to order Our Price: $215.99
5	400853563C	SILL LINING SIDE MEMBER COVER, OUTER LH	1 req	Avail to order Our Price: $1,430.80
5	400853564D	SILL LINING SIDE MEMBER COVER, OUTER RH	1 req	Avail to order Our Price: $1,430.80
6		SIDE MEMBER SEAL (VALID UP TO MODEL YEAR 06)	0 req
7	N90777702	SNAP NUT CLAMP CLIP	2 req	Current Stock: 5 Our Price: $2.00
8	N90807405	HEXALOBULAR SOCKET FLANGE BOLT SCREW M5X18	10 req	Current Stock: 2 Our Price: $2.00
9	N90847903	HEXAGON FLANGE SCREW M6X15	12 req	Avail to order Our Price: $2.00
11	WHT001190	SCREW SCREW M5X12	12 req	Current Stock: 14 Our Price: $2.00
12	N90342503	SNAP NUT CLAMP CLIP	8 req	Avail to order Our Price: $2.00
13	N90857301	screw SCREW	12 req	Current Stock: 10 Our Price: $2.00
14		SIDE SKIRT (FOR SUPERLEGGERA MODEL)	1 req
15	WHT000778	SPRING LOCK WASHER WASHER	20 req	Current Stock: 15 Our Price: $2.00
15		WASHER (FOR SUPERLEGGERA MODEL)	20 req
16	N90807405	HEXALOBULAR SOCKET FLANGE BOLT SCREW M5X18	20 req	Current Stock: 2 Our Price: $2.00
16		SCREW (FOR SUPERLEGGERA MODEL)	20 req
17	N0211963	HEX.HEAD CLAMPING NUT M5	20 req	Avail to order Our Price: $2.00
17		NUT M5 (FOR SUPERLEGGERA MODEL)	20 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
