2012 GALLARDO LP 550-2 COUPE - AUSTRALIA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14

Ignition

PN	Item	Diagram
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27

Sensors

PN	Item	Diagram
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 837.10.00 - DOORS

2012 Lamborghini GALLARDO LP 550-2 COUPE AUSTRALIA DOORS (837.10.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	WHT000767	TAPP.SCREW,CSK. SCREW	4 req	Current Stock: 14 Our Price: $2.00
2	400035243	BRACKET TWEETER SUPPORT BRACKET	2 req	Avail to order Our Price: $11.48
3	400831707	DOOR SEAL INNER LEFT DOOR WEATHERSTRIP, INNER	1 req	Current Stock: 1 Our Price: $1,030.41
3	400831708	DOOR SEAL INNER RIGHT DOOR WEATHERSTRIP, INNER	1 req	Current Stock: 1 Our Price: $1,030.41
4	400837967C	RUBBING STRIP DOOR CRASH PAD	1 req	Avail to order Our Price: $70.20
4	400837968C	RUBBING STRIP DOOR CRASH PAD	1 req	Avail to order Our Price: $70.20
5		ASSEMBLY DOOR PANEL (CANNOT BE SOLD SEPARATELY)	1 req
6		UPHOLSTERY ASSEMBLY FOR DOOR INTERIOR (CANNOT BE SOLD SEPARATELY)	1 req
7	400867131B	DOOR TRAY LEFT POCKET (LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $2,324.86
7	400867131C	DOOR TRAY LEFT POCKET (PERFORATED LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $697.46
7	400867132B	DOOR TRAY RIGHT POCKET (LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $2,324.86
7	400867132C	DOOR TRAY RIGHT POCKET (PERFORATED LEATHER INTERIOR - SUPPLY VIN)	1 req	Avail to order Our Price: $697.46
8	400867171D	HANDLE RECESS, LH HANDLE UPPER PORTION (CARBON INTERIOR)	1 req	Current Stock: 5 1 Used Available Our Price: $4,002.82
8	400867171H	HANDLE RECESS, LH HANDLE UPPER PORTION (LEATHER UPHOLSTERY SUPPLY VIN)	1 req	Avail to order Our Price: $1,578.61
8	400867171HSK1	HANDLE RECESS, LH HANDLE UPPER PORTION (BLACK LEATHER UPHOLSTERY)	1 req	Avail to order Our Price: $1,578.61
8	400867171J	HANDLE RECESS, LH HANDLE UPPER PORTION (STANDARD) LH HANDLE UPPER PORTION (STANDARD)	1 req	Avail to order Our Price: $190.16
8	400867172D	HANDLE RECESS, carbon RH HANDLE UPPER PORTION (CARBON INTERIOR)	1 req	Current Stock: 3 Our Price: $4,002.82
8	400867172H	HANDLE RECESS, RH HANDLE UPPER PORTION (LEATHER UPHOLSTERY SUPPLY VIN)	1 req	Avail to order Our Price: $1,578.61
8	400867172HSK1	HANDLE RECESS, RH HANDLE UPPER PORTION (BLACK LEATHER UPHOLSTERY)	1 req	Avail to order Our Price: $1,578.61
8	400867172J	HANDLE RECESS, RH HANDLE UPPER PORTION (STANDARD)	1 req	Current Stock: 1 Our Price: $190.16
9	400867195C	HANDLE RECESS, LH HANDLE CENTER PORTION (CARBON INTERIOR)	1 req	Current Stock: 1 Our Price: $3,323.77
9	400867195G	HANDLE RECESS, LH LH HANDLE CENTER PORTION (STANDARD)	1 req	Current Stock: 5 Our Price: $124.71
9	400867195J	HANDLE RECESS, LH HANDLE CENTER PORTION (LEATHER UPHOLSTERY SUPPLY VIN)	1 req	Avail to order Our Price: $872.54
9	400867195JSK1	HANDLE RECESS, LH HANDLE CENTER PORTION (BLACK LEATHER UPHOLSTERY)	1 req	Avail to order Our Price: $872.54
9	400867196C	HANDLE RECESS, RH HANDLE CENTER PORTION (CARBON INTERIOR)	1 req	Avail to order Our Price: $3,323.77
9	400867196G	HANDLE RECESS, RH HANDLE CENTER PORTION (STANDARD)	1 req	Current Stock: 2 Our Price: $124.71
9	400867196J	HANDLE RECESS, RH HANDLE CENTER PORTION (LEATHER UPHOLSTERY SUPPLY VIN)	1 req	Avail to order Our Price: $872.54
9	400867196JSK1	HANDLE RECESS, RH HANDLE CENTER PORTION (BLACK LEATHER UPHOLSTERY)	1 req	Avail to order Our Price: $872.54
10	400867299	CLIP FASTENER LYS FUSION, YELLOW	4 req	Avail to order Our Price: $18.02
11	402867105G	DOOR TRIM PANEL LH DOOR PANEL ASSEMBLY (SUPPLY VIN)	1 req	Avail to order Our Price: $5,403.14
11	402867106H	DOOR TRIM PANEL RH DOOR PANEL ASSEMBLY (SUPPLY VIN)	1 req	Avail to order Our Price: $5,403.14
12	400868099C	FINGER PLATE blue INNER HANDLE WITH GRID LH (LEATHER UPHOLSTERY SUPPLY VIN)	1 req	Current Stock: 1 Our Price: $4,728.65
12	400868099CSK1	HANDLE RECESS MIT GITTER INNER HANDLE WITH GRID LH (BLACK LEATHER UPHOLSTERY)	1 req	Avail to order Our Price: $4,728.65
12	400868099D	FINGER PLATE INNER HANDLE WITH GRID LH (CARBON INTERIOR)	1 req	Current Stock: 2 Our Price: $5,511.02
12	400868099J	HANDLE RECESS INNER HANDLE WITH GRID LH	1 req	Avail to order Our Price: $250.43
12	400868099F	FINGER PLATE INNER HANDLE WITH GRID LH (DECORATIVE INSERTS - SUPPLY VIN)	1 req	Current Stock: 1 2 Used Available Our Price: $4,728.65
12	400868100C	FINGER PLATE INNER HANDLE WITH GRID RH (LEATHER UPHOLSTERY SUPPLY VIN)	1 req	Avail to order Our Price: $4,728.65
12	400868100CSK1	HANDLE RECESS MIT GITTER INNER HANDLE WITH GRID RH (BLACK LEATHER UPHOLSTERY)	1 req	Avail to order Our Price: $4,728.65
12	400868100D	FINGER PLATE INNER HANDLE WITH GRID RH (CARBON INTERIOR)	1 req	Avail to order Our Price: $5,511.02
12	400868100N	HANDLE RECESS INNER HANDLE WITH GRID RH	1 req	Current Stock: 1 Our Price: $250.43
12	400868100F	FINGER PLATE INNER HANDLE WITH GRID RH (DECORATIVE INSERTS - SUPPLY VIN)	1 req	Current Stock: 1 1 Used Available Our Price: $4,423.57
13	400962107A	ROCKER SWITCH, DOOR LOCK/UNLOCK SWITCH (DRIVER SIDE)	2 req	Avail to order Our Price: $420.49
13	400962107B	ROCKER SWITCH, PLUG (PASSENGER SIDE)	2 req	Avail to order Our Price: $37.82
14		DOOR CLEARANCE LIGHT (VALID UP TO MODEL YEAR 09)	0 req
15		DOOR COURTESY LIGHT (VALID UP TO MODEL YEAR 09)	0 req
16	8N0919238	WARNING LIGHT ANTITHEFT LED	1 req	Avail to order Our Price: $43.92
17	8Z0919242	SEE PN 8Z0919242A ANTITHEFT LED BUSHING	2 req	Avail to order Our Price: $2.01
18	N10613801	CYL.SCREW AM5x55.0 SCREW M 5X55.0	4 req	Current Stock: 12 Our Price: $2.00
19	N10544301	CYL.SCREW SCREW M 5X25	2 req	Current Stock: 17 Our Price: $2.00
20	N90526602	SNAP NUT CLAMP CLIP	2 req	Avail to order Our Price: $2.00
21	WHT002961	WASHER WASHER	4 req	Current Stock: 39 Our Price: $2.00
22	N10586401	HEXALOBULAR SOCKET SCREW M5X10	4 req	Current Stock: 13 Our Price: $2.00
23	400867159A	BRACKET LH BRACKET	1 req	Current Stock: 1 Our Price: $22.75
23	400867160A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $22.75
24	N01154012	WASHER WASHER	6 req	Current Stock: 14 Our Price: $2.00
25	WHT003111	HEXAGON SOCKET SCREW M 5X16	2 req	Current Stock: 23 Our Price: $2.00
26	WHT000778	SPRING LOCK WASHER WASHER	2 req	Current Stock: 15 Our Price: $2.00
27	N10621601	HEXALOBULAR SOCKET SCREW M 4X12	2 req	Current Stock: 4 Our Price: $2.37
28	402837232C	STRIKER PLATE PLUG	1 req	Avail to order Our Price: $34.74
29		PULL HANDLE (VALID UP TO MODEL YEAR 11 )	0 req
30	8E0867443	CAP PLUG	2 req	Avail to order Our Price: $8.55
31	4E0947415	ENTRANCE LIGHT ROOF LAMP (ADDITIONAL LIGHTS)	2 req	Avail to order Our Price: $26.69
32	8P0947412	DOOR WARNING LIGHT REAR LIGHT REFLECTOR	2 req	Avail to order Our Price: $8.12
33	6Y0947411	DOOR WARNING LIGHT DOOR CLEARANCE LIGHT (ADDITIONAL LIGHTS)	2 req	Avail to order Our Price: $28.49
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
