2012 GALLARDO LP 550-2 COUPE - AUSTRALIA

Group :

Tav :

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $938.30
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $1,031.98

Common repairs and upgrades

PN	Item
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 8 Our Price: $61.26
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $75.82
0R1400313	LP560 AND LP570 SERVICE KIT 1 - AIR-CABIN-OIL FILTERS KIT SERVICE KIT 1 - 2 CABIN, 2 AIR AND 1 OIL FILTER INCLUDES: 1X 079198405E OIL FILTER 2X 420133844D AIR FILTER 1X 4F0898438C POLLEN FILTER 1X N0138322 COPPER WASHER 1X N0138486 COPPER WASHER	Avail to order Our Price: $399.23
0R1400314	GALLARDO 2009-2014 SERVICE KIT - AIR-CABIN-OIL FILTER +PLUGS+BELT KIT AIR-CABIN-OIL FILTER +PLUGS+BELT KIT KIT SERVICE 2 INCLUDES: 1X 079198405E OIL FILTER 2X 420133844D AIR FILTERS 1X 4F0898438C POLLEN FILTER 10X 06H905601A SPARK PLUGS 1X07L903137T ALTERNATOR BELT 1X N0138322 COPPER WASHER 1X N0138486 COPPER WASHER	Avail to order Our Price: $664.29
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66

Drivetrain

PN	Item
079198405E	OIL FILTER ENGINE ENGINE OIL FILTER GALLARDO LP SERIES AND HURACAN TECNICAS	Current Stock: 6 Our Price: $89.00
086301517	OIL FILTER GEARBOX OIL FILTER FOR GEARBOX	Current Stock: 2 Our Price: $141.07
N0138495	O-RING / WASHER O-RING	Current Stock: 47 Our Price: $3.45

Fuel-Air

PN	Item
420133844D	AIR FILTER GALLARDO LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Current Stock: 1 Our Price: $135.23
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $122.39
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $42.69
4F0201511E	FUEL FILTER - GALLARDO LP 560-4 FUEL FILTER - GALLARDO LP 560-4	Current Stock: 8 Our Price: $87.67
420133844DZ	PAIR HIGH FLOW K&N AIR FILTER GALLARDO LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $227.32
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $133.02

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.16

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $493.18
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $102.38
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL FOR INDIVIDUAL COILS SEE PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $480.17

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $447.76
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $10,988.32
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
7H0906271A-ALT	FUEL PUMP MODULE ASSEMBLY FUEL PUMP MODULE ASSEMBLY 7H0906271A FUEL VAPOR LEAK DETECTION PUMP THE FACTORY IS NO LONGER PROVIDING THE ORIGINAL ITEM. THIS IS A COMPATIBLE REPLACEMENT	Avail to order Our Price: $7,629.44

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $47.65
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $361.59
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62

Tools and Tookits

PN	Item
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237	Avail to order Our Price: $38.70
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL	Current Stock: 2 Our Price: $245.40
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 91 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 407.05.00 - FRONT ARMS

2012 Lamborghini GALLARDO LP 550-2 COUPE AUSTRALIA FRONT ARMS (407.05.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. NUT M12X1.5	2 req	Avail to order 1 Used Available Our Price: $2.65
2	400407505J	CONTROL ARM,FRONT UPPER LH UPPER ARM	1 req	Avail to order Our Price: $1,330.09
2	400407506J	CONTROL ARM,FRONT UPPER RH UPPER ARM	1 req	Avail to order Our Price: $1,330.09
2	420407505E	CONTROL ARM,FRONT LH UPPER ARM	1 req	Avail to order Our Price: $562.71
2	420407506E	CONTROL ARM,FRONT RH UPPER ARM	1 req	Avail to order Our Price: $562.71
3	WHT002262	ECCENTRIC BOLT SCREW M12X1.5X87	4 req	Avail to order Our Price: $16.47
4	N10689301	12-POINT SOCKET SCREW M8X25	16 req	Current Stock: 4 Our Price: $3.36
5	N10428002	HEXAGON FLANGE SCREW M12X1.5X80	4 req	Avail to order Our Price: $6.82
6	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. NUT M12X1.5	2 req	Avail to order 1 Used Available Our Price: $2.65
7	4D0411327J	RUBBER MOUNTING SWAY BAR BUSHING BUSHING	2 req	Current Stock: 2 1 Used Available Our Price: $14.16
8	400411309F	STABILIZER - BALBONI FRONT STABILIZER BAR (2WD - VALENTINO BALBONI)	1 req	Avail to order Our Price: $348.40
8	420411309	STABILIZER FRONT STABILIZER BAR	1 req	Avail to order Our Price: $406.58
9		FLEXIBLE BUSHING (CANNOT BE SOLD SEPARATELY - SEE REF. 2 - 20)	0 req
10	WHT001676	ECCENTRIC WASHER WASHER	4 req	Current Stock: 6 Our Price: $1.94
11	N10629501	HEXAGON FLANGE JOURNAL M12X1.50X125X90	2 req	Avail to order Our Price: $9.47
12	N10699901	HEXAGON FLANGE SCREW M10X45	2 req	Current Stock: 6 Our Price: $3.98
13	N10314506	HEXAGON FLANGE SCREW M10X50	4 req	Current Stock: 1 Our Price: $5.04
14	420407465	CONNECTING LINK CONNECTING ROD	2 req	Avail to order Our Price: $179.69
15	N10682501	12-POINT SOCKET FL SCREW M8X50	4 req	Current Stock: 6 1 Used Available Our Price: $3.01
16	420411031A	STABILIZER MOUNTIN STABILIZER BAR BRACKET	2 req	Avail to order 1 Used Available Our Price: $27.80
17	4D0411336G	CLIP STABILIZER BAR BRACKET	2 req	Current Stock: 1 1 Used Available Our Price: $6.37
18	N10689301	12-POINT SOCKET SCREW M8X25	16 req	Current Stock: 4 Our Price: $3.36
19	WHT004898	HEXAGON FLANGE NUT W.WASHER NUT M14X1.5	4 req	Current Stock: 10 Our Price: $7.70
20	400407151J	TRACK CONTROL ARM LH LOWER ARM	1 req	Avail to order Our Price: $1,468.59
20	400407152J	TRACK CONTROL ARM RH LOWER ARM	1 req	Avail to order Our Price: $1,409.70
20	420407151L	TRACK CONTROL ARM LH LOWER ARM	1 req	Avail to order Our Price: $627.54
20	420407152L	TRACK CONTROL ARM RH LOWER ARM	1 req	Avail to order Our Price: $627.54
21	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. NUT M12X1.5	4 req	Avail to order 1 Used Available Our Price: $2.65
22	420407457B	MOUNTING LEFT SUPPORT	1 req	Avail to order Our Price: $61.90
22	420407458B	MOUNTING RIGHT SUPPORT	1 req	Current Stock: 1 Our Price: $61.90
23	420407457F	MOUNTING LEFT SUPPORT	1 req	Avail to order Our Price: $606.90
23	420407458F	MOUNTING RIGHT SUPPORT	1 req	Avail to order Our Price: $606.90
24	420407457H	MOUNTING LEFT SUPPORT	1 req	Avail to order Our Price: $61.90
24	420407458H	MOUNTING RIGHT SUPPORT	1 req	Avail to order Our Price: $61.90
25	400407457	MOUNTING SUPPORT	2 req	Avail to order Our Price: $174.55
26	N90848406	HEXAGON FLANGE NUT NUT M12X1.5	2 req	Current Stock: 4 Our Price: $7.79
27	400412019BN	DAMPER STRUT SHOCK ABSORBER (STANDARD/LIFTING SYSTEM - 2WD - VALENTINO BALBONI)	2 req	Avail to order Our Price: $3,702.44
27	400412019BP	DAMPER STRUT SHOCK ABSORBER (STANDARD - 2WD - VALENTINO BALBONI)	2 req	Avail to order Our Price: $1,505.17
27	400412019BS	DAMPER STRUT SHOCK ABSORBER (STANDARD - FROM VIN ALA09702 INTERCHANGEABLE 1 TO 1)	2 req	Avail to order Our Price: $1,505.17
27	400412019BS	DAMPER STRUT SHOCK ABSORBER (STANDARD - UNTIL THE VIN ALA09701 REPLACE PER AXLE)	2 req	Avail to order Our Price: $1,505.17
27	400412019BT	DAMPER STRUT SHOCK ABSORBER (STANDARD/LIFTING SYSTEM - FROM VIN ALA09702 INTERCHANGEABLE 1 TO 1)	2 req	Avail to order Our Price: $6,370.03
27	400412019BT	DAMPER STRUT SHOCK ABSORBER (STANDARD/LIFTING SYSTEM - UNTIL THE VIN ALA09701 REPLACE PER AXLE)	2 req	Avail to order Our Price: $6,370.03
27	400412019CA	SHOCK ABSORBER (SPORT) SHOCK ABSORBER (SPORT)	2 req	Avail to order Our Price: $1,505.17
27	400412019CB	DAMPER STRUT SHOCK ABSORBER (SPORT/LIFTING SYSTEM - FROM VIN ALA09702 INTERCHANGEABLE 1 TO 1)	2 req	Avail to order Our Price: $6,370.03
27	400412019CB	DAMPER STRUT SHOCK ABSORBER (SPORT/LIFTING SYSTEM - UNTIL THE VIN ALA09701 REPLACE PER AXLE)	2 req	Avail to order Our Price: $6,370.03
27	400412019CC	DAMPER STRUT SHOCK ABSORBER (COMFORT)	2 req	Avail to order Our Price: $1,505.17
27	400412019CD	DAMPER STRUT SHOCK ABSORBER (COMFORT/LIFTING SYSTEM - BILSTEIN)	2 req	Avail to order Our Price: $4,838.01
28	N10428002	HEXAGON FLANGE SCREW M12X1.5X80	2 req	Avail to order Our Price: $6.82
29	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. NUT M12X1.5	2 req	Avail to order 1 Used Available Our Price: $2.65
30	400971845A	BRACKET LH BRACKET	1 req	Avail to order Our Price: $38.88
30	400971846A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $38.88
31	N10714801	HEXALOBULAR SOCKET SCREW M6X18	2 req	Avail to order Our Price: $0.99
32	420419811A	BALL JOINT BALL JOINT COUPLING	2 req	Avail to order Our Price: $198.82
33	N10218708	HEX.NUT NUT M14X1.5	2 req	Avail to order Our Price: $3.98
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
