1974 - 1978 Countach LP400 - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
004504532	BELT BELT FOR AIR CONDITIONER WE HAVE SOURCE IT IS NLA FROM LAMBORGHINI		Avail to order Our Price: $50.20

Common repairs and upgrades

PN	Item
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 7 Our Price: $27.66
007021195	SHOCK ABSORBER COUNTACH DOOR SHOCK ABSORBER WITHOUT INTERNAL PARTS YOU MAY ALSO NEED N02214812 X1 HEX.HEAD 007021193 X1 SHOCK ABSOR.FIX.PIN TO DO 007021208 X1 SHOCK ABSORBER SECURPIN A 008580801 X1 O-RING E 8 UNI 7535-75 N01118410 X1 HEX.HEAD CLAMPING NUT WHT002962 X3 WASHER	Current Stock: 7 Our Price: $114.14
007029006	TRUNK LIFTER STRUT TRUNK LIFTER WITH STAB.	Current Stock: 4 Our Price: $80.38
007029005	BONNET LIFTER BONNET LIFTER	Current Stock: 4 Our Price: $103.63

Drivetrain

PN	Item
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Avail to order Our Price: $378.11
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 2 Our Price: $1,290.15
002109861	NLA (NO LONGER AVAILABLE) ENGINE FLYWHEEL	Avail to order Our Price: $2,815.50
002109864	THRUST BEARING THRUST BEARING	Avail to order Our Price: $6,806.83
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $51.86

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $541.53
002021172	FREQUENCY VALVE FREQUENCY VALVE BOSCH 0280150300 (028 0150 300)	Avail to order Our Price: $940.50
002021173	FUEL DAMPERS FUEL DAMPERS	Avail to order Our Price: $467.72
002021146	COLD START INJECTOR STARTER INJECTOR	Current Stock: 4 Our Price: $378.11
002021170	COUNTACH FUEL DISTRIBUTOR FUEL DISTRIBUTOR 0438100106 (043 8100 106)	Avail to order Our Price: $6,264.87
002021174	COUNTACH INJECTION EFI ECU ECU	Avail to order Our Price: $4,273.56
002021141RE	COUNTACH EFI FUEL INJECTION PUMP FUEL PUMP	Avail to order Our Price: $799.00
002021147	FUEL INJECTOR FOR COUNTACH FUEL INJECTOR FOR COUNTACH	Current Stock: 11 Our Price: $286.94
002021176	LAMBDA O2 SENSOR LAMBDA SENSOR *MAY NEED TO USE YOUR EXISTING CONNECTOR	Current Stock: 4 Our Price: $778.09
002021141	COUNTACH EFI FUEL INJECTION PUMP COUNTACH FUEL INJECTION INLINE FUEL PUMP	Avail to order Our Price: $1,444.72
002021142B	FUEL FILTER - COUNTACH - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL FILTER USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE. AS OF 1-3-2024 DOESN'T SHOW AVAILABILITY	Avail to order Our Price: $30.48
002021173b	FUEL DAMPERS - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL REGULATOR USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE.	Current Stock: 1 Our Price: $267.03
002021176OE	LAMBDA SENSORS LAMDA SENSORS	Current Stock: 2 Our Price: $99.14
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $102.16
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $23.72
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $14.48

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $10.00
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.20
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $8.94
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.12
006311155	RELAY RELAY	Avail to order Our Price: $60.68
006311154	RELAY RELAY	Avail to order Our Price: $50.59
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $18.30
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $10.66

Gaskets

PN	Item	Diagram
001526487	NLA (NO LONGER AVAILABLE) ENGINE GASKET KIT SEE PN 001526467 FOR SEALS KIT		Avail to order Our Price: $1,722.46
001526467	NLA (NO LONGER AVAILABLE) GROMMET & OIL SEALS SET		Avail to order Our Price: $142.56

Ignition

PN	Item	Diagram
001610428	DISTRIBUTOR/SPARK PLUG WIRES - DUAL DISTRIBUTOR IGNITION SYSTEM DISTRIBUTOR/SPARK PLUG WIRES		Avail to order Our Price: $1,167.87
001611403	COUNTACH WIRING HARNESS COUNTACH WIRING HARNESS		Avail to order Our Price: $3,100.38

Misc

PN	Item
006111300	LONG WIPER BLADE LONG WIPER BLADE	Avail to order Our Price: $48.90
006128790	WIPER SHORT BLADE 13 INCH WIPER SHORT BLADE (PREVIOUS PN 006111019)	Current Stock: 2 Our Price: $18.14
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.53
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $137.97
002021143	THERMOSTAT SWITCH - EFI COUNTACH ONLY ORIGINAL OEM THERMOSTAT SWITCH - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $940.50
001724565	FAN MOTOR THERMAL CONTACT FAN MOTOR THERMAL CONTACT	Avail to order Our Price: $263.59
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $583.24

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 92 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 25 - Rear Suspension

1974 - 1978 Lamborghini Countach LP400 USA Rear Suspension (25)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	005109562	This item is no longer available	2 req
2	008201411	M14 UNI 5589 8G/ZNUT	10 req	Avail to order Our Price: $17.65
3	005109558	JOINT	4 req	Avail to order Our Price: $533.59
4	N0111849	HEX.HEAD CLAMPING NUT	12 req	Current Stock: 5 Our Price: $2.39
5	N90179103	WASHER	8 req	Current Stock: 5 Our Price: $1.92
6	005209565	This item is no longer available	2 req
7	008251401	M14X1.5X24 SELF-LOCKING RING N	10 req	Current Stock: 1 Our Price: $28.22
8	008401401	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	6 req	*See Description
9	008101420	SPECIAL SCREW M14X53	2 req	Avail to order Our Price: $101.43
10	005109521	SUSPENSION JOINT	2 req	Avail to order Our Price: $358.12
11	005209688	UPPER ARM FORK	2 req	Avail to order Our Price: $794.28
12	008401402	SUSPENSION ARM WASHER	2 req	Avail to order Our Price: $28.06
13	005209535	LOWER JOINT	4 req	Avail to order Our Price: $376.27
14	008401421	WASHER D.14.5X30X1 UNI 4721	18 req	Current Stock: 34 Our Price: $0.70
15	005209537	UPPER REAR ARM ADJUSTMENT	2 req	Avail to order Our Price: $309.07
16	008201412	M14X1.5 LH SPECIAL NUT	2 req	Avail to order Our Price: $19.28
17	005209538	UPPER JOINT	2 req	Avail to order Our Price: $456.66
18	005209771	BAR FORK	2 req	Avail to order Our Price: $272.14
19	005109713	JOINT BUSHING	8 req	Avail to order Our Price: $8.62
20	008100807	SCREW M8X40 UNI 5737/8G ZD	4 req	Avail to order Our Price: $0.90
21	005109714	SWAY BAR JOINT BOOT	4 req	Avail to order Our Price: $27.57
22	005206963	NLA (NO LONGER AVAILABLE)	2 req	*See Description
23	008201014	M10X1X6 UNI 5589/5S/Z NUT	2 req	Current Stock: 1 Our Price: $6.42
24	005209770	NLA (NO LONGER AVAILABLE)	2 req	*See Description
25	008201016	10X1X6 S LEFT NUT	2 req	Avail to order Our Price: $23.91
26	005206964	BALL JOINT RFL 10 S LH	2 req	Avail to order Our Price: $138.44
27	005209769	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
28	005209757	REAR TORSION BAR BRACKET	2 req	Avail to order Our Price: $280.19
29	WHT001197A	WASHER	4 req	Current Stock: 22 Our Price: $0.33
30	008700609	SCREW 6X45 UNI 5931/8G/ZD	4 req	Avail to order Our Price: $0.60
31	005209756	REAR TORSION BAR BUSHING	2 req	Current Stock: 4 Our Price: $77.76
32	008401413	FLAT WASHER 14.3 UNI1750/Z	2 req	Current Stock: 11 Our Price: $1.10
33	008101424	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
34	008101702	SPECIAL SCREW 17X1X59	4 req	Avail to order Our Price: $130.90
35	008401706	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	12 req	*See Description
36	008401710	FLAT WASHER 17X34X1	32 req	Current Stock: 21 Our Price: $43.52
37	008251702	M17X1X28 SELF-LOCKING RING NUT	8 req	Avail to order Our Price: $4.06
38	005209595	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
39	005205680	REAR SHOCK ABSORBER BULKHEAD	4 req	Avail to order Our Price: $125.34
40	005209717	REAR SUSPENSION SPRING	4 req	Avail to order Our Price: $674.61
41	005109529	JOINT	10 req	Avail to order Our Price: $160.60
42	005212040	RH/LH SUSPENSION HUB	2 req	Avail to order Our Price: $1,095.30
43	005210407	SUSPENSION HUB OUTERSHIM	2 req	Avail to order Our Price: $72.72
44	008616003	OIL SEAL	2 req	Current Stock: 1 Our Price: $17.57
45	008577501	O-RING I 75 UNI 3654	2 req	Current Stock: 2 Our Price: $1.80
46	008503507	BEARING	2 req	Avail to order Our Price: $96.24
47	005212033	SPACER	2 req	Avail to order Our Price: $336.00
48	005212037	RH REAR HUB HOLDER	1 req	Avail to order Our Price: $12,241.28
49	005212038	LH REAR HUB HOLDER	1 req	Avail to order Our Price: $12,241.28
50	008524502	BEARING	2 req	Avail to order Our Price: $151.16
51	008614506	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
52	008410603	WASHER D.6.4 UNI 1751/ZD	16 req	Avail to order Our Price: $0.10
53	008700617	SCREW M6X18 UNI 5931/8G/Z	16 req	Current Stock: 1 Our Price: $0.30
54	005209686	HUB OIL SEAL HOUSING	2 req	Avail to order Our Price: $364.23
55	005212039	DRIVE SHAFT FLANGE	2 req	Avail to order Our Price: $411.26
56	008402802	AXLE SHAFT WASHER	2 req	Avail to order Our Price: $6.01
57	008252803	28X1.5 SPECIAL RING NUT	2 req	Avail to order Our Price: $24.00
58	005209718	SHOCK ABSORBER PIN	2 req	Avail to order Our Price: $376.27
59	005209695	LOWER ARM PIN	2 req	Avail to order Our Price: $281.57
60	005209694	LOWER ARM SHIM ADJUSTMENT WASH	6 req	Avail to order Our Price: $112.60
61	005209693	BUSHING SEAL RING SET	8 req	Avail to order Our Price: $60.03
62	005209696	FIFTH WHEEL	8 req	Avail to order Our Price: $13.42
63	005209697	LOWER ARM SHIM	4 req	Avail to order Our Price: $302.81
64	008850303	REFERENCE PIN 3X33 C40	4 req	Avail to order Our Price: $6.18
65	008802004	BUSHING20X23X30 MM	4 req	Avail to order Our Price: $39.90
66	008101419	SPECIAL SCREW M14X57	2 req	Avail to order Our Price: $104.71
67	005209586	RH/LH REAR LOWER ARM	2 req	Avail to order Our Price: $2,571.68
68	008101703	SPECIAL SCREW 17X1X65	2 req	Avail to order Our Price: $21.47
69	008201811	M18 UNI 5589 8G NUT	2 req	Avail to order Our Price: $7.97
70	005109532	LOWER JOINT SLEEVE	2 req	Current Stock: 1 Our Price: $525.48
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
