1974 - 1978 Countach LP400 - USA

Maintenance Parts:

Belts

PN	Item	Diagram
004504532	Belt Belt		Current Stock: 1 Our Price: $51.90

Drivetrain

PN	Item
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Avail to order Our Price: $45.47
002109861	NLA (No Longer Available) Engine Flywheel	Avail to order Our Price: $2,909.20
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,332.37
002109864	Thrust Bearing Thrust Bearing	Avail to order Our Price: $7,026.38
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $332.32

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $474.94
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $125.33
002021141	Countach EFI Fuel Injection Pump SEE ALSO PN 002021141B Fuel Pump	Avail to order Our Price: $1,486.77
002021141B	Countach EFI Fuel Injection Pump OEM This is the original and SAME fuel pump used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Current Stock: 1 Our Price: $117.00
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability	Current Stock: 1 Our Price: $37.39
002021146	Cold Start Injector Starter Injector	Current Stock: 4 Our Price: $331.59
002021147	Countach Fuel Injector Injector	Current Stock: 11 Our Price: $295.93
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)	Avail to order Our Price: $5,502.31
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)	Avail to order Our Price: $825.35
002021173	Fuel Dampers Dampers	Avail to order Our Price: $483.20
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $327.60
002021174	Countach Injection EFI ECU ECU	Avail to order Our Price: $4,410.25
002021176	Lambda O2 Sensor (READ DESCRIPTION) Lambda Sensor The Exact OEM replacement for this is PN 002021176OE you can save by simply using your existing connector.	Avail to order Our Price: $803.43
002021176OE	Lambda Sensors Original Equipment Lambda Sensors	Current Stock: 2 Our Price: $121.63
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $15.04

Fuses-Bulbs-Relays

PN	Item
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.01
006311154	Relay Relay	Avail to order Our Price: $52.25
006311155	Relay Relay	Avail to order Our Price: $62.69
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $12.67
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $18.99
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.36
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01

Gaskets

PN	Item	Diagram
001526467	NLA (No Longer Available) Grommet & Oil Seals Set		Avail to order Our Price: $125.11
001526487	Countach 400/400s Gasket set Engine Gasket Kit see pn 001526467 for seals kit		Avail to order Our Price: $1,505.90

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,206.57
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,801.84

Misc

PN	Item
006111300	Long Wiper Blade Long Wiper Blade	Avail to order Our Price: $50.47
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)	Current Stock: 1 Our Price: $18.73
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $230.95
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $825.35
002409895	NLA (No Longer Available) Reverse Switch	Avail to order Our Price: $120.91

Open All

Select Group and TAV

< Previous Next >

TAV: 10 - Sump

1974 - 1978 Lamborghini Countach LP400 USA Sump (10)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001812768	Propeller Shaft PipeGasket	1 req	Avail to order Our Price: $29.32
2	008607301	Ring 73 mm Or	2 req	Current Stock: 2 Our Price: $2.00
3	001808101	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
4	008300610	SEE PN WHT003165	23 req	Avail to order Our Price: $26.67
5	WHT001197A	WASHER	24 req	Current Stock: 2 Our Price: $2.00
6	N01100637	HEX.NUT	16 req	Current Stock: 18 Our Price: $2.00
7	086301141A	Magnetic Plug 22x1.5	2 req	Avail to order Our Price: $37.39
8	001810040	Countach Oil Sump	1 req	Avail to order Our Price: $7,226.52
9	008300815	Special Stud M8x33	3 req	Avail to order Our Price: $18.16
10	001811229	Oil Dipstick Assembly	1 req	Avail to order Our Price: $621.87
11	WHT003057	O-RING	1 req	Current Stock: 14 Our Price: $2.00
12	008100620	Screw M6x12 Uni 5739/5s/Z	8 req	Avail to order Our Price: $6.29
13	001819931	Dipstick Pipe	1 req	Avail to order Our Price: $97.79
14	001808152	Oil Sump Bulkhead	1 req	Avail to order Our Price: $267.34
15	001811732	Sump Inspection Cover	1 req	Avail to order Our Price: $215.16
16	001810045	Differential Seal	2 req	Current Stock: 20 Our Price: $5.58
17	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
18	002302182	Differential Oil Breather Pipe	2 req	Avail to order Our Price: $240.37
19	001811040	Lh Differential Oil Breather	1 req	Avail to order Our Price: $38.32
20	001811041	Rh Differential Oil Breather	1 req	Avail to order Our Price: $38.32
21	008931901	Taper Plug 3/4X14/5s/Z D	4 req	Avail to order Our Price: $6.15
22	008401408	Annealed Copper Washer 21x14x1	1 req	Current Stock: 41 Our Price: $2.00
23	001810335	This item is no longer available	1 req
24	001810336	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
25	008300844	Stud M8x15 Uni 5914 8g Zd	8 req	Avail to order Our Price: $2.01
26	002308058	Differential Box Cover	1 req	Avail to order Our Price: $557.54
27	002311535	Differential Oil Breather Plug	2 req	Avail to order Our Price: $120.80
28	008300847	Special Stud M8x26	1 req	Avail to order Our Price: $2.00
29	410971250	Engine/Chassis/Exhaust Pipe Ea	1 req	Avail to order Our Price: $67.89
30	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $2.00
31	008200804	Nut	1 req	Current Stock: 7 Our Price: $2.00
32	008200806	M8 Uni 5588/8g/Z Nut	13 req	Current Stock: 25 Our Price: $2.00
33	WHT001514	SPRING WASHER	13 req	Current Stock: 9 Our Price: $25.05
34	008300843	Stud M8x22 Uni 5917 8g Zd	13 req	Avail to order Our Price: $2.00
35	01S409965	PLUG	1 req	Current Stock: 5 Our Price: $175.80
36	008300814	Stud M8x18 Uni 5914 8g Zd	16 req	Current Stock: 5 Our Price: $7.15
37	001803094	Oil Dipstick Pipe Seal	1 req	Current Stock: 11 Our Price: $7.87
38	N01118312	HEX.HEAD CLAMPING NUT	7 req	Current Stock: 4 Our Price: $2.01
39	001808102	Spacer	1 req	Avail to order Our Price: $155.83
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
