1974 - 1978 Countach LP400 - USA

Maintenance Parts:

Belts

PN	Item	Diagram
004504532	Belt Belt		Current Stock: 1 Our Price: $54.12

Drivetrain

PN	Item
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Avail to order Our Price: $46.75
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $341.11
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,389.53
002109861	NLA (No Longer Available) Engine Flywheel	Avail to order Our Price: $3,034.00
002109864	Thrust Bearing Thrust Bearing	Avail to order Our Price: $7,327.81

Fuel-Air

PN	Item
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option	Avail to order Our Price: $487.51
002021172	Frequency Valve Frequency Valve Bosch 0280150300 (028 0150 300)	Avail to order Our Price: $847.20
002021173	Fuel Dampers Dampers	Avail to order Our Price: $503.93
002021146	Cold Start Injector Starter Injector	Current Stock: 4 Our Price: $340.37
002021170	Countach Fuel Distributor Fuel Distributor 0438100106 (043 8100 106)	Avail to order Our Price: $5,647.97
002021174	Countach Injection EFI ECU ECU	Avail to order Our Price: $4,599.45
002021141	Countach EFI Fuel Injection Pump SEE ALSO PN 002021141B Fuel Pump	Avail to order Our Price: $1,550.55
002021147	Countach Fuel Injector Injector	Current Stock: 11 Our Price: $308.62
002021176	Lambda O2 Sensor (READ DESCRIPTION) Lambda Sensor The Exact OEM replacement for this is PN 002021176OE you can save by simply using your existing connector.	Avail to order Our Price: $837.90
002021141B	Countach EFI Fuel Injection Pump OEM This is the original and SAME fuel pump used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Current Stock: 1 Our Price: $121.38
002021142B	Fuel Filter - Countach - For Fuel Injected EFI This is the original and SAME fuel filter used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive. As of 1-3-2024 doesn't show availability	Current Stock: 1 Our Price: $38.79
002021173b	Fuel Dampers - For Fuel Injected EFI This is the original and SAME fuel regulator used on all Countach EFI systems. It has a different part number, in order to que the order from another vendor rather than the Factory. We would be more than happy to get it from Italy, but it will be the same pump and much more expensive.	Avail to order Our Price: $339.85
002021176OE	Lambda Sensors Original Equipment Lambda Sensors	Current Stock: 2 Our Price: $126.18
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $15.56
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.71
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $13.10
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.60
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.09
006311155	Relay Relay	Avail to order Our Price: $65.38
006311154	Relay Relay	Avail to order Our Price: $54.49
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $19.64
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.48

Gaskets

PN	Item	Diagram
001526487	Countach 400/400s Gasket set Engine Gasket Kit see pn 001526467 for seals kit		Avail to order Our Price: $1,548.32
001526467	NLA (No Longer Available) Grommet & Oil Seals Set		Avail to order Our Price: $128.64

Ignition

PN	Item	Diagram
001610428	Distributor/Spark Plug Wires - Dual Distributor Ignition System Distributor/Spark Plug Wires		Avail to order Our Price: $1,258.33
001611403	Countach Wiring Harness Countach Wiring Harness		Avail to order Our Price: $2,876.01

Misc

PN	Item
006111300	Long Wiper Blade Long Wiper Blade	Avail to order Our Price: $52.64
006128790	Wiper Short Blade 13 inch Wiper Short Blade (Previous PN 006111019)	Current Stock: 1 Our Price: $19.54
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
002409895	NLA (No Longer Available) Reverse Switch	Avail to order Our Price: $124.11
002021143	Thermostat Switch - EFI Countach only Original OEM Thermostat Switch - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $847.20
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $237.07

Open All

Select Group and TAV

< Previous Next >

TAV: 19 - Front and Rear Brakes

1974 - 1978 Lamborghini Countach LP400 USA Front and Rear Brakes (19)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003204974	NLA (No longer Available to order)	1 req	*See Description
2	003101513	Copper Washer 16.2x24x1	3 req	Avail to order Our Price: $0.87
3	008830205	Clamp	4 req	Avail to order Our Price: $7.68
4	003204607	Brake Booster Union Pipe	1 req	Avail to order Our Price: $115.70
5	003101518	Check Valve	1 req	Avail to order Our Price: $197.55
6	003101486	Bolt	1 req	Avail to order Our Price: $36.39
7	003210387	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
8	008610502	Grommet 4.76x14.28x1.58 mm	6 req	Avail to order Our Price: $4.55
9	003108672	Brake Three-Way Union	2 req	Avail to order Our Price: $63.02
10	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $0.29
11	008100603	Screw M6x25 Uni 5739-8g Zg	3 req	Avail to order Our Price: $1.50
12	003208682	Union	4 req	Current Stock: 1 Our Price: $62.32
13	003110365	Safety Device Pipe/Three-Way	1 req	Avail to order Our Price: $24.68
14	003208683	Hose	4 req	Avail to order Our Price: $97.50
15	003110363	Lh Front Brake Pipe	1 req	Avail to order Our Price: $342.17
16	003107709	NLA (No Longer Available)	1 req	*See Description
17	003110373	Safety Device Pipe/Front Brake	1 req	Avail to order Our Price: $33.40
18	003210372	Safety Device Pipe/Rear Brake	1 req	Avail to order Our Price: $87.08
19	003110364	Rh Front Brake Pipe	1 req	Avail to order Our Price: $358.57
20	003210366	NLA (No Longer Available)	1 req	*See Description
21	003208693	Hydraulic Brake Light Switch	1 req	Avail to order Our Price: $117.42
22	N0111849	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 5 Our Price: $2.31
23	003210357	Valve	1 req	Avail to order Our Price: $292.96
24	003210386	Engine Pipe/Check Valve	1 req	Avail to order Our Price: $45.03
25	003210358	Limiting Valve Pipe/Rear Hose	2 req	Avail to order Our Price: $484.54
26	003210367	Three-Way Pipe/Limiting Valve	1 req	Avail to order Our Price: $23.64
27	008100629	SEE PN N01022217	3 req	Avail to order Our Price: $0.33
28	003101941	Banjo Bolt Fitting	1 req	Avail to order Our Price: $4.54
29	003204610	Vacuum Union	1 req	Avail to order Our Price: $153.83
30	008401610	Annealed Copper Washer 16x22x0	2 req	Current Stock: 25 Our Price: $10.86
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
