1974 - 1978 Countach LP400 - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
004504532	BELT BELT		Current Stock: 1 Our Price: $55.72

Common repairs and upgrades

PN	Item
007021195	SHOCK ABSORBER COUNTACH DOOR SHOCK ABSORBER WITHOUT INTERNAL PARTS YOU MAY ALSO NEED N02214812 X1 HEX.HEAD 007021193 X1 SHOCK ABSOR.FIX.PIN TO DO 007021208 X1 SHOCK ABSORBER SECURPIN A 008580801 X1 O-RING E 8 UNI 7535-75 N01118410 X1 HEX.HEAD CLAMPING NUT WHT002962 X3 WASHER	Current Stock: 7 Our Price: $126.61
007029005	BONNET LIFTER BONNET LIFTER	Current Stock: 4 Our Price: $114.94
007029006	TRUNK LIFTER STRUT TRUNK LIFTER WITH STAB.	Current Stock: 4 Our Price: $89.17
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 2 Our Price: $1,431.28
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Avail to order Our Price: $350.83
002109861	NLA (NO LONGER AVAILABLE) ENGINE FLYWHEEL	Avail to order Our Price: $3,123.45
002109864	THRUST BEARING THRUST BEARING	Avail to order Our Price: $7,551.46
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
002021141	COUNTACH EFI FUEL INJECTION PUMP FUEL PUMP	Avail to order Our Price: $799.00
002021146	COLD START INJECTOR STARTER INJECTOR	Current Stock: 4 Our Price: $350.83
002021147	FUEL INJECTOR FOR COUNTACH FUEL INJECTOR FOR COUNTACH	Current Stock: 11 Our Price: $318.36
002021170	COUNTACH FUEL DISTRIBUTOR FUEL DISTRIBUTOR 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.46
002021172	FREQUENCY VALVE FREQUENCY VALVE BOSCH 0280150300 (028 0150 300)	Avail to order Our Price: $872.46
002021173	FUEL DAMPERS FUEL DAMPERS	Avail to order Our Price: $518.87
002021174	COUNTACH INJECTION EFI ECU ECU	Avail to order Our Price: $4,741.13
002021176	LAMBDA O2 SENSOR LAMBDA SENSOR *MAY NEED TO USE YOUR EXISTING CONNECTOR	Current Stock: 4 Our Price: $863.20
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01
002021142B	FUEL FILTER - COUNTACH - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL FILTER USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE. AS OF 1-3-2024 DOESN'T SHOW AVAILABILITY	Avail to order Our Price: $38.79
002021173b	FUEL DAMPERS - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL REGULATOR USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE.	Avail to order Our Price: $339.85
002021176OE	LAMBDA SENSORS LAMDA SENSORS	Current Stock: 2 Our Price: $126.18
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.01

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $11.06
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $13.59
006311154	RELAY RELAY	Avail to order Our Price: $56.11
006311155	RELAY RELAY	Avail to order Our Price: $67.29
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.90
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.86
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $20.28

Gaskets

PN	Item	Diagram
001526467	NLA (NO LONGER AVAILABLE) GROMMET & OIL SEALS SET		Avail to order Our Price: $132.32
001526487	NLA (NO LONGER AVAILABLE) ENGINE GASKET KIT SEE PN 001526467 FOR SEALS KIT		Avail to order Our Price: $1,597.77

Ignition

PN	Item	Diagram
001610428	DISTRIBUTOR/SPARK PLUG WIRES - DUAL DISTRIBUTOR IGNITION SYSTEM DISTRIBUTOR/SPARK PLUG WIRES		Avail to order Our Price: $1,295.63
001611403	COUNTACH WIRING HARNESS COUNTACH WIRING HARNESS		Avail to order Our Price: $2,876.02

Misc

PN	Item
006111300	LONG WIPER BLADE LONG WIPER BLADE	Current Stock: 1 Our Price: $54.16
006128790	WIPER SHORT BLADE 13 INCH WIPER SHORT BLADE (PREVIOUS PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $373.98

Sensors

PN	Item
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $127.96
002021143	THERMOSTAT SWITCH - EFI COUNTACH ONLY ORIGINAL OEM THERMOSTAT SWITCH - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.46
001724565	FAN MOTOR THERMAL CONTACT FAN MOTOR THERMAL CONTACT	Avail to order Our Price: $244.48
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.04
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $177.89

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 21 - Hand Brake

1974 - 1978 Lamborghini Countach LP400 USA Hand Brake (21)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003311179	This item is no longer available	1 req
2	008100616	SCREW M6X16 UNI 5739/5S/Z	4 req	Avail to order Our Price: $0.20
3	008410603	WASHER D.6.4 UNI 1751/ZD	4 req	Avail to order Our Price: $0.10
4	006721234	DOOR LIGHT PIN SWITCH (DOES NOT INCLUDE RUBBER GASKET ORDER PN 006921236)	1 req	Current Stock: 6 2 Used Available Our Price: $43.47
5	008700315	LOCK SCREW 3.5X9.5DIN7983	1 req	Avail to order Our Price: $2.92
6	008400806	WASHER 15X8X1.5 UNI 1750 R40/Z	2 req	Current Stock: 5 Our Price: $0.60
7	008820201	SPLIT PIN	1 req	Current Stock: 19 Our Price: $7.58
8	008830403	BAND CLAMP	4 req	Avail to order Our Price: $2.63
9	003311189	HANDBRAKE LEVER WIRE/ADJUSTMEN	1 req	Avail to order Our Price: $16.00
10	003307535	HANDBRAKE WIRE COVER	1 req	Current Stock: 1 Our Price: $34.42
11	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $0.40
12	413609206	HANDBRAKE TIEROD ADJUSTMENT	1 req	Avail to order Our Price: $70.69
13	008200607	D 6X1 SIN. 8G NUT	1 req	Avail to order Our Price: $14.88
14	410609789	PIN	1 req	Avail to order Our Price: $32.92
15	003309378	HANDBRAKE LH TIEROD	1 req	Avail to order Our Price: $29.27
16	008400806	WASHER 15X8X1.5 UNI 1750 R40/Z	1 req	Current Stock: 5 Our Price: $0.60
17	008820201	SPLIT PIN	1 req	Current Stock: 19 Our Price: $7.58
18	008410502	WASHER D.5.3 UNI 1751/ZD	1 req	Current Stock: 33 Our Price: $0.10
19	008100505	SCREW M5X20 UNI 5739/5S	1 req	Avail to order Our Price: $0.50
20	003309426	HANDBRAKE WIRE RETAINING BAR	1 req	Avail to order Our Price: $12.64
21	003309423	HANDBRAKE BRACKET	1 req	Avail to order Our Price: $26.35
22	003310774	RH HANDBRAKE WIRE ASSEMBLY	1 req	Avail to order Our Price: $141.82
23	003310773	LH HANDBRAKE WIRE ASSEMBLY	1 req	Avail to order Our Price: $500.89
24	003309387	HANDBRAKE SHOE RUBBER WASHER	2 req	Avail to order Our Price: $48.66
25	008573601	O-RING I 36 UNI 3654	2 req	Avail to order Our Price: $0.80
26	003309385	LH HANDBRAKE SHOE CONTROL UNIT	1 req	Avail to order Our Price: $117.08
27	003309384	RH HANDBRAKE SHOE CONTROL UNIT	1 req	Avail to order Our Price: $117.08
28	003309363	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
29	003309361	HANDBRAKE SHOE RETAINING PIN	2 req	Avail to order Our Price: $31.60
30	003309365	HANDBRAKE SHOE LH INNER UNIT	1 req	Avail to order Our Price: $1,339.13
31	003309364	HANDBRAKE SHOE RH INNER UNIT	1 req	Avail to order Our Price: $363.00
32	008820201	SPLIT PIN	2 req	Current Stock: 19 Our Price: $7.58
33	008400806	WASHER 15X8X1.5 UNI 1750 R40/Z	2 req	Current Stock: 5 Our Price: $0.60
34	003309478	HANDBRAKE SHOE LEVERPIN	2 req	Avail to order Our Price: $22.07
35	003309590	HANDBRAKE SHOE BRACKET	2 req	Avail to order Our Price: $453.24
36	008101225	SPECIAL SCREW M12X25	4 req	Avail to order Our Price: $21.68
37	WHT003055	WASHER 13X24X1.2 DIN137/B C72	4 req	Current Stock: 10 Our Price: $0.70
38	008401305	WASHER 13X22X* C 72	1 req	Avail to order Our Price: $0.30
39	003309362	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
40	008573701	O-RING I 37 UNI 3654	2 req	Avail to order Our Price: $0.80
41	008700814	SCREW D.8X25 UNI 2386 8G	2 req	Avail to order Our Price: $8.85
42	008200811	M8 UNI 5589/8G/ZDNUT	2 req	Avail to order Our Price: $6.81
43	003309388	NLA (NO LONGER AVAILABLE)	2 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
