1974 - 1978 Countach LP400 - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
004504532	BELT BELT		Current Stock: 1 Our Price: $55.72

Common repairs and upgrades

PN	Item
007021195	SHOCK ABSORBER COUNTACH DOOR SHOCK ABSORBER WITHOUT INTERNAL PARTS YOU MAY ALSO NEED N02214812 X1 HEX.HEAD 007021193 X1 SHOCK ABSOR.FIX.PIN TO DO 007021208 X1 SHOCK ABSORBER SECURPIN A 008580801 X1 O-RING E 8 UNI 7535-75 N01118410 X1 HEX.HEAD CLAMPING NUT WHT002962 X3 WASHER	Current Stock: 7 Our Price: $126.61
007029005	BONNET LIFTER BONNET LIFTER	Current Stock: 4 Our Price: $114.94
007029006	TRUNK LIFTER STRUT TRUNK LIFTER WITH STAB.	Current Stock: 4 Our Price: $89.17
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 2 Our Price: $1,431.28
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Avail to order Our Price: $350.83
002109861	NLA (NO LONGER AVAILABLE) ENGINE FLYWHEEL	Avail to order Our Price: $3,123.45
002109864	THRUST BEARING THRUST BEARING	Avail to order Our Price: $7,551.46
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION	Avail to order Our Price: $502.34
002021141	COUNTACH EFI FUEL INJECTION PUMP FUEL PUMP	Avail to order Our Price: $799.00
002021146	COLD START INJECTOR STARTER INJECTOR	Current Stock: 4 Our Price: $350.83
002021147	FUEL INJECTOR FOR COUNTACH FUEL INJECTOR FOR COUNTACH	Current Stock: 11 Our Price: $318.36
002021170	COUNTACH FUEL DISTRIBUTOR FUEL DISTRIBUTOR 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.46
002021172	FREQUENCY VALVE FREQUENCY VALVE BOSCH 0280150300 (028 0150 300)	Avail to order Our Price: $872.46
002021173	FUEL DAMPERS FUEL DAMPERS	Avail to order Our Price: $518.87
002021174	COUNTACH INJECTION EFI ECU ECU	Avail to order Our Price: $4,741.13
002021176	LAMBDA O2 SENSOR LAMBDA SENSOR *MAY NEED TO USE YOUR EXISTING CONNECTOR	Current Stock: 4 Our Price: $863.20
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01
002021142B	FUEL FILTER - COUNTACH - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL FILTER USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE. AS OF 1-3-2024 DOESN'T SHOW AVAILABILITY	Avail to order Our Price: $38.79
002021173b	FUEL DAMPERS - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL REGULATOR USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE.	Avail to order Our Price: $339.85
002021176OE	LAMBDA SENSORS LAMDA SENSORS	Current Stock: 2 Our Price: $126.18
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.01

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $11.06
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $13.59
006311154	RELAY RELAY	Avail to order Our Price: $56.11
006311155	RELAY RELAY	Avail to order Our Price: $67.29
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.90
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.86
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $20.28

Gaskets

PN	Item	Diagram
001526467	NLA (NO LONGER AVAILABLE) GROMMET & OIL SEALS SET		Avail to order Our Price: $132.32
001526487	NLA (NO LONGER AVAILABLE) ENGINE GASKET KIT SEE PN 001526467 FOR SEALS KIT		Avail to order Our Price: $1,597.77

Ignition

PN	Item	Diagram
001610428	DISTRIBUTOR/SPARK PLUG WIRES - DUAL DISTRIBUTOR IGNITION SYSTEM DISTRIBUTOR/SPARK PLUG WIRES		Avail to order Our Price: $1,295.63
001611403	COUNTACH WIRING HARNESS COUNTACH WIRING HARNESS		Avail to order Our Price: $2,876.02

Misc

PN	Item
006111300	LONG WIPER BLADE LONG WIPER BLADE	Current Stock: 1 Our Price: $54.16
006128790	WIPER SHORT BLADE 13 INCH WIPER SHORT BLADE (PREVIOUS PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $373.98

Sensors

PN	Item
002409895	REVERSE SWITCH REVERSE SWITCH NLA FROM FACTORY PLEASR CONTACT US FOR CURRENT PRICE AND AVAILABILITY	Avail to order Our Price: $127.96
002021143	THERMOSTAT SWITCH - EFI COUNTACH ONLY ORIGINAL OEM THERMOSTAT SWITCH - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.46
001724565	FAN MOTOR THERMAL CONTACT FAN MOTOR THERMAL CONTACT	Avail to order Our Price: $244.48
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.04
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $177.89

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 11 - Electrical System

1974 - 1978 Lamborghini Countach LP400 USA Electrical System (11)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	006111138	THREE-WAY/HORN PIPE	2 req	Avail to order Our Price: $5.23
2	006617028	This item is no longer available	1 req
3	001610771	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
4	001611773	This item is no longer available	1 req
5	001604746	BATTERY NEGATIVE WIRE	1 req	Avail to order Our Price: $609.79
6	008200804	NUT	4 req	Current Stock: 7 Our Price: $1.20
7	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $1.80
8	008700511	NLA	2 req	*See Description
9	001619328	FAN SPEED ADJUSTMENT RESISTOR	2 req	Avail to order Our Price: $152.39
10	N0211963	HEX.HEAD CLAMPING	2 req	Avail to order Our Price: $0.80
11	007005014	HEAT.MOT.RESISTEERING SUPPORT	1 req	Avail to order Our Price: $130.20
12	008200401	M4 UNI 5587/5S/Z	6 req	Avail to order Our Price: $0.10
13	008410405	ALLEN WASHER 4.3X8 DIN 137/A	6 req	Avail to order Our Price: $0.10
14	008700314	SCREW M4X10 UNI 61095S/Z	6 req	Avail to order Our Price: $2.92
15	008830109	DASHBOARD WIRE CLAMP	1 req	Avail to order Our Price: $8.85
16	006714081	EMERG.HOLDER	5 req	Avail to order Our Price: $28.10
17	006311154	RELAY	3 req	Avail to order Our Price: $56.11
18	006311830	VALVE PLATE	1 req	Avail to order Our Price: $196.04
19	001611379	NLA (NO LONGER AVAILABLE)	1 req	*See Description
20	001611380	NLA (NO LONGER AVAILABLE)	2 req	*See Description
21	001600906	DISTRIBUTOR BRACKET SEAL	2 req	Current Stock: 1 Our Price: $11.54
22	001600905	NLA (NO LONGER AVAILABLE)	2 req	*See Description
23	008613502	OIL SEAL	2 req	Current Stock: 9 Our Price: $10.95
24	006714079	ELECTRONIC BULB	1 req	Avail to order Our Price: $384.68
25	006311155	RELAY	1 req	Avail to order Our Price: $67.29
26	006111139	THREE-WAY/COMPRESSORPIPE	1 req	Avail to order Our Price: $15.27
27	006617029	This item is no longer available	1 req
28	006108392	THREE-WAY UNION	1 req	Current Stock: 4 Our Price: $1.30
29	006617030	HORN RELAY	1 req	Avail to order Our Price: $35.29
30	N01100637	HEX.NUT	12 req	Current Stock: 18 Our Price: $0.40
31	008300613	STUD M6X14 UNI 5911 8G/Z	8 req	Avail to order Our Price: $5.74
32		This item is no longer available	6 req
33		This item is no longer available	6 req
34	N0111849	HEX.HEAD CLAMPING NUT	6 req	Current Stock: 5 Our Price: $2.43
35	008820201	SPLIT PIN	2 req	Current Stock: 19 Our Price: $7.58
36	N10689901	HEX.NUT	2 req	Current Stock: 5 Our Price: $0.10
37	008410503	WASHER DIN 137A 5.3X10 ZGD.	2 req	Avail to order Our Price: $0.20
38	N10430103	HEXALOBULAR SOCKET	2 req	Current Stock: 21 Our Price: $0.90
39	001607059	CONDENSER	2 req	Current Stock: 6 Our Price: $86.42
40	001602984	NLA (NO LONGER AVAILABLE)	2 req	*See Description
41		This item is no longer available	1 req
42		This item is no longer available	1 req
43		This item is no longer available	1 req
44	007044005	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
45	008200602	M6 UNI 5588 5S/F NUT	4 req	Avail to order Our Price: $0.10
46	008300629	SPECIAL STUD M6X40	2 req	Avail to order Our Price: $26.74
47	008700801	SCREW M8X16 UNI 5933/5S/Z	2 req	Current Stock: 18 Our Price: $0.20
48	001606170	BATTERY WIRE TERMINALS	1 req	Avail to order Our Price: $62.62
49	WHT001197A	WASHER	12 req	Current Stock: 2 Our Price: $0.30
50	008300612	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
51	WHT003081	REFERENCE PIN 5H6X10C40	4 req	Avail to order Our Price: $12.62
52	008573202	O-RING I 30 UNI 3654	2 req	Avail to order Our Price: $6.52
53	001600376	DISTRIBUTOR P.T.O. SLEEVE	2 req	Avail to order Our Price: $486.06
54	001600377	DISTRIBUTOR P.T.O.	2 req	Avail to order Our Price: $193.12
55	001600371	DISTRIBUTOR MOUNT SHIM	2 req	Avail to order Our Price: $93.06
56	001601566	2 HOLE SPARK PLUG GROMMET	3 req	Avail to order Our Price: $75.03
57	001610428	DISTRIBUTOR/SPARK PLUG WIRES - DUAL DISTRIBUTOR IGNITION SYSTEM	1 req	Avail to order 1 Used Available Our Price: $1,295.63
58	001601565	4 HOLE SPARK PLUG GROMMET	2 req	Avail to order Our Price: $63.40
59	001601564	6 HOLE SPARK PLUG GROMMET	4 req	Avail to order Our Price: $52.80
60	008811402	This item is no longer available	12 req
61	001609441	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
62	001609855	ALTERNATOR DRIVE PULLEY	1 req	Avail to order Our Price: $381.67
63	001609856	ALTERNATOR	1 req	Avail to order Our Price: $2,467.47
64	006311152	LIGHT RELAY	2 req	Avail to order Our Price: $138.66
65	006990051	LH HEADL. ADJUSTMENTMOTOR	1 req	Avail to order 1 Used Available Our Price: $6,388.57
65	006990050	NLA (NO LONGER AVAILABLE)	1 req	*See Description
66	N01021626	HEXAGON HEAD BOLT	6 req	Current Stock: 8 Our Price: $1.50
67	008410603	WASHER D.6.4 UNI 1751/ZD	6 req	Avail to order Our Price: $0.10
68	001604460	NLA (NO LONGER AVAILABLE)	1 req	*See Description
69	008830114	GROMMET CLAMP	1 req	Avail to order Our Price: $116.72
70	001605394	SPARK PLUG WIRES CAP	2 req	Current Stock: 10 Our Price: $7.20
71	001601567	NLA (NO LONGER AVAILABLE)	7 req	*See Description
72	008301215	STARTER MOTOR SPECIAL STUD	2 req	Avail to order Our Price: $21.59
73	008411303	SNAP RING 21X13X2.5 UNI 175 1	2 req	Current Stock: 6 Our Price: $3.31
74	008201211	M12X1.75X10 UNI 5588/ 8G/Z	2 req	Avail to order Our Price: $9.53
75	001605790	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
76	001608173	This item is no longer available	3 req
77	001612580	EARTH BRAID C/MS-25	3 req	Avail to order Our Price: $10.99
78	001601335	IGNITION COIL	2 req	Current Stock: 1 Our Price: $156.07
79	001609853	ALTERNATOR DRIVE BELT	1 req	Avail to order Our Price: $90.83
80	008101036	SCREW M10X75 UNI 5737 8G	2 req	Avail to order Our Price: $6.90
81	008401006	WASHER 22X10.5X2.5 UNI 1734/5S	2 req	Current Stock: 1 Our Price: $0.60
82	008201008	NUT	2 req	Current Stock: 2 Our Price: $0.90
83		This item is no longer available	1 req
84		This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
