2012 AVENTADOR LP700-4 COUPE - USA

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137C	RIBBED V-BELT RIBBED V-BELT		Avail to order Our Price: $41.07

Brakes

PN	Item	Diagram
470698151	FRONT BRAKE PAD SET FRONT BRAKE PAD SET		Current Stock: 2 Our Price: $1,666.39
470698451	REAR BRAKE PAD SET REAR BRAKE PAD SET		Current Stock: 2 Our Price: $1,376.26

Drivetrain

PN	Item
07M105269C	SEE PN 07M105269D BALANCED CLUTCH MECHANISM	Avail to order Our Price: $8,288.36
07M115561	see PN 07M115561B Oil Filter Cartridge	Avail to order Our Price: $50.22
0CE141671A	CONCENTRIC SLAVE CYLINDER LP700 CONCENTRIC SLAVE CYLINDER	Avail to order Our Price: $1,451.55
0CE311675A	CLUTCH SENSOR - MASTER CYLINDER CLUTCH SENSOR - MASTER CYLINDER	Current Stock: 1 Our Price: $1,107.64
079905381	TRANSDUCER POS. TRANSDUCER POS.	Avail to order Our Price: $448.13
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 1 Our Price: $50.22

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $41.62
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $168.88

Fuses-Bulbs-Relays

PN	Item	Diagram
N01713118	FUSE Please Check your Part Manual for a Description		Current Stock: 18 Our Price: $2.00
N0177532	LAMP BULB LAMP BULB		Avail to order Our Price: $2.00

Ignition

PN	Item
7P0915105	BATTERY BATTERY	Avail to order Our Price: $587.70
470905619	SEE PN 470905619C SPARK PLUG	Avail to order Our Price: $104.90
470905619A	SPARK PLUG SPARK PLUG	Avail to order Our Price: $107.58

Misc

PN	Item
0R8340113	AVENTADOR CENTRAL LOCK CONVERSION KIT AVENTADOR CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,143.69
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
470898013	BLACK 73X CENTRAL LOCK CONVERSION KIT BLACK 73X CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,143.69
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $65.70
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $68.48
06A906262AT	O2 SENSOR-LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $149.62
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $37.90
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $890.28
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $203.22
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $969.58
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $46.75
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $46.75

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 145.02.00 - A/C COMPRESSOR

2012 Lamborghini AVENTADOR LP700-4 COUPE USA A/C COMPRESSOR (145.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	8K0260805H	AIR CONDITION COMPRESSOR LP700 COMPRESSOR	1 req	Avail to order Our Price: $1,196.97
1	8K0260805H	AIR CONDITION COMPRESSOR LP700 COMPRESSOR	1 req	Avail to order Our Price: $1,196.97
2		BRACKET (VALID UP TO MODEL YEAR 12 )	0 req
2	470260183	CLIP ANGLE BRACKET	1 req	Avail to order Our Price: $51.00
3	470260810B	Pulley PULLEY	1 req	Avail to order Our Price: $368.48
3	470260810E	PULLEY A/C PULLEY (FROM VIN DLA1411 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $1,110.62
4	470260877	COVER COVER	1 req	Avail to order Our Price: $253.84
4	470260877	COVER COVER	1 req	Avail to order Our Price: $253.84
5	470260095	SEE PNS 470260095A AND 470260810E AND N90809103 SHAFT	1 req	Avail to order Our Price: $54.64
5	470260095A	SHAFT COMPRESSORE SHAFT (FROM VIN DLA1411 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $471.94
6	470260097C	DEEP GROOVE BALL BEARING BEARING	1 req	Avail to order Our Price: $145.15
6	470260097C	DEEP GROOVE BALL BEARING BEARING	1 req	Avail to order Our Price: $145.15
7	N10756901	SEEGER SEEGER 47X1.75	1 req	Current Stock: 9 Our Price: $2.00
7	N10756901	SEEGER SEEGER 47X1.75	1 req	Current Stock: 9 Our Price: $2.00
8	WHT005222	SLOTTED ROUND NUT RING NUT M25X1,5	1 req	Avail to order Our Price: $55.61
8	WHT005222	SLOTTED ROUND NUT RING NUT M25X1,5	1 req	Avail to order Our Price: $55.61
9	N10531802	HEXAGON HEAD BOLT SCREW M8X100	2 req	Avail to order Our Price: $30.67
9	N10531802	HEXAGON HEAD BOLT SCREW M8X100	2 req	Avail to order Our Price: $30.67
10	N10561102	HEXAGON FLANGE BOLT SCREW 10X142X45	1 req	Avail to order Our Price: $8.79
10	N10665801	12-POINT SOCKET FLANGE BOLT SCREW M10X145	1 req	Avail to order Our Price: $53.52
11	470260845	Spacer SPACER	1 req	Avail to order Our Price: $1,256.52
11	470260845	Spacer SPACER	1 req	Avail to order Our Price: $1,256.52
12	07K260817	SEE PN 03L260817 BUSHING	2 req	Avail to order Our Price: $2.00
12	07K260817	SEE PN 03L260817 BUSHING	2 req	Avail to order Our Price: $2.00
13	N0152785	WASHER WASHER	2 req	Current Stock: 71 Our Price: $2.00
13		WASHER (VALID UP TO MODEL YEAR 12 )	0 req
14	N10406602	SCREW SCREW M5X8	4 req	Avail to order Our Price: $2.00
14	N10406602	SCREW SCREW M5X8	4 req	Avail to order Our Price: $2.00
15		SUPPORT (SEE TABLE 1450300)	0 req
15		SUPPORT (SEE TABLE 1450300)	0 req
16		SCREW M5X10 (VALID UP TO MODEL YEAR 12 )	0 req
16	N10586401	HEXALOBULAR SOCKET SCREW M5X10	1 req	Current Stock: 13 Our Price: $2.00
17	470260625A	HEAT SHIELD HEAT SHIELD	1 req	Avail to order Our Price: $711.64
17		HEAT SHIELD (VALID UP TO MODEL YEAR 12 )	0 req
18		SCREW M6X12 (VALID UP TO MODEL YEAR 12 )	0 req
18	N10406504	HEXALOBULAR SOCKET SCREW M6X12	2 req	Avail to order Our Price: $2.00
19	470260963	SHIELD HEAT SHIELD	1 req	Avail to order Our Price: $442.16
20	470260081	BRACKET BRACKET	1 req	Avail to order Our Price: $139.20
21	N90737804	HEXALOBULAR SOCKET SCREW M6X14	3 req	Avail to order Our Price: $2.00
22	N90809103	O-RING 16X2-N O-RING	1 req	Current Stock: 9 Our Price: $3.13
23		KIT PULLEY (KIT NOT AVAILABLE)	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
