2012 AVENTADOR LP700-4 COUPE - USA

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137C	RIBBED V-BELT RIBBED V-BELT		Avail to order Our Price: $41.07

Brakes

PN	Item	Diagram
470698151	FRONT BRAKE PAD SET FRONT BRAKE PAD SET		Current Stock: 2 Our Price: $1,666.39
470698451	REAR BRAKE PAD SET REAR BRAKE PAD SET		Current Stock: 2 Our Price: $1,376.26

Drivetrain

PN	Item
07M105269C	SEE PN 07M105269D BALANCED CLUTCH MECHANISM	Avail to order Our Price: $8,288.36
07M115561	see PN 07M115561B Oil Filter Cartridge	Avail to order Our Price: $50.22
0CE141671A	CONCENTRIC SLAVE CYLINDER LP700 CONCENTRIC SLAVE CYLINDER	Avail to order Our Price: $1,451.55
0CE311675A	CLUTCH SENSOR - MASTER CYLINDER CLUTCH SENSOR - MASTER CYLINDER	Current Stock: 1 Our Price: $1,107.64
079905381	TRANSDUCER POS. TRANSDUCER POS.	Avail to order Our Price: $448.13
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 1 Our Price: $50.22

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $41.62
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $168.88

Fuses-Bulbs-Relays

PN	Item	Diagram
N01713118	FUSE Please Check your Part Manual for a Description		Current Stock: 18 Our Price: $2.00
N0177532	LAMP BULB LAMP BULB		Avail to order Our Price: $2.00

Ignition

PN	Item
7P0915105	BATTERY BATTERY	Avail to order Our Price: $587.70
470905619	SEE PN 470905619C SPARK PLUG	Avail to order Our Price: $104.90
470905619A	SPARK PLUG SPARK PLUG	Avail to order Our Price: $107.58

Misc

PN	Item
0R8340113	AVENTADOR CENTRAL LOCK CONVERSION KIT AVENTADOR CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,143.69
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
470898013	BLACK 73X CENTRAL LOCK CONVERSION KIT BLACK 73X CENTRAL LOCK CONVERSION KIT	Avail to order Our Price: $9,143.69
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $65.70
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $68.48
06A906262AT	O2 SENSOR-LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $149.62
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $37.90
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $890.28
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $203.22
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $969.58
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $46.75
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $46.75

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 103.02.00 - OIL SUMP

2012 Lamborghini AVENTADOR LP700-4 COUPE USA OIL SUMP (103.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10709401	HEXAGON FLANGE SCREW BM8X120X80	1 req	Avail to order Our Price: $6.41
1	N10709401	HEXAGON FLANGE SCREW BM8X120X80	1 req	Avail to order Our Price: $6.41
2	N10689302	12-POINT SOCKET FLANGE BOLT SCREW M8X25	24 req	Avail to order Our Price: $3.28
2	N10689302	12-POINT SOCKET FLANGE BOLT SCREW M8X25	24 req	Avail to order Our Price: $3.28
3	07M103121C	GASKET SEAL	1 req	Avail to order Our Price: $17.42
3	07M103121	Sealing SEAL	2 req	Avail to order Our Price: $26.51
4	N91084501	O ring SEAL RING	1 req	Avail to order Our Price: $7.82
4	N91084501	O ring SEAL RING	1 req	Avail to order Our Price: $7.82
5	07M103627	Plug PLUG	1 req	Avail to order Our Price: $44.00
5	07M103627	Plug PLUG	1 req	Avail to order Our Price: $44.00
6	022103139B	SLEEVE BUSHING	6 req	Avail to order Our Price: $4.69
6	022103139B	SLEEVE BUSHING	6 req	Avail to order Our Price: $4.69
7		95 DIAMETER CYLINDER LINER (NOT AVAILABLE)	0 req
7		95 DIAMETER CYLINDER LINER (NOT AVAILABLE)	0 req
8		SEAL RING (NOT AVAILABLE)	0 req
8		SEAL RING (NOT AVAILABLE)	0 req
9	07M103937A	CAP PLUG	1 req	Avail to order Our Price: $280.64
9	07M103937A	CAP PLUG	1 req	Avail to order Our Price: $280.64
10	07M115540	SPRAY JET VALVE VALVE	1 req	Avail to order Our Price: $266.49
10	07M115540	SPRAY JET VALVE VALVE	1 req	Avail to order Our Price: $266.49
11	WHT000406	WASHER WASHER	1 req	Avail to order Our Price: $3.80
11	WHT000406	WASHER WASHER	1 req	Avail to order Our Price: $3.80
12	N91014801	O RING 11,11X1,78-N SEAL RING	14 req	Current Stock: 8 Our Price: $2.00
12	N91014801	O RING 11,11X1,78-N SEAL RING	14 req	Current Stock: 8 Our Price: $2.00
13	N90111301	O RING 12,42X1,78 SEAL RING	14 req	Current Stock: 4 Our Price: $2.00
13	N90111301	O RING 12,42X1,78 SEAL RING	14 req	Current Stock: 4 Our Price: $2.00
14	N90443601	O-RING SEAL RING	2 req	Avail to order Our Price: $9.23
14	N90443601	O-RING SEAL RING	2 req	Avail to order Our Price: $9.23
15	050121113B	THERMOSTAT WATER THERMOSTAT	2 req	Avail to order Our Price: $75.93
15	050121113B	THERMOSTAT WATER THERMOSTAT	2 req	Avail to order Our Price: $75.93
16	07M103649	SEAL SEAL	2 req	Avail to order Our Price: $26.35
16	07M103649	SEAL SEAL	2 req	Avail to order Our Price: $26.35
17	N91084801	HEXALOBULAR SOCKET SCREW M6X18	8 req	Current Stock: 18 Our Price: $2.00
17	N91084801	HEXALOBULAR SOCKET SCREW M6X18	8 req	Current Stock: 18 Our Price: $2.00
18	07M121121E	Cover COVER	2 req	Avail to order Our Price: $799.47
18	07M121121E	Cover COVER	2 req	Avail to order Our Price: $799.47
19	07L919561B	OIL PRESSURE GAUGE SENDER ENGINE OIL PRESSURE SENSOR	1 req	Avail to order Our Price: $890.28
19	07L919561B	OIL PRESSURE GAUGE SENDER ENGINE OIL PRESSURE SENSOR	1 req	Avail to order Our Price: $890.28
20	079905381	TRANSDUCER POS. CRANKSHAFT POSITION SENSOR	1 req	Avail to order Our Price: $448.13
20	06H906433C	PULSE GENERATOR CRANKSHAFT POSITION SENSOR	1 req	Avail to order Our Price: $95.73
21	N91096702	HEXALOBULAR SOCKET SCREW M6X16	1 req	Avail to order Our Price: $2.00
21	N91096702	HEXALOBULAR SOCKET SCREW M6X16	1 req	Avail to order Our Price: $2.00
22	470971504	BRACKET SUPPORT	1 req	Avail to order Our Price: $192.05
22		SUPPORT (VALID UP TO MODEL YEAR 12 )	0 req
23		SCREW M6X16 (VALID UP TO MODEL YEAR 12 )	0 req
23	N90780901	HEXALOBULAR SOCKET SCREW M6X16	1 req	Avail to order Our Price: $2.00
24	079907601	PULSE GENERATOR TRANSMISSION RANGE SENSOR	1 req	Avail to order Our Price: $192.80
24	079907601	PULSE GENERATOR TRANSMISSION RANGE SENSOR	1 req	Avail to order Our Price: $192.80
25	N91096702	HEXALOBULAR SOCKET SCREW M6X16	1 req	Avail to order Our Price: $2.00
25	N91096702	HEXALOBULAR SOCKET SCREW M6X16	1 req	Avail to order Our Price: $2.00
26	07M103158E	NOZZLE NOZZLE FOR PISTONS COOLING	7 req	Avail to order Our Price: $1,525.98
26	07M103158E	NOZZLE NOZZLE FOR PISTONS COOLING	7 req	Avail to order Our Price: $1,525.98
27	N10456103	PAN HEAD BOLT M4X10.0 SCREW M4X10	1 req	Avail to order Our Price: $2.00
27	N10456103	PAN HEAD BOLT M4X10.0 SCREW M4X10	1 req	Avail to order Our Price: $2.00
28	059919523A	TEMPERATURE SENDER TEMPERATURE SENSOR	2 req	Current Stock: 6 Our Price: $68.48
28	059919523A	TEMPERATURE SENDER TEMPERATURE SENSOR	2 req	Current Stock: 6 Our Price: $68.48
29	470971729	PROTECTIVE HOSE CONNETT.PRESS.OLIO HEATING PROTECTION SHEATH	1 req	Avail to order Our Price: $44.97
30	N10562301	CLAMP CLAMP	1 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
