Lamborghini Aventador LP700 Parts

0 items in your cart
Your Shopping Cart
  • Your cart is empty
Subtotal: $0.00
Shipping: $0.00
Total: $0.00

Maintenance Parts:

Belts

PN Item Diagram
07M903137C RIBBED V-BELT
RIBBED V-BELT
view diagram Current Stock: 2
Our Price: $30.16
RIBBED V-BELT

Brakes

PN Item Diagram
470698151 FRONT BRAKE PAD SET
FRONT BRAKE PAD SET
view diagram Current Stock: 2
Our Price: $1,366.19
FRONT BRAKE PAD SET
470698451 REAR BRAKE PAD SET
REAR BRAKE PAD SET
view diagram Current Stock: 2
Our Price: $1,366.19
REAR BRAKE PAD SET

Drivetrain

PN Item Diagram
07M105269C SEE PN 07M105269D
BALANCED CLUTCH MECHANISM
Avail to order
Our Price: $7,286.40
SEE PN 07M105269D
07M115561 see PN 07M115561B
Oil Filter Cartridge
Avail to order
Our Price: $38.91
see PN 07M115561B
0CE141671A CONCENTRIC SLAVE CYLINDER LP700
CONCENTRIC SLAVE CYLINDER
view diagram Current Stock: 1
Our Price: $861.74
CONCENTRIC SLAVE CYLINDER LP700
0CE311675A CLUTCH SENSOR - MASTER CYLINDER
CLUTCH SENSOR - MASTER CYLINDER
view diagram Current Stock: 2
Our Price: $788.08
CLUTCH SENSOR - MASTER CYLINDER
079905381 TRANSDUCER POS.
TRANSDUCER POS.
view diagram Avail to order
Our Price: $71.73
TRANSDUCER POS.
07M115561B SPIN-ON FILTER CARTUCCIS FIL.OLIO
SPIN-ON FILTER CARTUCCIS FIL.OLIO
Current Stock: 6
Our Price: $38.91
SPIN-ON FILTER    CARTUCCIS FIL.OLIO

Fuel-Air

PN Item Diagram
4D0906321C FUEL FILTER
FILTER
view diagram Current Stock: 3
Our Price: $30.67
FUEL FILTER
470133843A FILTER ELEMENT
FILTER ELEMENT
view diagram Current Stock: 3
Our Price: $103.19
FILTER ELEMENT

Fuses-Bulbs-Relays

PN Item Diagram
N01713118 FUSE
Please Check your Part Manual for a Description
view diagram Current Stock: 19
Our Price: $2.00
FUSE
N0177532 LAMP BULB
LAMP BULB
view diagram Avail to order
Our Price: $2.00

Ignition

PN Item Diagram
7P0915105 BATTERY
BATTERY
view diagram Avail to order
Our Price: $419.74
470905619 SPARK PLUG
SPARK PLUG
view diagram Current Stock: 12
Our Price: $77.09
SPARK PLUG
470905619A SPARK PLUG
SPARK PLUG
Avail to order
Our Price: $78.99

Misc

PN Item Diagram
900000382 BATTERY CHARGER USA BC
BATTERY CHARGER USA BC
Current Stock: 2
Our Price: $154.66
BATTERY CHARGER USA BC
900000381 BATTERY CHARGER ROW BC - EURO
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Current Stock: 6
Our Price: $154.66
BATTERY CHARGER ROW BC - EURO
0R8340113 AVENTADOR CENTRAL LOCK CONVERSION KIT
AVENTADOR CENTRAL LOCK CONVERSION KIT
Avail to order
Our Price: $5,155.00
470898013 BLACK 73X CENTRAL LOCK CONVERSION KIT
BLACK 73X CENTRAL LOCK CONVERSION KIT
Avail to order
Our Price: $5,155.00
N0300574 KEY - Spanner Murcielago-Aventador-Huracan
Wrench Spanner Murcielago-Aventador-Huracan
Avail to order
Our Price: $6.97
KEY - Spanner Murcielago-Aventador-Huracan

Sensors

PN Item Diagram
07L905163A SEE PN 07L905163C
PHASE SENSOR
view diagram Avail to order
Our Price: $26.96
SEE PN 07L905163C
4F0907275D See PN 7PP907275F
WHEEL ELECTRONICS
Avail to order
Our Price: $144.68
059919523A TEMPERATURE SENDER
TEMPERATURE SENDER
view diagram Current Stock: 18
Our Price: $48.57
TEMPERATURE SENDER
07L919561B OIL PRESSURE GAUGE SENDER
OIL PRESSURE GAUGE SENDER
view diagram Current Stock: 2
Our Price: $211.25
OIL PRESSURE GAUGE  SENDER
06A906262AT O2 SENSOR-LAMBDA PROBE
LAMBDA PROBE
view diagram Avail to order
Our Price: $336.02
O2 SENSOR-LAMBDA PROBE
4E0927804 ABS SENSOR RIGHT
ABS SENSOR RIGHT
Avail to order
Our Price: $33.27
ABS SENSOR RIGHT
4E0927803 ABS SENSOR LEFT
ABS SENSOR LEFT
Current Stock: 5
Our Price: $33.27
ABS SENSOR LEFT
Open All

Select Group and TAV

TAV: 505.01.00 - REAR ARMS

2012 Lamborghini AVENTADOR LP700-4 COUPE ENGLAND REAR ARMS (505.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 SHOCK ABSORBER (SEE TABLE 512.01.00) 0 req
1 SHOCK ABSORBER (SEE TABLE 512.01.00) 0 req
2 WHT005396 TAP END STUD
STUD BOLT M10X1,25XM10X45
8 req Avail to order
Our Price: $9.51
TAP END STUD
2 WHT005396 TAP END STUD
STUD BOLT M10X1,25XM10X45
8 req Avail to order
Our Price: $9.51
TAP END STUD
3 N10272302 HEX.NUT W/ FLANGE
NUT M10
16 req Avail to order
Our Price: $2.00
HEX.NUT W/ FLANGE
3 N10272302 HEX.NUT W/ FLANGE
NUT M10
16 req Avail to order
Our Price: $2.00
HEX.NUT W/ FLANGE
4 0R8340064 REAR SUSPENSION KIT
KIT REAR AXLE (UNTIL THE VIN CLA01031 - INCLUDES: LH RH UPPER LOWER ARM - NUT M14 - REAR LH RH HUB CARRIER)
1 req Avail to order
Our Price: $3,929.97
4 WHT004898 HEXAGON FLANGE NUT W.WASHER
NUT M14X1,5 (FROM VIN CLA01032)
4 req Current Stock: 3
Our Price: $4.77
HEXAGON FLANGE NUT  W.WASHER
4 WHT004995 PREV.TORQUE HEX.
NUT M12X1,5
6 req Avail to order
Our Price: $3.67
5 N10736901 HEXAGON FLANGE BOLT
SCREW M12X1,5X95
2 req Avail to order
Our Price: $67.21
5 N10736901 HEXAGON FLANGE BOLT
SCREW M12X1,5X95
2 req Avail to order
Our Price: $67.21
6 N10106402 HEX.NUT W/FLANGE LOCKING ELEM.
NUT M12X1,5
6 req Avail to order
Our Price: $2.00
HEX.NUT W/FLANGE LOCKING ELEM.
6 N10106402 HEX.NUT W/FLANGE LOCKING ELEM.
NUT M12X1,5
6 req Avail to order
Our Price: $2.00
HEX.NUT W/FLANGE LOCKING ELEM.
7 REAR HUB CARRIER (SEE TABLE 505.02.00) 0 req
7 REAR HUB CARRIER (SEE TABLE 505.02.00) 0 req
8 N91055501 HEXALOBULAR SOCKET
SCREW M5POWX12
4 req Avail to order
Our Price: $2.00
8 N91055501 HEXALOBULAR SOCKET
SCREW M5POWX12
4 req Avail to order
Our Price: $2.00
9 N10689301 12-POINT SOCKET
SCREW M8X25
8 req Current Stock: 4
Our Price: $2.00
12-POINT SOCKET
9 N10689301 12-POINT SOCKET
SCREW M8X25
8 req Current Stock: 4
Our Price: $2.00
12-POINT SOCKET
10 N10640301 HEXAGON FLANGE
SCREW BM12X1,5X100X90
2 req Avail to order
Our Price: $4.11
10 N10640301 HEXAGON FLANGE
SCREW BM12X1,5X100X90
2 req Avail to order
Our Price: $4.11
11 WHT005397 TAP END STUD
STUD BOLT M10X1,25XM10X39
8 req Avail to order
Our Price: $13.86
11 WHT005397 TAP END STUD
STUD BOLT M10X1,25XM10X39
8 req Avail to order
Our Price: $13.86
12 WHT004856 ECCENTRIC BOLT
SCREW M12X1,5X75
2 req Avail to order
Our Price: $48.55
12 WHT004856 ECCENTRIC BOLT
SCREW M12X1,5X75
2 req Avail to order
Our Price: $48.55
13 WHT001676 ECCENTRIC WASHER
WASHER
2 req Current Stock: 10
Our Price: $2.00
ECCENTRIC WASHER
13 WHT001676 ECCENTRIC WASHER
WASHER
2 req Current Stock: 10
Our Price: $2.00
ECCENTRIC WASHER
14 0R8340064 REAR SUSPENSION KIT
KIT REAR AXLE (UNTIL THE VIN CLA01031 - INCLUDES: LH RH UPPER LOWER ARM - NUT M14 - REAR LH RH HUB CARRIER)
1 req Avail to order
Our Price: $3,929.97
14 470505311F TRACK CONTROL ARM
LH LOWER ARM (FROM VIN CLA01032)
1 req Avail to order
Our Price: $1,010.84
14 470505312F TRACK CONTROL ARM
RH LOWER ARM (FROM VIN CLA01032)
1 req Avail to order
Our Price: $1,010.84
14 470505311D TRACK CONTROL ARM
LH LOWER ARM (UNTIL THE VIN CLA00135)
1 req Avail to order
Our Price: $1,026.31
14 470505311E TRACK CONTROL ARM
LH LOWER ARM (FROM VIN CLA00136)
1 req Avail to order
Our Price: $1,028.63
14 470505312D TRACK CONTROL ARM
RH LOWER ARM (UNTIL THE VIN CLA00135)
1 req Avail to order
Our Price: $1,068.82
14 470505312E TRACK CONTROL ARM
RH LOWER ARM (FROM VIN CLA00136)
1 req Avail to order
Our Price: $1,028.63
15 470971005 CABLE HOLDER
BRACKET
4 req Avail to order
Our Price: $13.60
15 470971005 CABLE HOLDER
BRACKET
4 req Avail to order
Our Price: $13.60
16 470407203 BACKING PLATE
1 MM SHIM
4 req Avail to order
Our Price: $70.55
BACKING PLATE
16 470407203A BACKING PLATE
5.0 MM SHIM
4 req Avail to order
Our Price: $70.55
BACKING PLATE
16 470407203B BACKING PLATE
3 MM SHIM
4 req Avail to order
Our Price: $63.25
BACKING PLATE
16 470407203 BACKING PLATE
1 MM SHIM
4 req Avail to order
Our Price: $70.55
BACKING PLATE
16 470407203A BACKING PLATE
5.0 MM SHIM
4 req Avail to order
Our Price: $70.55
BACKING PLATE
16 470407203B BACKING PLATE
3 MM SHIM
4 req Avail to order
Our Price: $63.25
BACKING PLATE
17 470501529D TIE ROD
LH LOWER ARM (UNTIL THE VIN CLA00135)
1 req Avail to order
Our Price: $458.17
17 470501529D TIE ROD
LH LOWER ARM (UNTIL THE VIN CLA00135)
1 req Avail to order
Our Price: $458.17
17 470501529E TIE ROD
LH LOWER ARM (FROM VIN CLA00136)
1 req Avail to order
Our Price: $405.87
17 470501530D TIE ROD
RH LOWER ARM (UNTIL THE VIN CLA00135)
1 req Avail to order
Our Price: $458.17
17 470501530E TIE ROD
RH LOWER ARM (FROM VIN CLA00136)
1 req Avail to order
Our Price: $405.87
17 470501529E TIE ROD
LH LOWER ARM (FROM VIN CLA00136)
1 req Avail to order
Our Price: $405.87
17 470501530D TIE ROD
RH LOWER ARM (UNTIL THE VIN CLA00135)
1 req Avail to order
Our Price: $458.17
17 470501530E TIE ROD
RH LOWER ARM (FROM VIN CLA00136)
1 req Avail to order
Our Price: $405.87
18 470505323E TRACK CONTROL ARM
LH UPPER ARM (UNTIL THE VIN CLA00135)
1 req Avail to order
Our Price: $666.86
18 470505323F TRACK CONTROL ARM
LH UPPER ARM (FROM VIN CLA00136)
1 req Avail to order
Our Price: $641.76
18 470505324E TRACK CONTROL ARM
RH UPPER ARM (UNTIL THE VIN CLA00135)
1 req Avail to order
Our Price: $640.32
18 470505324F TRACK CONTROL ARM
RH UPPER ARM (FROM VIN CLA00136)
1 req Avail to order
Our Price: $641.76
18 0R8340064 REAR SUSPENSION KIT
KIT REAR AXLE (UNTIL THE VIN CLA01031 - INCLUDES: LH RH UPPER LOWER ARM - NUT M14 - REAR LH RH HUB CARRIER)
1 req Avail to order
Our Price: $3,929.97
18 470505323G TRACK CONTROL ARM SUP.POST SX
LH UPPER ARM (FROM VIN CLA01032)
1 req Avail to order
Our Price: $552.28
18 470505324G TRACK CONTROL ARM SUP.POST DX
RH UPPER ARM (FROM VIN CLA01032)
1 req Avail to order
Our Price: $552.28
19 470513387B PUSH ROD
STRUT,BUMPER
2 req Avail to order
Our Price: $211.64
PUSH ROD
19 470513387B PUSH ROD
STRUT,BUMPER
2 req Avail to order
Our Price: $211.64
PUSH ROD
20 470501430A MOUNTING
SUPPORT
4 req Avail to order
Our Price: $43.43
20 470501430A MOUNTING
SUPPORT
4 req Avail to order
Our Price: $43.43
21 WHT004995 PREV.TORQUE HEX.
NUT M12X1,5
2 req Avail to order
Our Price: $3.67

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
