TAV: 52.02.00 - REAR SUSPENSION

2003 Lamborghini MURCIELAGO COUPE USA REAR SUSPENSION (52.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10725301	HEX.HEAD CLAMPING NUT 12X1,25X14,8	8 req	Avail to order Our Price: $2.00
2	410407135	Offset Screw and Slot CAM	8 req	Avail to order Our Price: $42.41
3	410407515A	BEARING FLEXIBLE BUSHING	2 req	Current Stock: 1 Our Price: $391.79
4	410407127A	ECCENTRIC SCREW	8 req	Avail to order Our Price: $1,010.31
5	008200804	Nut NUT	4 req	Current Stock: 7 Our Price: $2.00
6	410411317	CONNECTING LINK CONNECTING ROD	2 req	Avail to order Our Price: $429.10
8	0052008792	STABILIZER BAR STABILIZER BAR	1 req	Avail to order 1 Used Available Our Price: $2,251.61
9	WHT000923	CHEESE HEAD SCREW SCREW	4 req	Current Stock: 1 Our Price: $7.97
10	WHT001197A	WASHER WASHER	4 req	Current Stock: 2 Our Price: $2.00
11	400411031D	STABILIZER U-BOLT	2 req	Current Stock: 29 Our Price: $199.48
12	400511324C	BUSH BUSHING	2 req	Avail to order Our Price: $55.90
13	410512383	Extendible 012 X 042X 46 X 35 FLEXIBLE BUSHING	8 req	Avail to order Our Price: $591.26
14	008101281	SCREEW SCREW M12X70	8 req	Avail to order Our Price: $17.59
15	410512108	SCHOCK ABSORBER BUKHEAD PANEL	4 req	Avail to order Our Price: $44.85
16	005133618	Suspension Spring SPRING	4 req	Avail to order Our Price: $215.16
17	410512385	Shock Absorber Bulkhead RUBBER RING	4 req	Avail to order 1 Used Available Our Price: $53.68
18	0052010976	ELECTRONIC SHOCK ABSORBER REAR ELECTRONICALLY-CONTROLLED SHOCK ABSORBER	4 req	Avail to order Our Price: $5,402.61
19	N10268603	HEX.HEAD CLAMPING NUT € NUT	4 req	Avail to order Our Price: $6.82
20	0052008726	Rear LH Lower ARM LH LOWER ARM	1 req	Avail to order Our Price: $1,227.01
20	0052008728	ARM RH LOWER ARM	1 req	Avail to order Our Price: $708.95
21	410505365	JOINT BALL JOINT	2 req	Current Stock: 1 Our Price: $236.08
22	400407749	spacer bush 0.5 MM SHIM	24 req	Current Stock: 77 Our Price: $3.23
22	400407739	spacer bush 1.0 MM SHIM	24 req	Current Stock: 76 Our Price: $3.59
22	400407740	spacer bush 1.5 MM SHIM	24 req	Current Stock: 54 Our Price: $4.09
22	400407742	spacer bush 2.0 MM SHIM	24 req	Current Stock: 60 Our Price: $4.67
23	0052008857	LOWER REAR HUB CARRIER BOLT JOURNAL	2 req	Avail to order Our Price: $149.98
24	410505361	Rear LH Upper ARM LH UPPER ARM	1 req	Avail to order Our Price: $2,633.41
24	410505362	ARM RH UPPER ARM	1 req	Avail to order Our Price: $3,293.55
25	0052008858	UPPER REAR HUB CARRIER BOLT JOURNAL	2 req	Avail to order Our Price: $149.98
26	410407295	SPACER RING 1.0 MM ADJUSTMENT SHIM	1 req	Current Stock: 28 Our Price: $4.52
26	410407295A	SPACER RING 1.5 MM ADJUSTMENT SHIM	1 req	Current Stock: 15 Our Price: $6.82
26	410407295B	SPACER RING 2.0 MM ADJUSTMENT SHIM	1 req	Current Stock: 10 Our Price: $6.67
26	410407295C	SPACER RING (Previosly PN 005133490) 2.5 MM ADJUSTMENT SHIM	1 req	Current Stock: 15 Our Price: $7.39
26	410407295D	SPACER RING WASHER	1 req	Current Stock: 9 Our Price: $29.86
27	0052010342	PROTECTION PROTECTION	2 req	Avail to order Our Price: $17.37
28	400511324	STABILIZER BUSHING STABILIZER BUSHING	1 req	Current Stock: 10 Our Price: $88.70
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
