TAV: 18.02.00 - CRANKCASE AND LOWER MOUNTING

2003 Lamborghini MURCIELAGO COUPE USA CRANKCASE AND LOWER MOUNTING (18.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	Q.ty</span></nobr></DIV>	Description	0 req
1	001824761	Cylinder Head Stud On Crankcas STUD BOLT	28 req	Avail to order Our Price: $119.61
2	008401230	Washer WASHER	28 req	Avail to order Our Price: $57.97
3	001120924	Stud Nut CAP NUT	28 req	Avail to order Our Price: $42.49
4	WHT003085	Cylinder Liner Rubber Washer m SEAL RING	12 req	Avail to order Our Price: $4.66
5	07M103321A	cylinder line diam. 87 87 DIAMETER CYLINDER LINER	12 req	Avail to order 9 Used Available Our Price: $7,882.97
6	N01152427	WASHER WASHER	2 req	Current Stock: 16 Our Price: $2.00
7	008700609	Screw 6x45 Uni 5931/8g/Zd SCREW	2 req	Avail to order Our Price: $2.00
8	WHT002944	TAP END STUD STUD BOLT	1 req	Avail to order Our Price: $17.87
9	WHT003030	TAP END STUD STUD BOLT	2 req	Avail to order Our Price: $12.91
10	N0444416	TAP END STUD STUD BOLT	2 req	Avail to order Our Price: $3.79
11	WHT003098	Check your book Description DOWEL	2 req	Avail to order Our Price: $32.04
12	008301050	STUD M10 65-20-26 10.9 ZD (5914) STUD BOLT	8 req	Avail to order Our Price: $34.37
13	008601201	Ring 13 mm Or SEAL RING	2 req	Avail to order Our Price: $2.00
14	WHT003030	TAP END STUD STUD BOLT	1 req	Avail to order Our Price: $12.91
15	WHT003028	TAP END STUD STUD BOLT	2 req	Avail to order Our Price: $22.20
16	410109445	Tab 15x5x5 Uni 92/C40 KEY	1 req	Current Stock: 9 Our Price: $2.00
17	008101642	SCREW SCREW	1 req	Current Stock: 3 Our Price: $5.06
18	WHT003056	WASHER WASHER	1 req	Current Stock: 6 Our Price: $2.33
19	07M105255	PULLEY,SHAFT PULLEY	1 req	Avail to order Our Price: $1,263.95
20	WHT003103	SEALING RING SEAL RING	1 req	Avail to order Our Price: $69.33
21	400147003	ENGINE BLOCK ENGINE BLOCK	1 req	Avail to order Our Price: $25,965.20
22	008700861	SCREW M8*25 10K ZD UNI 5931 SCREW	4 req	Avail to order Our Price: $2.00
23	WHT000771	SPRING LOCK WASHER WASHER	4 req	Current Stock: 10 Our Price: $2.00
24	008300902	Stud M8x35 Uni 5914 8g/Z STUD BOLT	5 req	Avail to order Our Price: $10.70
25	N01100845	HEX.NUT NUT	14 req	Current Stock: 17 Our Price: $2.14
26	008410815	Washer 8.4x15x0.5 Din137/B C70 WASHER	14 req	Current Stock: 28 Our Price: $2.00
27	WHT003166	TAP END STUD STUD BOLT	3 req	Avail to order Our Price: $54.08
28	07M103729	CRANCKCASE PANEL PANEL	1 req	Avail to order Our Price: $50.49
29	07M103730	CRANCKCASE PANEL PANEL	3 req	Avail to order Our Price: $47.38
30	008700416	Screw M4x10 Uni 59318g SCREW	12 req	Current Stock: 6 Our Price: $2.00
31	008410402	Washer D.4.3 Uni 1751 /Zd WASHER	12 req	Current Stock: 15 Our Price: $2.00
32	WHT003024	NUT NUT	14 req	Avail to order Our Price: $280.62
33	07M103749	CRANCKCASE PANEL PANEL	2 req	Avail to order Our Price: $49.23
34	WHT003046	WASHER WASHER	14 req	Avail to order Our Price: $124.48
35	WHT003038	TAP END STUD STUD BOLT	14 req	Avail to order Our Price: $25.83
36	WHT003033	TAP END STUD STUD BOLT	13 req	Avail to order Our Price: $17.67
37	07L919561B	OIL PRESSURE GAUGE SENDER PRESSURE SENSOR	1 req	Avail to order Our Price: $928.96
38	WHT003097	Reference Pin 11h7x16 C40 DOWEL	4 req	Avail to order Our Price: $12.23
39	008300839	Stud M8x28 Uni 5911 8g Z STUD BOLT	1 req	Avail to order Our Price: $8.14
40	WHT003043	WASHER WASHER	14 req	Avail to order Our Price: $42.34
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
