TAV: 72.02.00 - Doors

1999 Lamborghini Diablo 2WD-4WD USA Doors (72.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	009421055	Rh Diablo Door/Sv	1 req	Avail to order Our Price: $10,108.35
1	009421056	Left Door Diablov	1 req	Avail to order Our Price: $10,108.35
2	410837983	Door Hinge Shim 0.8 mm	req	Current Stock: 1 Our Price: $19.51
2	410837983A	Door Hinge Shim 1 mm	req	Avail to order Our Price: $21.66
2	410837983B	Door Hinge Shim 1.2 mm	req	Current Stock: 1 Our Price: $17.72
2	410837983C	Door Hinge Shim 1.5 mm	req	Avail to order Our Price: $21.15
3	009421030	LH Door Hinge	1 req	Avail to order 2 Used Available Our Price: $1,487.93
3	009421029	RH Door Hinge	1 req	Avail to order 1 Used Available Our Price: $1,478.98
4	009421381	Door Hinge Shim mm.1.5	req	Avail to order Our Price: $32.88
4	410837944A	Door Hinge Shim mm.1	req	Avail to order Our Price: $20.70
5	008900401	Elastic Pin 4x20 Din1481	4 req	Current Stock: 5 Our Price: $2.00
6	N90179103	WASHER	8 req	Current Stock: 5 Our Price: $2.00
7	N01024230	HEXAGON HEAD BOLT	8 req	Current Stock: 4 Our Price: $2.00
8	008411015	Washer Tab Fiat 1119579	8 req	Current Stock: 8 Our Price: $13.13
9	008101008	Screw M10x30uni 5739/8g/Zd	8 req	Current Stock: 3 Our Price: $17.20
10	009421031	Door Gas Strut	2 req	Avail to order Our Price: $128.72
11	WHT003304	Lock Screw 2.9x16din7981/Cr B	2 req	Current Stock: 20 Our Price: $2.00
12	005934450	DOOR PIN SWITCH	2 req	Avail to order Our Price: $25.01
13	005934447	Door Button Shim	2 req	Avail to order Our Price: $86.78
14	008830411	Spring	2 req	Current Stock: 1 Our Price: $2.00
15	008830302	Grommet mm 500x113x17	10 req	Avail to order Our Price: $4.31
16	009421606	Winder Motor Wiring	2 req	Avail to order Our Price: $29.38
17	009421607	Pin And Bracket	4 req	Avail to order Our Price: $69.11
18	009421408	WINDOW STOP PAD	4 req	Avail to order Our Price: $22.45
19	009421406	Door Window Stop Pad	2 req	Avail to order Our Price: $56.28
19	009421407	Door Window Stop Pad	2 req	Avail to order Our Price: $11.11
20	WHT003040	WASHER	8 req	Current Stock: 2 Our Price: $8.12
21	N01020717	HEXAGON HEAD BOLT	8 req	Current Stock: 4 Our Price: $2.00
22	N01508213	HEXAGON FLANGE NUT	6 req	Current Stock: 4 Our Price: $2.00
23	WHT003040	WASHER	8 req	Current Stock: 2 Our Price: $8.12
24	N0211963	HEX.HEAD CLAMPING	8 req	Avail to order Our Price: $2.00
25	009421604	Rh Door Motor	1 req	Avail to order Our Price: $569.53
25	009421605	Lh Door Motor	1 req	Avail to order Our Price: $569.53
26	009421600	RH Window motor and regulator assembly	1 req	Avail to order Our Price: $695.59
26	009421601	LH Window motor and regulator assembly	1 req	Avail to order Our Price: $2,296.35
27	WHT002961	WASHER	8 req	Current Stock: 38 Our Price: $2.00
28	008700663	Screw M6	8 req	Current Stock: 11 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
