TAV: 18.03.01 - Oil Sump

1999 Lamborghini Diablo 2WD-4WD USA Oil Sump (18.03.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	WHT000771	SPRING LOCK WASHER	18 req	Current Stock: 10 Our Price: $2.00
2	008300839	Stud M8x28 Uni 5911 8g Z	8 req	Avail to order Our Price: $8.18
2	008300806	Stud M8x70 Uni 5911 9g Z	6 req	Avail to order Our Price: $6.49
2	008300897	Stud M8x106 8g	4 req	Avail to order Our Price: $17.38
3	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $46.98
4	001827775	Oil Sump Bulkhead	1 req	Avail to order Our Price: $99.75
5	008700644	Screw M6x12 Uni 5931/8g/Zd	8 req	Current Stock: 3 Our Price: $2.00
6	WHT001197A	WASHER	8 req	Current Stock: 2 Our Price: $2.00
7	086301047D	Breather pipe	1 req	Avail to order Our Price: $15.49
8	0023001636	Breather Extension Pipe	1 req	Avail to order Our Price: $102.28
9	008700547	Screw M5x16 Uni 5931/8g/B	1 req	Avail to order Our Price: $2.00
10	008410503	Washer Din 137a 5.3x10 Zgd.	1 req	Avail to order Our Price: $2.00
11	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $46.98
12	WHT000768	SPRING WASHER	10 req	Current Stock: 17 Our Price: $2.09
13	N10155210	HEX.NUT	10 req	Current Stock: 38 Our Price: $2.17
14	410971250	Engine/Chassis/Exhaust Pipe Ea	2 req	Avail to order Our Price: $72.58
15	008932602	Cap 26x1.5x12 Din 906/B	1 req	Current Stock: 1 Our Price: $4.10
16	086301141A	Magnetic Plug 22x1.5	2 req	Avail to order Our Price: $39.91
17	WHT003614	This item is no longer available	1 req
18	004126765	Rear Differential Frame Mount	2 req	Avail to order Our Price: $319.80
19	0B9501144	SILENTBLOC	1 req	Avail to order Our Price: $262.02
20	410813761A	REINF.PLATE	req	Current Stock: 5 Our Price: $46.98
21	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
22	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
23	N01033520	HEXAGON HEAD BOLT	4 req	Current Stock: 6 Our Price: $2.00
24	008101430	Screw 14x2x80uni57378g Zg	1 req	Current Stock: 3 Our Price: $4.10
25	0018001643	Differential Cover Fastening S	10 req	Avail to order Our Price: $15.06
26	450132001	Mach. MY98 Oil Sump	1 req	Avail to order Our Price: $10,727.08
27	WHT002222	O-RING	1 req	Current Stock: 9 Our Price: $14.15
28	001832017	Oil Sump Intake Terminal	1 req	Avail to order Our Price: $381.68
29	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
30	008700644	Screw M6x12 Uni 5931/8g/Zd	4 req	Current Stock: 3 Our Price: $2.00
31	001826521	Oil Sump Cover Seal	1 req	Avail to order Our Price: $145.07
32	001831852	NLA (No Longer Available)	1 req	*See Description
33	008402202	Annealed Washer.D.22x30	1 req	Current Stock: 1 Our Price: $5.00
34	008932211	Plug Din 908 M22x1.5/Z	1 req	Avail to order Our Price: $25.76
35	008100603	Screw M6x25 Uni 5739-8g Zg	20 req	Avail to order Our Price: $2.00
36	WHT001197A	WASHER	20 req	Current Stock: 2 Our Price: $2.00
37	N01100845	HEX.NUT	18 req	Current Stock: 17 Our Price: $2.09
38	001830006	Oil Dipstick Pipe Seal	1 req	Avail to order Our Price: $8.33
39	001837263	Oil Dipstick Assembly	1 req	Avail to order Our Price: $121.06
40	WHT001197A	WASHER	3 req	Current Stock: 2 Our Price: $2.00
41	N01021626	HEXAGON HEAD BOLT	3 req	Current Stock: 8 Our Price: $2.00
42	008300808	Stud M8x35 Uni 5911 8g Z	2 req	Avail to order Our Price: $6.02
43	001837261	Oil Dipstick	1 req	Avail to order Our Price: $346.32
44	WHT003028	TAP END STUD	1 req	Avail to order Our Price: $22.23
45	008100830	Screw M8x20 Uni 5739/8g/Z	2 req	Current Stock: 19 Our Price: $2.00
46	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $2.00
47	001836047	Rh Oil Sump Bulkhead	1 req	Avail to order Our Price: $469.64
48	001836048	Lh Oil Sump Bulkhead	1 req	Avail to order Our Price: $469.64
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
