TAV: 52.02.01 - Rear Suspension

1999 Lamborghini Diablo 2WD-4WD USA Rear Suspension (52.02.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	WHT003355	clamping nut	8 req	Current Stock: 13 Our Price: $23.50
2	410407135A	ECCENTRIC BUSH	8 req	Current Stock: 2 Our Price: $88.85
3	410407295	SPACER RING	req	Current Stock: 27 Our Price: $4.86
3	410407295A	SPACER RING	req	Current Stock: 15 Our Price: $7.28
3	005133489	Lock Flange Adjustment Shim 2	req	Current Stock: 8 Our Price: $4.36
3	410407295C	SPACER RING (Previosly PN 005133490)	req	Current Stock: 15 Our Price: $7.87
3	410407295D	SPACER RING	req	Current Stock: 11 Our Price: $31.95
4	008921206	Flanbloc	8 req	Avail to order Our Price: $50.12
5	410407127A	ECCENTRIC	8 req	Avail to order Our Price: $1,079.36
6	N0111849	HEX.HEAD CLAMPING NUT	4 req	Current Stock: 5 Our Price: $2.43
7	005227297	Ball Joint Bushing	8 req	Current Stock: 2 Our Price: $32.28
8	005227298	Torsion Bar Adapter Bushing	4 req	Avail to order Our Price: $20.52
9	005109714	Sway bar joint Boot	4 req	Avail to order Our Price: $30.63
10	008100807	Screw M8x40 Uni 5737/8g Zd	4 req	Avail to order Our Price: $2.00
11	005234393	Roll Bar	1 req	Avail to order Our Price: $4,010.57
12	WHT002960	SCREW	4 req	Current Stock: 3 Our Price: $9.42
13	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
14	005230258	Torsion Bar Bracket Assembly	2 req	Current Stock: 2 Our Price: $363.00
15	005238302	Torsion Bar Bushing	2 req	Avail to order Our Price: $163.27
16	410512383	Extendible 012 X 042X 46 X 35	8 req	Avail to order Our Price: $631.25
17	008101269	Screw M12x1.25x75 Uni 5738	8 req	Avail to order Our Price: $5.14
18	410512385	Shock Absorber Bulkhead	8 req	Avail to order 1 Used Available Our Price: $57.39
19	005226157	Rear Spring	4 req	Avail to order Our Price: $444.29
20	005233166	Rear Electronic Shock Absorber	4 req	Current Stock: 1 Our Price: $7,587.94
21	417801931A	STRAP JOINT	2 req	Avail to order Our Price: $284.41
22	008201034	M10x1 S. Uni5588 8g/Z Nut	2 req	Avail to order Our Price: $2.00
23	005209770	NLA (No Longer Available)	2 req	*See Description
24	008201035	M10x1 Uni 5588 8g/Z Nut	2 req	Avail to order Our Price: $2.00
25	005227295	Ball Joint (reverse thread)	2 req	Avail to order Our Price: $151.61
26	008251702	M17x1x28 Self-Locking Ring Nut	4 req	Avail to order Our Price: $4.47
27	008401708	Washer 17.5x26x3 Aq42	4 req	Current Stock: 1 Our Price: $2.92
28	005225207	Joint	8 req	Avail to order Our Price: $451.84
29	008401710	Flat Washer 17x34x1	24 req	Current Stock: 21 Our Price: $48.33
30	005225906	Rh Lower Arm	1 req	Current Stock: 2 Our Price: $1,984.26
30	005225907	Lh rear Lower Arm	1 req	Current Stock: 1 Our Price: $1,961.97
31	005225204	NLA (No Longer Available)	2 req	*See Description
32	005225909	Lh Upper Arm	1 req	Avail to order Our Price: $2,645.59
32	005225908	Rh Upper Arm	1 req	Avail to order Our Price: $2,385.50
33	005225205	Upper Arm Pin	2 req	Avail to order Our Price: $107.06
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
