TAV: 23.01.00 - Rear Differential

1998 Lamborghini Diablo SV USA Rear Differential (23.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008575501	O-Ring I 55 Uni 3654	2 req	Current Stock: 9 Our Price: $2.00
2	410103520	Bearing	1 req	Avail to order Our Price: $75.04
3	002330969	Rear Differential Propeller Sh	1 req	Avail to order Our Price: $1,709.26
4	008613510	Ring 35x55x10 mm	1 req	Current Stock: 1 Our Price: $53.98
5	008503010	Bearing	1 req	Avail to order Our Price: $25.43
6	002324939	Spacer	req	Current Stock: 14 Our Price: $43.25
7	002324938	Sleeve	1 req	Avail to order Our Price: $804.10
8	008410822	Washer	4 req	Avail to order Our Price: $2.00
9	002330693	Rear Differential Adjustment S	req	Current Stock: 12 Our Price: $28.71
9	002330694	Rear Differential Adjustment S	req	Current Stock: 7 Our Price: $40.73
9	002330695	Rear Differential Adjustment S	req	Current Stock: 11 Our Price: $40.73
9	002330696	Rear Differential Adjustment S	req	Current Stock: 9 Our Price: $40.73
9	002330697	SPES.REGOL.DIFF.POST.0,15	req	Current Stock: 14 Our Price: $28.71
10	N01024230	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $2.00
11	002328764	Shim	1 req	Avail to order Our Price: $72.46
12	008545004	Bearing	2 req	Avail to order Our Price: $155.33
13	002337199	Bevel Gear	1 req	Avail to order Our Price: $4,852.91
14	008545002	Taper Roller Bearing50x88x22	2 req	Avail to order Our Price: $535.24
15	002324942	DISCONTINUED - NLA - LIMITED QTY AVAILABLE	req	*See Description
16	002324452	Flange	1 req	Avail to order Our Price: $295.95
17	008301022	Special Stud M10x28	6 req	Avail to order Our Price: $14.02
18	008614507	Oil Seal 45x65x8 mm	2 req	Avail to order Our Price: $58.00
19	WHT000768	SPRING WASHER	6 req	Current Stock: 17 Our Price: $2.09
20	N10155210	HEX.NUT	6 req	Current Stock: 38 Our Price: $2.17
21	002333623	Drive Shaft Differential Flang	2 req	Avail to order Our Price: $424.91
22	002332653	Washer	2 req	Avail to order Our Price: $122.18
23	002332652	Washer	2 req	Avail to order Our Price: $11.34
24	002332651	Screw	2 req	Avail to order Our Price: $26.17
25	0B9517021	Rear Differential	1 req	Avail to order Our Price: $8,002.09
26	002332650	Screw	12 req	Avail to order Our Price: $31.84
27	002324940	Bushing	1 req	Avail to order Our Price: $259.36
28	002331917	Spacer	req	Current Stock: 17 Our Price: $28.62
28	002331918	Spacer	req	Current Stock: 10 Our Price: $28.71
28	002331919	Spacer	req	Current Stock: 8 Our Price: $28.71
28	002331920	Spacer	req	Current Stock: 16 Our Price: $28.71
28	002331921	Spacer	req	Current Stock: 50 Our Price: $28.71
29	008254503	M45x1.5 Special RingNut	1 req	Avail to order Our Price: $193.97
30	008575002	O-Ring D.50	1 req	Avail to order Our Price: $6.49
31	008524014	Differential Pinion Needle Bea	1 req	Avail to order Our Price: $238.55
32	86311819	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
