TAV: 13.01.01 - Intake Manifold From Engine Nr. 1889

1998 Lamborghini Diablo SV USA Intake Manifold From Engine Nr. 1889 (13.01.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	0013001063	RH Intake Manifold	1 req	Avail to order Our Price: $5,908.11
2	0013001226	Shim	4 req	Current Stock: 1 Our Price: $50.76
3	001323717	Intake Plenum Gasket	2 req	Current Stock: 1 Our Price: $57.87
4	490132008	Intake Manifold	1 req	Avail to order Our Price: $8,535.44
5	008300614	Stud M6x18 Uni 5911 8g/Zd	11 req	Avail to order Our Price: $8.72
6	N01152427	WASHER	11 req	Current Stock: 16 Our Price: $2.00
7	N01118312	HEX.HEAD CLAMPING NUT	11 req	Avail to order Our Price: $2.14
8	008200605	Simmon Nut for urama	1 req	Current Stock: 50 Our Price: $3.10
9	008300613	Stud M6x14 Uni 5911 8g/Z	1 req	Avail to order Our Price: $5.74
10	0013001062	LH Intake Manifold	1 req	Current Stock: 1 Our Price: $5,908.11
11	N0138481	WASHER	4 req	Current Stock: 43 Our Price: $2.00
12	0013001440	Eye Terminal	2 req	Avail to order Our Price: $13.13
13	0013001439	Manifold Cover Screw	2 req	Avail to order Our Price: $24.70
14	N0138481	WASHER	2 req	Current Stock: 43 Our Price: $2.00
15	001330455	Fairlead Bolt 5 mm	1 req	Avail to order Our Price: $38.60
16	001326311	Throttle Body Gasket	2 req	Current Stock: 2 Our Price: $25.67
17	001326293	Right Side Throttle Body w/TPS	1 req	Avail to order Our Price: $1,654.93
18	N01100845	HEX.NUT	4 req	Current Stock: 17 Our Price: $2.14
19	N91116801	WASHER	4 req	Current Stock: 1 Our Price: $8.93
20	008301043	Stud	4 req	Avail to order Our Price: $6.13
21	07M133119	Intake Manifold PipeInlet	1 req	Avail to order Our Price: $74.18
22	001326181	Left Side Throttle Body	1 req	Avail to order Our Price: $1,300.55
23	WHT003577	Reference Pin 6h6x16C40	4 req	Avail to order Our Price: $2.14
24	WHT003028	TAP END STUD	8 req	Avail to order Our Price: $22.20
25	WHT000771	SPRING LOCK WASHER	8 req	Current Stock: 10 Our Price: $2.00
26	N01100845	HEX.NUT	8 req	Current Stock: 17 Our Price: $2.14
27	001732808	Thermostat Housing Cover Seal	1 req	Current Stock: 23 Our Price: $27.32
28	0017006576	THERMOSTAT FOR DIABLO	1 req	Current Stock: 3 Our Price: $541.02
29	001732806	Engine Intake Thermostat Cover	1 req	Avail to order Our Price: $1,252.35
30	WHT003167	TAP END STUD	4 req	Current Stock: 1 Our Price: $11.36
31	WHT000771	SPRING LOCK WASHER	4 req	Current Stock: 10 Our Price: $2.00
32	WHT003022	NUT	4 req	Avail to order Our Price: $138.66
33	001327641	Potentiometer TPS Throttle Position Sensor Diablos	1 req	Avail to order Our Price: $199.83
34	001335307	Throttle Casing Cover Bracket	2 req	Avail to order Our Price: $32.28
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
