TAV: 43.02.00 - Steering

1998 Lamborghini Diablo SV USA Steering (43.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $2.00
2	WHT000771	SPRING LOCK WASHER	2 req	Current Stock: 10 Our Price: $2.00
2	003101941	Banjo Bolt Fitting	1 req	Avail to order Our Price: $4.65
3	008100830	Screw M8x20 Uni 5739/8g/Z	1 req	Current Stock: 19 Our Price: $2.00
4	008831320	Clamp	2 req	Avail to order Our Price: $3.70
4	004337924	Strut	1 req	Avail to order Our Price: $190.88
5	008200824	8x1.25 Din 6923 6s/Z Nut	2 req	Avail to order Our Price: $2.00
5	004033464	Oil Delivery Power Steering Bo	1 req	Avail to order Our Price: $526.19
6	004033459	Oil Return From Power Steering	1 req	Avail to order Our Price: $31.21
6	410407295	SPACER RING	req	Current Stock: 27 Our Price: $4.86
7	004338286	Steering Column Support	1 req	Avail to order Our Price: $544.16
7	004338285	This item is no longer available	1 req
7	008101039	Screw M10x100 Uni 5737 8g	4 req	Avail to order Our Price: $2.00
8	008401007	Washer 21.5x10.4x2 Uni 6592/5s	4 req	Avail to order Our Price: $2.00
8	008700830	Screw M8x45 Uni 59318g/Zd	2 req	Avail to order Our Price: $2.00
9	WHT000771	SPRING LOCK WASHER	1 req	Current Stock: 10 Our Price: $2.00
9	004333518	Steering Box Upper Rh Bracket	1 req	Avail to order Our Price: $240.80
10	004331587	Steering Column Upper Seal	1 req	Current Stock: 1 Our Price: $2.31
10	N01100845	HEX.NUT	1 req	Current Stock: 17 Our Price: $2.14
11	07M109381	Snap Ring I 35 Uni 3654	1 req	Current Stock: 35 Our Price: $2.00
11	004333655	Steering Box Lower Bracket	1 req	Avail to order Our Price: $381.94
12	410419831	CUP	1 req	Avail to order Our Price: $1,378.63
12	008581501	O-Ring E 17 Uni 7435-75	1 req	Current Stock: 16 Our Price: $2.00
13	410115207	Bearing	1 req	Avail to order Our Price: $35.93
13	004333658	Steering Box Lower Mount Shim	req	Avail to order Our Price: $11.09
14	004333657	Steering Box Lower Mount Shim	req	Avail to order Our Price: $17.11
14	004337937	No Description - Please Check your book	1 req	Avail to order Our Price: $493.49
15	004337941	Geared Shim	1 req	Avail to order Our Price: $67.00
15	N0211963	HEX.HEAD CLAMPING	3 req	Avail to order Our Price: $2.00
16	400419811A	BALL JOINT	2 req	Current Stock: 1 Our Price: $1,476.89
16	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	2 req	Current Stock: 8 Our Price: $2.00
17	008700522	Screw	2 req	Avail to order Our Price: $2.00
17	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	3 req	Current Stock: 8 Our Price: $2.00
18	N01033520	HEXAGON HEAD BOLT	2 req	Current Stock: 6 Our Price: $2.00
18	008502011	Bearing	1 req	Avail to order Our Price: $62.24
19	008581801	O-Ring E 20 Uni 7435-75	1 req	Current Stock: 18 Our Price: $2.00
19	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.43
20	004329850	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
20	004337938	No Description - Please Check your book	1 req	Avail to order Our Price: $1,610.20
21	004338318	Pin	2 req	Avail to order Our Price: $11.96
22	008700673	Screw 6.3x9.5 Iso14 Uni694 9-B	4 req	Avail to order Our Price: $11.34
22	004337939	Shim	3 req	Avail to order Our Price: $52.12
23	004337944	Bushing	1 req	Avail to order Our Price: $64.96
23	004330272	Steering Column to Chassis Boot seal	1 req	Avail to order Our Price: $86.15
24	004038062	Pump Delivery/ReturnPipe	1 req	Avail to order Our Price: $475.60
24	008201231	12x1.5 H1l 8g Z Self-Locki	1 req	Avail to order Our Price: $2.00
25	410407295D	SPACER RING	1 req	Current Stock: 11 Our Price: $31.95
25	004332458	CV Joint & Steering Box Connec	1 req	Current Stock: 1 Our Price: $408.51
26	008410820	Snap Ring D.8 Din 7980	1 req	Current Stock: 50 Our Price: $2.00
26	004337942	Pin	1 req	Avail to order Our Price: $318.06
27	WHT003591	Elastic Pin 38 Ncd4 B.	1 req	Avail to order Our Price: $14.37
27	008100831	Screw M8x30 Uni 5737/8g/Z	1 req	Avail to order Our Price: $2.00
28	004333656	Steering Box Side Lower Bracke	1 req	Avail to order Our Price: $294.31
28	004338065	Plug 6x18 mm	1 req	Avail to order Our Price: $8.65
29	004338060	Positioning Ball	1 req	Avail to order Our Price: $38.12
29	410419831	CUP	1 req	Avail to order Our Price: $1,378.63
30	410419063	STEERING GEAR	1 req	Avail to order Our Price: $4,830.52
30	004337946	Bushing	1 req	Avail to order Our Price: $290.75
31	004337952	Waster	1 req	Avail to order Our Price: $57.96
31	008401408	Annealed Copper Washer 21x14x1	2 req	Current Stock: 41 Our Price: $2.00
32	004331582	U-Bolt	1 req	Avail to order Our Price: $341.13
32	004337947	Spring	1 req	Avail to order Our Price: $14.39
33	004337948	Toothed cup	1 req	Avail to order Our Price: $168.52
34	005124347	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
34	009907111	Hadler Positioning Device 22 0 for Roof Latch	1 req	Avail to order Our Price: $12.54
35	004338317	Steering Column Adjustment Lev	1 req	Avail to order Our Price: $839.38
35	0043002396	Lower Shaft Bushing	1 req	Avail to order Our Price: $110.12
36	0043002198	Jointed Shaft	1 req	Avail to order Our Price: $661.42
36	008100824	Screw M8x75 Uni 5737-65a/F	1 req	Current Stock: 9 Our Price: $2.00
37	008581801	O-Ring E 20 Uni 7435-75	2 req	Current Stock: 18 Our Price: $2.00
37	002334682	BEVEL GEAR	2 req	Avail to order Our Price: $5,506.77
38	008700843	Screw Din 7984 8x25 10k B	2 req	Avail to order Our Price: $4.56
38	008573701	O-Ring I 37 Uni 3654	1 req	Avail to order Our Price: $2.00
39	008502011	Bearing	2 req	Avail to order Our Price: $62.24
40	0043002199	STEERING COLUMN INT. STEM	1 req	Avail to order Our Price: $156.56
41	0043002200	Steering Column Outer Sleeve	1 req	Avail to order Our Price: $1,343.27
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
