TAV: 24.01.00 - Gearbox Control Tower

1998 Lamborghini Diablo SV USA Gearbox Control Tower (24.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002437668	Gear Lever Knob	1 req	Avail to order Our Price: $116.07
2	410711267	Seal Aerostop/Fa Cn/20	1 req	Avail to order Our Price: $38.45
3	008700681	Screw M6x1x20uni593310.9 ZN	2 req	Avail to order Our Price: $2.00
4	002433903	Gear Lever Selector	1 req	Avail to order Our Price: $336.26
5	008700804	Screw 8x1.5x25 5931 8g Zg	4 req	Avail to order Our Price: $2.00
6	WHT000771	SPRING LOCK WASHER	4 req	Current Stock: 10 Our Price: $2.00
7	240132003	Gearbox Lever Complete	1 req	Avail to order Our Price: $1,908.34
8	002437767	Gear Lever Knob Adapter	1 req	Avail to order Our Price: $41.42
9	002433043	NLA (No Longer Available)	1 req	*See Description
10	002434091	Gear Lever Ball Seat	1 req	Avail to order Our Price: $281.02
11	002427202	Gear Lever Cylinder	1 req	Avail to order Our Price: $99.18
12	002432167	Gear Lever Cylinder Spring	1 req	Current Stock: 1 Our Price: $14.20
13	002427204	Retainer	1 req	Current Stock: 8 Our Price: $12.06
14	008572201	O-Ring I 22 Uni 3654	1 req	Current Stock: 4 Our Price: $2.00
15	002433020	Camshaft Sliding Bush	2 req	Current Stock: 4 Our Price: $35.87
16	002437666	Gear Change Lever	1 req	Current Stock: 1 Our Price: $1,449.17
17	008700644	Screw M6x12 Uni 5931/8g/Zd	4 req	Current Stock: 3 Our Price: $2.00
18	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
19	002429160	GEAR LEVER SPRING	1 req	Avail to order Our Price: $170.91
20	002427207	Gear Lever Bushing	1 req	Avail to order Our Price: $375.74
21	002429161	Gear Lever Shaft	1 req	Avail to order Our Price: $355.61
22	008900305	Door handle cable Pin	1 req	Current Stock: 10 Our Price: $2.00
23	410711615	JOINT WITH RH THREAD	1 req	Avail to order Our Price: $1,162.77
24	WHT003616	M12x1.25 Sin. 8g Nut	1 req	Avail to order Our Price: $9.13
25	002434472	Gearbox Tierod	1 req	Avail to order Our Price: $45.51
26	WHT003615	M12x1.25 Uni 5589 Nut	1 req	Current Stock: 17 Our Price: $2.00
27	008830305	Clamp	2 req	Avail to order Our Price: $2.00
28	410711423	Gearbox Tierod JointSleeve	1 req	Avail to order Our Price: $75.45
29	002408637	REVERSE SWITCH	1 req	Avail to order Our Price: $136.72
30	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
31	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
32	008100827	Screw M8x25 Uni 5739/8g/Zg	4 req	Current Stock: 14 Our Price: $2.00
33	002433904	Reverse Notch on Selector	1 req	Avail to order Our Price: $937.78
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
