TAV: 24.04.00 - Gearbox Oil Pump

1994 Lamborghini Diablo VT USA Gearbox Oil Pump (24.04.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002433939	Gearbox Turret MountShim	2 req	Avail to order Our Price: $47.19
2	008401421	Washer D.14.5x30x1 Uni 4721	2 req	Current Stock: 34 Our Price: $2.00
3	0B9501144	SILENTBLOC	2 req	Avail to order Our Price: $262.02
4	N10268603	HEX.HEAD CLAMPING NUT €	2 req	Avail to order Our Price: $7.30
5	002433937	Front Side Gearbox Mount	1 req	Avail to order Our Price: $486.04
6	008101411	Screw 14x1.5x85 Uni 5738/8	2 req	Current Stock: 1 Our Price: $7.60
7	008200806	M8 Uni 5588/8g/Z Nut	8 req	Current Stock: 25 Our Price: $2.00
8	WHT001514	SPRING WASHER	8 req	Current Stock: 9 Our Price: $26.80
9	008300840	Stud M8x32 Uni 5911 8g Z	8 req	Avail to order Our Price: $3.88
10	002431783	GEARBOX FRONT BOX COVER & OIL	1 req	Avail to order Our Price: $2,002.39
11	008701204	Screw M12x12uni5924/12k/Zd	4 req	Avail to order Our Price: $2.46
12	002425259	Secondary Shaft Oil Delivery N	1 req	Avail to order Our Price: $23.86
13	008100617	Screw M6x18 Uni 57395s	4 req	Avail to order Our Price: $6.79
14	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
15	002431778	GEARBOX OIL PUMP COVER	1 req	Avail to order Our Price: $502.44
16	002425185	Oil Pump Idle Gear	1 req	Avail to order Our Price: $647.05
17	002425184	Oil Pump Drive Gear	1 req	Avail to order Our Price: $574.01
18	008602301	Ring 24 mm Or	2 req	Current Stock: 2 Our Price: $2.01
19	002425246	Oil Pump Filter	1 req	Current Stock: 4 Our Price: $176.13
20	WHT003030	TAP END STUD	2 req	Avail to order Our Price: $12.95
21	008200821	M8 Self-Locking Nut	2 req	Avail to order Our Price: $3.21
22	002434272	Gearbox Mount Shim Washer	2 req	Avail to order Our Price: $49.87
23	N01033520	HEXAGON HEAD BOLT	4 req	Current Stock: 6 Our Price: $2.00
24	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
25	008400802	Copper Washer 8.4x16x1.5	4 req	Avail to order Our Price: $2.00
26	002433990	Gearbox Crossmember	1 req	Avail to order Our Price: $53.68
27	002433346	Gearbox Front Mount	1 req	Avail to order Our Price: $506.91
28	002433991	Gearbox Crossmember Shim	req	Avail to order Our Price: $61.01
29	410813761A	REINF.PLATE	req	Current Stock: 5 Our Price: $46.98
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
